roost&root Round-Top Walk-In Coop 2 Assembly Instructions Manual

Hide thumbs Also See for Round-Top Walk-In Coop 2:

Advertisement

Quick Links

Download this manual
Assembly Instructions
Round-Top Walk-In
Model 2
These written instructions, as
provided with your purchase, will
always be the latest iteration of the
instructions and match the coop
shipped and provide the most
complete up-to-date information.
We depend on feedback about our
instructions to implement changes
to future versions. Please know
that we value your input to that
ongoing process and endeavor to
produce instructions that are as
effective as possible for a wide
variety of customers.
Assembly
Overview...
Use your phones camera to read QR Code.
Video overview of assembly.
Copyright ® Roost & Root all rights reserved. This document is intellectual property of Roost & Root and is being provided to you for your own personal limited use as a
paying customer for the purpose of assembling your coop. Roost & Root claims all available Federal protection for the name Round-Top Coop ™ , our protected designs and
V1
2022
trade dress as is allowed by any and all Federal intellectual property protection laws. We invest heavily in your coop and work very hard to do a good job and it is only fair that
our workers benefit for their hard work.
Coop™
Help Text-line: 512-596-5200
EMAIL: support@urbancoopcompany.com re: Assembly Support
VOICE: 877-741-COOP | Assembly Support ext 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Round-Top Walk-In Coop 2 and is the answer not in the manual?

Questions and answers

Related Manuals for roost&root Round-Top Walk-In Coop 2

Summary of Contents for roost&root Round-Top Walk-In Coop 2

  • Page 1 Help Text-line: 512-596-5200 EMAIL: support@urbancoopcompany.com re: Assembly Support VOICE: 877-741-COOP | Assembly Support ext 3 Assembly Instructions Round-Top Walk-In Coop™ Model 2 These written instructions, as provided with your purchase, will always be the latest iteration of the instructions and match the coop shipped and provide the most complete up-to-date information.
  • Page 2 Front Left Roost Area Egg Boxes Run Door Waterer Run Roof Page Turn-Out Door Right Back We recommend having the right side of your coop facing North in winter weather intense locations.
  • Page 3 9'-11 5/8" Waterer Feeders Exterior measurements are to the outside edges of the ground foot print. Ground contact panels Sun Room Option are 1¾ inches wide. Page...
  • Page 4 Sorry... a little reading ;-) Understanding these concepts / conventions will help guide you through the instructions. Mating edges of parts to be flush and tight (when called for) will keep measurements in tolerance as the coop grows in size. CRITICAL: Having a flat area is required for the coop to assemble properly and operate properly.

  • Page 5: Please Be Careful

    Please Be Careful Coop is designed to be assembled by two people of ordinary skill. Some of the steps will need to be performed from a six foot or taller step ladder. If you are not comfortable and experienced standing on and working from a ladder you may want to get some help for those steps.
  • Page 6 Tools & Loose Parts QTY Description Gold T-25 4½” Screws Brown T-25 3” Screws Green T-20 1 5/8” Screws Bolt Style Gate Latch Eye Bolt & Hooks Neoprene Washer Roof Screws Bit Holder T-25 Bit T-20 Bit #2 Phillips Bit 12”...
  • Page 7 Front Wall Back Wall A4 Front D2 Back A1 Door Step #1 is a little time to identify parts... Page...
  • Page 8 Wire stapled to Interior Beveled Top Edge side of panel Find shipping screw in door frames that keep doors closed during transport and remove them. A stock set of storm panels are provided for these 2 doors... Looking From Inside Coop …...
  • Page 9 Back of Coop Front of Coop Roost Bar Support Bracket Wire to the Inside 11 x 15 Chicken Door Facing outside of coop Door opening fits a "Standard" sized automatic turnout door from www.chickendoors.com Page...
  • Page 10 Beveled Edge Wire On Backside Looking From Outside Coop Page...
  • Page 11 G5 Roost Bars 4X G8 Roost Ramp Supports 2X G9 Mid Roost Bar Support Hinges G6 Longer Ramp G6 Upper Ramp 2X G7 Roost Ramp Landing Page...
  • Page 12 G13 With Trimmed Edge is for the lower Roost section G12 Roof Supports G13 Roost Roof Metal G11 Eave Boards Page...
  • Page 13 Looking From Inside Beveled Coop Top Edge Wire Side Two Sets of this Perch Assembly Page...
  • Page 14 Front of Back of Coop Coop Wire Side Hole For Optional Waterer Page...
  • Page 15 F4 Inner Divider Magnets F3 Outer Divider F6 Feeder Bracket For Optional Feeders F5 Egg Box Everything illustrated Floor is 2X Page...
  • Page 16 Beveled Top Edges Wire to Back Looking From Outside Coop Page...
  • Page 17 F11 Roof Metal F12 Feeder Area Roof Beveled Edge F9 Eave F10 Eave Magnet Lipped Edge Pointed towards Center Page...
  • Page 18 E1 Mid-Arc E2 Roof Supports 6 piece set noted by E4 Galvalume® Roof Metal Panels red, green and yellow stickers. 6 equal length roof metal sections. Magnet Beveled Top Edges E3 Eaves 2 Sets of 3 Page Magnet...
  • Page 19 Y2 Optional Feeders (4) Y3 Waterer Brackets (2) Standard Poultry Nipples Y1 Optional Waterer (delivered in 2 sections) Page...
  • Page 20 This is what you're about to build. Section 1 - Run Area Back View Front View Build on level ground. Start With The End in Mind... The start of each section has an Finished coop will weigh 800+ pounds and is not designed to be illustration of what you'll end up moved without at least partial disassembly.
  • Page 21 T25 Bit Bit Holder T25 3 Inch Screw Included Included Your Drill Included Your Measure Tape D1 & A2 on outside of B2's Flush Tops Gold arrows indicate a T25 3" Screw and its direction. Back of Coop B2 Panels 25"...
  • Page 22 Open Doors To Access Screw Holes. Back of Flush Tops Coop 25" High Wire Wire 25" High Front of Coop If you don't see screw holes check other As with the egg box left side assembly, side of board or panel. make sure panels A2 and D1 are on If our shop goofed the outside of the C panels in areas...
  • Page 23 Back of Flush Tops Gold arrows indicate a Coop T25 Screw and its direction. Okay, got it. Front of Coop Temporarily place to about 27" apart... Using provided level check what you have built Page so far on all sides and adjust soil and contact points as needed.
  • Page 24 Bevel Slant Down & Out Wire Facing In on B1's Flush Tops Front of Coop Page...
  • Page 25 Open C1 Doors Wire Side Faces In to Access Screws Front of Bevel Top Slopes Down & Out Coop Access These Two Wire Side Screws From Other Side facing out Back of Coop Page...
  • Page 26 Assemble E2's as straight as possible. One trick would After connecting E2 halves slide down be to use the provided string stretched along its length into place locking notches into A3 & D2 after first screw and make it straight before screwing all 4 arcs.E1 mid roof stabilizer slides up from screws in...
  • Page 27 Door Side Stakes Using provided level When everything is great... double check top edges both sides... Should be pretty spot on. hammer door stakes into pre-drilled holes to pin door width into Using place. provided string, stretch along bottom and tops on both left and right sides and make sure middle...
  • Page 28 Top Edge Flush Middle eave board centered. T-20 With B1 Panel Tops Screw Repeat pattern both sides. Beveled Edge Up Double Bottom Boards Identify the 6 run roof panels and their features... "V" ribs point up. Left Middle Right Front Front Front Left...

  • Page 29: Please Be Careful

    Please Be Careful Using provided bit holder and neoprene washered roof screws you will install the 2 piece center portion of the roof as illustrated. Back Front Again, being careful not to shift pieces, use your drill and provided small drill bit to drill through the MB bottom back piece of metal using pre-drilled holes in top piece of MF metal for guides.
  • Page 30 Slide up and under both Please Be Careful center roof pieces. Loosen screws as needed to allow slipping in of lower panels. Slide LB left back roof panel up and under both layers of center roof sections until V grooves of center roof section line up on top of V grooves in LB panel.
  • Page 31 Instructions going forward will omit some complexity as HOPEFULLY we did a good job laying some common foundations and you are catching on to the techniques and our lingo. You can always call our support hotline at 877- 741-2667 or text your questions and photos to 512-596-5200.
  • Page 32 Install Center G11 eave first, then the outer eaves. Beveled edge of eaves will be flush with top of beveled edge of G4. Eave ends overhang about ½" each end. See next page if you ordered sunroom option. Repeat Back Side Page Wire Out Bottoms Flush...
  • Page 33 Skip Page If You Did Not Order XL Sunroom Option. Centered Support panel in place of G3's. G3's will get used in Sunroom. Right Side Front See Sun-Room addendum for completion of Sunroom after main coop is completed. Page Illustrated without sunroom option for remainder of instructions.
  • Page 34 Don't over-drive these screws or Mount G10 mid roost bar support bracket centered on the back wall 41¾ they may stick out back side. from the very bottom of the coop to the top of the bracket (yellow line). Use 4 of the 1¼...
  • Page 35 Portions of coop walls are omitted for clarity. The roost bars and access ramps are installed through a combination of reaching through the roost access doors, from inside the roost area and standing outside the coop. Place roost bars with notches towards outside and facing up.
  • Page 36 Push the TB top back panel up against the side of the coop (C2 panels) and align the pre-drilled holes along the right edge up with the center of the roost back wall, G2 Panel. Loosely screw in upper right corner. Push the TF top front panel up against the side of the coop (C2 panels) align the pre-drilled holes along the right edge up with the center of the roost front wall, G1 panel and overlap V-Grooves on the TB panel.
  • Page 37 Slide the BB panel up and under the TB & TF panels until the single "V" in the bottom panel is seated into the 2nd "V" groove of the TB & TF panels. Slide panel side-to-side to where the right edge aligns with edge of TB panel and install bottom right roof screw to pin the BB panel into place.
  • Page 38 Section Page...
  • Page 39 Flush Attach F7's to F8 Wire to Inside. Flush Flush Bottoms Attach F7 to F1 panel, making sure to keep all edges flush. Do the Page same process for Cutout for optional waterer (will have wire over it if you did not get waterer)
  • Page 40 The F5 panels install at the level as indicated by the purple arrows and attach to the F7 back egg wall door panels as illustrated using the 3 inch T25 screws. The F6 Bottom Feeder Bracket sits between the (2) F5's as shown. Install both F5's and Feeder Bracket before proceeding to step 2.
  • Page 41 Make Flush Carefully slide egg box sub assembly into place and attach on both front and back to run section. Page...
  • Page 42 The two F3 Outer Dividers are interchangeable whereas the two F4 Inner Dividers are mirrored copies of each other and have a left and a right side. Dividers are dropped down into egg box (force fit may be required) and screwed into place using 3"...
  • Page 43 Install optional water brackets & feeders. Panels hidden for clarity. Insert feeders... Shorter feeders to outside. Taller feeders to inside. Attach both water support brackets in the positions shown using T25 Screws short part of bracket to front of roost section and flush with egg box panels.
  • Page 44 F12 panel covers feeders and is held in place by magnets. Lipped Edge Out Force up against Folded Edges edge of coop. To Inside Screw in place with back edge flush the 2 F3 outer eave boards and the inner F3 eave boards. Make sure magnets in F10 face up.
  • Page 45 An extra hook and eye set is provided if you want to Align latch install inside of coop. carefully and use at least 2-3 screws and tighten. Install hinges in predrilled holes using flat head Philips Screws. Use large pan head screws to install gate latch where pin slides freely into and releases...
  • Page 46 Find shipping screw in door frame that keeps door closed during transport and remove it. Using small pan head screws install latch as illustrated. Page Small Pan Head Screw...
  • Page 47 Some things to know about using your new Round-Top Walk-In™ Chicken Coop Egg Box Liners: You will need to put some sort of a liner in the bottom of the egg boxes. We recommend a cut up doormat that can be washed.
