  • Page 1 User’s Guide T70B ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.

  • Page 2: Important Precautions

    Operate the monitor only from a power source indicated in the specifications of this manual or listed on the monitor. If you are not sure what type of power supply you have in your home, consult with your dealer.
  • Page 3 Important Precautions To Prevent Fire or Hazards: Always turn the monitor OFF if you leave the room for more than a short period of time. Never leave the monitor ON when leaving the house. Keep children from dropping or pushing objects into the monitor's cabinet openings.
  • Page 4 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 5: Connecting The Monitor

    Connecting the Monitor Before setting up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices. Carefully set the monitor face-down with the underside facing you. Connecting the Tilt/Swivel stand Align the hooks on the tilt/swivel stand with the matching slots in the base of the monitor.

  • Page 6: Using The Computer

    Connect the power cord into a properly power outlet that is easily accessible and close to the monitor. NOTE This is a simplified representation of the rear view. This rear view represents a general model; your monitor may differ from the view as shown. Wall-outlet type PC-outlet type...

  • Page 7: Control Panel Functions

    MENU Button Buttons SELECT Button Function Use this button to turn the monitor on or off. This Indicator lights up blue when the monitor operates normally. If the monitor is in DPM (Energy Saving) mode, this indicator will flicker. Use this button to enter or exit the on screen display.
  • Page 8 Control Panel Functions Control CONTROLS LOCKED CONTROLS UNLOCKED BrightView Direct Access Function CONTROLS LOCKED/UNLOCKED : MENU and This function allows you to secure the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button and button for 5 seconds: the message "CONTROLS LOCKED"...

  • Page 9: On Screen Display (Osd) Control Adjustment

    Making adjustments to the image size, position and operating parameters of the monitor is quick and easy with the On Screen Display Control system. A short example is quick and easy given below to familiarize you with the use of the controls.

  • Page 10: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Icon Main menu Contrast Brightness H Position H Size V Position V Size Tilt Pincushion Pin Balance Parallelogram Trapezoid Top Corner : Adjustable NOTE The order of icons may differ depending on the model (A9~A12).
  • Page 11 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Icon Sub menu CONTRAST...
  • Page 12 Balance, Parallelogram, Trapezoid, Top Corner, Bottom Corner (These recalled options may differ depending on the mode selected: Preset, User, or New). If you don’t want to recall the monitor to these modified settings, use the CANCEL and then press the SELECT button.
  • Page 13 Brightness, Contrast, Tilt, Color 9300, Video Level, OSD Time, Moire (These reset options may differ depending on the mode selected: Preset, User, or New). If you don’t want to reset the monitor, use the button to select CANCEL and then press the SELECT button.

  • Page 14: Troubleshooting

    • Press the Power button. • Adjust the brightness and the contrast. • If the monitor is in power saving mode, try moving the mouse or pressing any key on the keyboard to bring up the screen.
  • Page 15 Brighten the screen and use the ' M OIRE' icon on the screen adjustment menu to adjust the screen. • Be sure to install the monitor driver from the monitor driver CD (or diskette) that comes with your monitor. Or, you can also download the driver from our web site: http://www.lge.com.

  • Page 16: Specifications

    Specifications Picture Tube 17 inches (16.0 inches viewable) 106 degree deflection 0.25mm dot pitch AGARAS(Anti-Glare Anti-Reflective Anti-Static) coating Sync Input Horizontal Freq. Vertical Freq. Input Form Signal Input Input Form Video Input Resolution Recommend DDC 2B Plug&Play Power Sleep Consumption Width Dimensions Height...

  • Page 17: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) VESA 640 x 480 VESA 800 x 600 VESA 800 x 600 VESA 1024 x 768 Horizontal Freq. (kHz) Vertical Freq. (Hz) 37.50 46.88 53.674 68.677...
  • Page 18 Digitally yours...
