- Page 1 User’s Guide T710BH/T710SH ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.
-
Page 2: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions To Prevent Fire or Hazards: Always turn the monitor OFF if you leave the room for more than a short period of time. Never leave the monitor ON when leaving the house. Keep children from dropping or pushing objects into the monitor's cabinet openings.
-
Page 4: Connecting The Monitor
Connecting the Monitor Before setting up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices. Carefully set the monitor face-down with the underside facing you. Connecting the Tilt/Swivel stand Align the hooks on the tilt/swivel stand with the matching slots in the base of the monitor. -
Page 5: Using The Computer
Connecting the Monitor Using the Computer Connect the signal cable. When mated, tighten the thumbscrews to secure the connection. Connect the power cord into a properly power outlet that is easily accessible and close to the monitor. NOTE This is a simplified representation of the rear view. This rear view represents a general model;... -
Page 6: Control Panel Functions
Control Panel Functions Front Panel Controls Brightview Control Function Power Button Use this button to turn the monitor on or off. This Indicator lights up green when the monitor Power (DPMS) operates normally. If the monitor is in DPM (Energy Indicator Saving) mode, this indicator will flicker. - Page 7 Control Panel Functions Control Direct Access Function Button Bring up Contrast adjustment Button Bring up Brightness adjustment The Contrast and Brightness functions are also available in the On Screen Display (OSD) menu. CONTROLS LOCKED/UNLOCKED : MENU and This function allows you to secure the current CONTROLS LOCKED control settings, so that they cannot be inadvertently changed.
-
Page 8: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the monitor is quick and easy with the On Screen Display Control system. A short example is quick and easy given below to familiarize you with the use of the controls. -
Page 9: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness and Brightness contrast of the screen Contrast BRIGHTNESS/ CONTRAST V Position To adjust the position of the screen H Position... -
Page 10: To Adjust The Brightness And Contrast Of The Screen
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE The order of icons may differ depending on the model (A9~A12). -
Page 11: To Adjust The Size Of The Screen
On Screen Display(OSD) Selection and Adjustment To adjust the size of the screen OSD Adjust Description Vertical Size To adjust image height. Horizontal Size To adjust image width. To adjust the shape of the screen OSD Adjust Description Tilt To correct image rotation. Side Pincushion To correct a concave or convex bowing of the image. -
Page 12: To Customize The Color Of The Screen
On Screen Display(OSD) Selection and Adjustment To customize the color of the screen OSD Adjust Description PRESET 6500K/ 9300K Select the screen color. • 6500K: Slightly reddish white. • 9300K: Slightly bluish white. TEMP Select the screen temperature which you prefer among reddish or bluish or any color in between. -
Page 13: To Improve The Clarity And Stability Of The Screen
On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description DEGAUSS To manually demagnetize the screen to avoid showing incorrect images or colors. RECALL You can use this function to reload the modified parameters for screen display operation, as specified by the user after purchase: Position, Size, Side Pincushion,... -
Page 14: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears ❐ Is the power cord of the • Check and see if the power cord is connected properly to monitor connected? the power outlet. ❐ Is the power indicator light •... - Page 15 Troubleshooting The screen color is not normal. ❐ Do you see basic • Set the color depth to 256 colors or higher: use ' Control discoloration (16 colors)? Panel ' - >' Display ' - >' Settings ' - >' Color Palette ' ❐...
-
Page 16: Specifications
Separate, RGB Analog, 0.7Vp-p/75 ohm, Positive Video Input VESA 1280 x 1024 @ 60Hz Resolution Recommend VESA 1024 x 768 @ 85Hz DDC 2B Plug&Play T710BH T710SH ≤ 63W ≤ 63W Power Sleep ≤ 3W Sleep ≤ 4W Consumption ≤ 3W ≤... -
Page 17: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 37.50 VESA 640 x 480 VESA 46.88 800 x 600 VESA 53.674 800 x 600 68.677 VESA 1024 x 768... - Page 18 Digitally yours...
