HOT CUPBOARD (ELECTRICAL)
USER'S MANUAL
PRODUCTION YEAR:
SERIAL NO :
081
MANUFACTURER
: ÖZTİRYAKİLER MADENİ EŞYA SAN. VE TİC A.Ş.
PRODUCTION SITE : Cumhuriyet Mh. Eski Hadımköy Yolu No:37 Büyükçekmece İstanbul/TÜRKİYE
Phone : 0090 212 886 78 00 (8 Hat-Lines) Fax : 0090 212 886 66 29
Our website:
www.oztiryakiler.com.tr
e-mail: export@oztiryakiler.com.tr
VER . 05
1/16
Published on
: 23.01.2007
Advertisement
Table of Contents
Related Manuals for OZTI OSD 800
Summary of Contents for OZTI OSD 800
- Page 1 HOT CUPBOARD (ELECTRICAL) USER’S MANUAL PRODUCTION YEAR: SERIAL NO : MANUFACTURER : ÖZTİRYAKİLER MADENİ EŞYA SAN. VE TİC A.Ş. PRODUCTION SITE : Cumhuriyet Mh. Eski Hadımköy Yolu No:37 Büyükçekmece İstanbul/TÜRKİYE Phone : 0090 212 886 78 00 (8 Hat-Lines) Fax : 0090 212 886 66 29 Our website: www.oztiryakiler.com.tr...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE NR. TOPICS COVER PAGE TABLE OF CONTENTS INTRODUCTION TECHNICAL DATA ELECTRICAL CIRCUIT DIAGRAM MAIN DIMENSIONS WARNING SIGNS 8 – 9 SAFETY DETAILS TRANSPORTING AND MOVING INSTALLATION OF THE DEVICE CONTROL BOARDS 13 -14 OPERATION OF THE DEVICE CLEAN-UP AND MAINTENANCE TERMS OF GUARANTEE CAUTION... -
Page 3: Introduction
INTRODUCTION Dear User, Thank you for purchasing our device and for your reliance upon our company. Our devices have been used within our customers kitchen, your kitchen in 75 countries. Our devices are produced in compliance with international standards. Important notice: Please read or ensure that the users read this user’s manual in order to achieve the desired performance in line with your expectations and to use your device for long years. -
Page 4: Technical Data
TECHNICAL DATA YOUR DEVICE'S TYPE OSD 1200 OSD 800 OSD 1600 1200X700X550 800X700X550 1600X700X550 MAIN DIMENSIONS (mm) 1538 1538 1538 TOTAL ELECTRICAL INPUT (W) POWER SUPPLY VOLTAGE (V) WORKING FREQUENCY (Hz) THERMOSTAT (°C) 30 – 90 30 – 90 30 – 90... - Page 5 ELECTRICAL SCHEMA 4500 W ALL OSD SERIES CODE COMPONENTS Resistance Thermostat lamp Green Thermostat 30-90 °C Switch Motor 5/16...
-
Page 6: Main Dimensions
MAIN DIMENSIONS OSD 800 6/16... -
Page 7: Warning Signs
WARNING SIGNS POWER NETWORK GROUNDING GROUNDING POWER OVERHEAT POWER SUPPLY CONNECTIONS 220-240V NPE / 50 Hz VOLTAGE: 220-240 V SUPPLY CONNECTION: SINGLE PHASE GROUNDED FREQUENCY : 50 Hz 7/16... -
Page 8: Safety Details
SAFETY DETAILS ☞ The device should only be operated under a chimney hood. ☞ Any kind of flammable solid and liquid material (cloths, alcohol and derivatives, petrochemical products, wooden and plastic materials, cutting blocks, curtains etc.) should never be held near the device. ☞... - Page 9 SAFETY DETAILS ☞ The device should not be handled by anyone else except for the manufacturer or authorized service. ☞ In case of fire or flame in the area where the device is operated, act without panic, close gas valves, turn off power switches and use a fire extinguisher.
-
Page 10: Transporting And Moving
TRANSPORTING AND MOVING CHANGING THE LOCATION; Machines installed by an authorized service CANNOT BE MOVED ELSEWHERE, ITS POWER SUPPLY CABLES CANNOT BE EXTENDED OR REPLACED except by an authorized service. ☞ The vehicle can be moved with supplementary vehicles like forklift. ☞... -
Page 11: Installation Of The Device
INSTALLATION OF THE DEVICE If this device located near to any wall, separation, kitchen furniture, decorative coating etc. the distance in between should be 20 cm. and if those are coated with fireproof heat insulating material, the distance should be 5 cm. It is strongly recommended that fire safety protection instructions are observed. All of the items mentioned below in connection with the installation of the device should be carried out by authorized service personnel. -
Page 12: Control Boards
CONTROL BOARDS ALL OSD SERIES A : ON-OFF SWITCH B : POWER WARNING LAMP C : THERMOSTAT D : THERMOSTAT LAMP 12/16... -
Page 13: Operation Of The Device
OPERATION OF THE DEVICE Hot cupboard is used in kitchens of restaurants, fast food stands, canteens, hospitals in order to keep the plate warm and ready for service. Before initial use of the device, the outer surface should be wiped with a cloth soaked in warm water and soap. - Page 14 OPERATION OF THE DEVICE CAUTION! : The device should be installed and operated as described in this user’s manual. If any failure is encountered please contact our nearest authorized service dealer. WHEN THE DEVICE HAS A FAILURE ONLY AUTHORIZED ………SERVICE DEALERS ARE ALLOWED TO HANDLE THE DEVICE.
-
Page 15: Clean-Up And Maintenance
CLEAN-UP AND MAINTENANCE 1. CLEAN-UP: Before (before the power is switched on) and after the first use and every subsequent use, outer surface of the device should be completely cleaned up with sponge and liquid detergent and then wiped dry. Do not use CHEMICAL CLEANING AGENTS like hydrochloric acid or abrasive cleaning agents. - Page 16 WARRANTY CONDITIONS 1- Documents without sales date, factory and sales company approval on, are not valid. In order to benefit from the guarantee, guarantee document should be presented. 2- If the device is installed and operated following the instructions in the installation, maintenance and user's manual, it is warranted for failures resulting from failures resulting from workmanship and material failures.
