FIT0677
Aluminum Heatsink Case for LattePanda V1
A s s e m b l y M a n u a l
Cain / 2021.04.25
lattepanda@outlook.com

Advertisement

loading

Summary of Contents for DFRobot FIT0677

  • Page 1 FIT0677 Aluminum Heatsink Case for LattePanda V1 A s s e m b l y M a n u a l Cain / 2021.04.25 lattepanda@outlook.com...
  • Page 2 Check Check all the parts in the package and make sure the parts are complete. • The top panel(with Logo)x1 • The side panel x4 • L Bracket x2 • L Bracket with wing shaped plate x2 • Heat-dissipation module x1 •...
  • Page 3 Assembly Assembly of the Heatsink The parts used: • LattePanda board x1 • Heat dissipation module x1 • Thermal pad x2 • M3 cross screw x4...
  • Page 4 Assembly Fit Thermal Pad The parts used: • Heat-dissipation module x1 • Thermal pad x2 Guide: 1. Split plastic films on both sides of the thermal pad. 2. Fit the thermal pads on these two positions indicated with red frame These two main heating source on lines.
  • Page 5 Assembly Mount the Heat-dissipation Module The parts used: • LattePanda board x1 • Heat-dissipation module x1 • M3 cross screw x4 Guide: 1. Mount the board on the heat-dissipation module. 2. Turn the screws on the corners. The protrusion structure on the back of the heat dissipation module is consistent with the shielding cover on the back of the board.
  • Page 6 Assembly Tips: There is no need to turn the screws too tightly Because the thermal pad needs to be fully filled with heat-dissipation module and board to play the role of heat conduction. In the material selection, we specially selected a slightly thicker specification than the gap to ensure the conduction.
  • Page 7 Assembly Assembly of the Antenna The parts used: • The side panel x1 • IPEX to SMA adapter x1 • SMA Wi-Fi & BT antenna x1 Note: Please use the side panel with antenna installation hole.
  • Page 8 Assembly Install IPEX to SMA Adapter The parts used: • The side panel x1 • IPEX to SMA adapter x1 Guide: 1. Unscrew the outermost nut at the adapter. 2. Plug the adapter into the antenna installation hole from the rear. 3.
  • Page 9 Assembly Install Wi-Fi & BT Antenna The parts used: • Previously assembled component x1 • SMA Wi-Fi & BT antenna x1 Guide: 1. Screw the antenna on the component. *Due to filming obscuration, the antenna part will be removed for now in the subsequent Assembly.
  • Page 10 Assembly Assembly of bottom frames The parts used: • L Bracket with wing shaped plate x2 • Previously assembled component x1 • M3 cross screw x2 Note: Use the L Bracket as shown in the picture.
  • Page 11 Assembly Mount the L Bracket at the bottom The parts used: • L Bracket with wing shaped plate x2 • Previously assembled component x1 • M3 cross screw x2 Guide: 1. Align the screw holes on the L Bracket and the bottom of the component. 2.
  • Page 12 Assembly Tips: How to align the panel and the L Bracket Place the L bracket flat on the table to quickly align the fixing screw holes of the side panel and L bracket.
  • Page 13 Assembly Assembly of the board The parts used: • LattePanda board with the heatsink x1 • Previously assembled component x1...
  • Page 14 Assembly Mount the LattePanda board The parts used: • LattePanda board with the heatsink x1 • Previously assembled component x1 Guide: 1. Position the HDMI port side of the board toward the panel on the bottom frames. 2. Insert the edge protrusion of heatsink into the top groove of L bracket.
  • Page 15 Assembly Tips: Notice the insertion direction of the board Please install the board according to the hole shape and silk screen printing label.
  • Page 16 Assembly Connect the Antenna The parts used: • Previously assembled component x1 Guide: 1. Connect the IPEX to SMA adapter to the board. 2. Arrange the antenna cable. Note: Install the antenna by inserting the round shaped end into the socket labeled “ANT” located next to the GPIO pins on the board.
  • Page 17 Assembly Tips: Place the antenna cable • Antenna cable can bend and finalize the shape to a certain extent. • The antenna cable can be clamped through the gap between the female header and the shield.
  • Page 18 Assembly Assembly of the side panel The parts used: • Previously assembled component x1 • The side panel x2 • Switch button x2...
  • Page 19 Assembly Mount one side of the panel The parts used: • Previously assembled component x1 • The side panel x1 Guide: 1. Insert the side panel into the slot. Note: If you need to install the screen and touch panel, please insert them under this step.
  • Page 20 Assembly Mount the other side panel The parts used: • Previously assembled component x1 • The side panel x1 • Switch button x2 Guide: 1. Put the two buttons in the position from the back of the panel. 2. Insert the side panel into the slot.
  • Page 21 Assembly Assembly of top frames The parts used: • Previously assembled component x1 • L Bracket x2 • M3 cross screw x2 Note: Use the L Bracket as shown in the picture.
  • Page 22 Assembly Mount the top frames The parts used: • Previously assembled component x1 • L Bracket x2 • M3 cross screw x2 Guide: 1. Align the slot on the L Bracket and the side panel, then, insert. 2. Turn the screws tightly.
  • Page 23 Assembly Assembly of the top panel The parts used: • Previously assembled component x1 The top panel(with Logo)x1 •...
  • Page 24 Assembly Mount the top panel The parts used: • Previously assembled component x1 The top panel(with Logo)x1 • Guide: 1. Slide the panel into the top frames.
  • Page 25 Assembly Assembly of the side panel The parts used: • Previously assembled component x1 • The side panel x1 • M3 cross screw x4...
  • Page 26 Assembly Install the last panel The parts used: • Previously assembled component x1 • The side panel x1 • M3 cross screw x4 Guide: 1. Put on the side panel. 2. Turn four screws tightly.
  • Page 27 Assembly Done!
  • Page 28 Supplement How to confirm the boot status of the LattePanda board • You can observe whether the small light is on through the hollow position of the side panel to determine the boot status of the board.
  • Page 29 Supplement How to Extend a Touch Display • Pass the FPC cable through the hollow of the side panel and fix it on the board interface. • Then, insert the side panel into the slot. Note: Please be careful of the FPC cable, do not pinch or damage during this period.
  • Page 30 Thank You! 2021.05.18...
