Master Specification
Data Collector with Bluetooth
OPN-3002n
XF2OPN3002
2013- -
4 - 1 2 - 1 7 T s u k a g o s h i W a r a b i - s h i , S a i t a m a
C S
Q A/QC
DOC_ID SS13022
st
Edition
1
O p t o e l e c t r o n i c s C o . , L t d .
照査
3 3 5 - 0 0 0 2 J a p a n
TEL +81-48-446-1183
FAX +81-48-446-1184
作成
Advertisement
Table of Contents
Related Manuals for Optoelectronics OPN-3002n
Summary of Contents for Optoelectronics OPN-3002n
- Page 1 Master Specification Data Collector with Bluetooth Model No. OPN-3002n Manufacturing XF2OPN3002 DOC_ID SS13022 Specification No. Issue No. Edition Issue Date 2013- - Approved by O p t o e l e c t r o n i c s C o . , L t d .
- Page 2 OPN-3002n DOC ID：SS13022 Revision History ：SS13022 DOC_ID Model No. ：OPN-3002n Edition Date Section Description of Changes （Initial Issue） 2013- -...
-
Page 3: Table Of Contents
OPN-3002n DOC ID：SS13022 Index page 1. ABSTRACT ..........................1 2. OVERVIEW ..........................1 3. BASIC SPECIFICATION ......................2 4. DETAILED VIEW ........................5 5. ELECTRICAL SPECIFICATIONS ................... 6 ＵＳＢ ............................. 6 5.1. Charging Cradle ......................... 6 5.2. 6. INTERFACE ..........................6 USB ............................. - Page 4 OPN-3002n DOC ID：SS13022 Export Administration Regulations ..................18 13.4. Bluetooth ..........................18 13.5. Frequency Band ........................18 13.6. 14. PRODUCT LABEL ......................... 20 15. PACKAGING SPECIFICATIONS ..................21 Individual Packaging Specification ..................21 15.1. Collective Packaging Specification ..................22 15.2.
-
Page 5: Abstract
This manual provides specifications for the OPN-3002n 2D Imager Barcode Scanner. 2. Overview The OPN-3002n scanner enables data transmission of barcode using Bluetooth wireless thechnology. ⚫ The OPN-3002n is handy and simple data collector. Data transmission is performed via a USB or Bluetooth. -
Page 6: Basic Specification
OPN-3002n DOC ID：SS13022 3. Basic Specification Item Spedification Note 32bit CISC/96MHz FROM 512Kbyte + 32KByte SRAM 96Kbyte FROM(strage) 1Mbyte For user data Key type 2 keys: Trigger, Function bi-colors(red and green) 2pcs, a blue LED Tone:variable frequency, Volume:3-level Beeper variable... - Page 7 OPN-3002n DOC ID：SS13022 Possible to read: UPC 100% moving at 2 m/s (DOF: Motion tolerance 100 mm) Resolution (0.127) 65 - 105 Code 39 Resolution (0.254) 45 - 185 Depth Resolution (0.508) 50- 250 field (mm) Code 128 Resolution (0.2) 65 - 150 Resolution (0.33)
- Page 8 OPN-3002n DOC ID：SS13022 Item Specification Note Main Battery Lithium-ion polymer battery 600mAh(typ.) When a barcode is scanned Up-time 10hours or more twice in 10 sec. at 25 deg. C Range of Operation(Charging) 4.5 - 5.5 V Voltage Current consump Charging <500mA...
-
Page 9: Detailed View
OPN-3002n DOC ID：SS13022 4. Detailed View Figure 1:Detailed View Description Name Scanning Window Laser light is emitted through this window to read bar codes. Scanning Window The laser light is emitted through this window. Trigger Key A trigger key used to read bar codes... -
Page 10: Electrical Specifications
： Hi-Power ( 500mA max ) ・Current consumption ： <500mA 5.2. Charging Cradle ・Voltage ： 4.5-5.5V 6. Interface The OPN-3002n supports USB, Bluetooth and serial interfaces. 6.1. USB This interface supported FULL Speed USB. 6.1.1. Connector ..Signal Pin No. -
Page 11: Bluetooth
OPN-3002n DOC ID：SS13022 6.2. Bluetooth The OPN-3002n supported Bluetooth. Frequency : 2402MHz - 2480MHz Specification : Bluetooth Ver2.1 Communication : 10ｍ distance Output level : Class 2 (4dBm Max. (25℃)) Supported profiles : SPP/HID Topology of connection : Point-to-point Operating mode... -
Page 12: Aiming Pattern
OPN-3002n DOC ID：SS13022 7.2. Aiming Pattern Figure 4 : Aiming Pattern and Imaging Range 7.3. Imaging Range The range is ±5% from the following values. [mm] L: Distance from the front edge of scanner H: Horizontal imaging range [mm] [mm]... -
Page 13: Technical Specifications
Barcode Test Sample (1D and 2D) Specified below. < Test chart > For 1D codes, OPTOELECTRONICS test samples For GS1 Databar, stacked codes and 2D codes, printed by a dedicated printer for bar code 8.1. Bar code Test Sample 1D Bar Codes <Code 39>... - Page 14 OPN-3002n DOC ID：SS13022 2D Codes <PDF417> Resolution Error Correction Size (mm) No. of Character 0.169 mm (6.7 mil) 23 × 10 Level-3 0.254 mm (10 mil) 35 × 15 <QR Code: Model-2> Resolution Error Correction Size (mm) No. of Character 0.212 mm (8.4 mil)
-
Page 15: Scan Area And Depth Of Field
OPN-3002n DOC ID：SS13022 8.2. Scan Area and Depth of Field 0 . 127 0 . 254 Code 39 [ Unit ： mm ] ： 0 . 508 0 . 20 Code 128 0 . 33 UPC 100 % 0 . 169 PDF 417 0 . -
Page 16: Minimum Resolution
OPN-3002n DOC ID：SS13022 8.4. Minimum Resolution 1D Code : 0.127 mm (5 mil) Code 39 specified in Chapter 8.1 GS1-Databar : 0.169 mm (6.7 mil) GS1 Databar Limited specified in Chapter 8.1 Stacked Code : 0.169 mm (6.7 mil) PDF417, GS1 Databar Limited Composite specified in Chapter 7.1 2D Code : 0.212 mm (8.4 mil) -
Page 17: Curvature
OPN-3002n DOC ID：SS13022 γ β Figure 7 : Pitch, Skew and Tilt 8.7. Curvature : R ≧ 20 mm 0.33 mm 12-digit UPC : R ≧ 16 mm 0.15 mm 10-digit Codabar <Conditions> Bar Code Sample : 0.33 mm UPC, 0.15 mm Codabar specified in Chapter 7.1... -
Page 18: Environmental Specifications
Power Supply Voltage : 3.7 V * Be sure that the direct light or specular reflection from the light source does not enter the light receiving section of the OPN-3002n. 9.4. Dust and Drip Proof IEC IP42 equivalent Protection against solid objects: Level 4 Protected against solid objects greater than 1.0 mm... -
Page 19: Vibration Strength(Without Packing)
OPN-3002n DOC ID：SS13022 9.5. Vibration Strength(without packing) There shall be no sign of malfunction after the following vibration test. Vibration test: Increase the frequency of the vibration from 10Hz to 100Hz at an accelerated velocity of 19.6m/s2 (2.0 G) for 30 minutes (60 minutes for a cycle) in the non-operating state. Repeat this in each X, Y and Z direction. -
Page 20: Regulatory Compliance
OPN-3002n DOC ID：SS13022 10. Regulatory Compliance 10.1. LED Safety IEC 62471-1:2006 Exempt Risk Group 10.2. Product Safety EN60950-1:2005 IEC60950-1:2006 10.3. EMC EN55022 EN55024 FCC Part 15 Subpart C , Subpart B ClassB Federal Communications Commission Notices This product complies with Part 15 of the FCC Rules. Operation is subject to the... -
Page 21: Other
10.4. Other Bluetooth logo certification MFi License Program The OPN-3002n uses Bluetooth module which qualifies as radio equipment for low-power radio stations as specified in the Radio Law 38-24-1. Specified Radio Equipment： Low power data communications system in the 2.4GHz band in Article 2 paragraph 1 item (19), Ordinance of MPT. -
Page 22: Radio Low
It may have an effect on the communication speed or communication range of this data collector. ・ The use of OPN-3002n outside of the European Union, the United States and Canada is punishable under the law. - Page 23 OPN-3002n DOC ID：SS13022 license for such as manufacturing lines at factories, specific power-saving radio station requiring no license and amateur radio station are managed. 1. Please make sure that “other radio stations” are not managed in the frequency band 2.4 GHz before using this product.
-
Page 24: Product Label
OPN-3002n DOC ID：SS13022 14. Product Label The labels shown below are attached to the back side of the data collector. Figure 10: Product & Laser Caution Label... -
Page 25: Packaging Specifications
OPN-3002n DOC ID：SS13022 15. Packaging Specifications 15.1. Individual Packaging Specification Assembled package size: 125 x 112 x 40 (WDH mm) AIR PACKING OPN10018003-0-01 Poly bag ﾃｰﾌﾟ止めはしないで折り返したまま Neck strap 折り返しを下にして箱に詰める Mini USB cable No.OPN20018001-0-00 ｼﾘｱﾙNo. の 表 示 に つ い て... -
Page 26: Collective Packaging Specification
OPN-3002n DOC ID：SS13022 15.2. Collective Packaging Specification Assembled package size: 595 x 520 x 245 (WDH mm), 100 pieces/box ｼ ﾘｱ ﾙ No . の 順 序 集 合 箱 ： 5B 0 00 8( 1 00 p 入 ) ⑪... -
Page 27: Warranty
16. Warranty 16.1. Warranty period OPTOELECTRONICS Co., Ltd. warrants that this product is free of defects or malfunctions for a period of twelve (12) months from its shipment. In case of having defects or malfunctions caused by normal usage in accordance with this specification during the foregoing warranty period, OPTOELECTRONICS shall repair or adjust the product free of charge. -
Page 28: Mechanical Drawing
OPN-3002n DOC ID：SS13022 17.3. Mechanical Drawing Figure 13: Mechanical Drawing... -
Page 29: Supported Symbologies
OPN-3002n DOC ID：SS13022 18. Supported Symbologies The OPN-3002n is set to default settings by reading the following menu label regardless of the interface types. Default @MENU_OPTO@ZZ@SO@ZZ@OTPO_UNEM@ 18.1. 1D symbologies Minimum Code type Default Remarks length ○ UPC Add-on 2 UPC Add-on 5 ○... -
Page 30: Gs1 Databar, Composite Code
OPN-3002n DOC ID：SS13022 18.2. GS1 Databar, Composite Code Code type Default Remarks GS1 DataBar ・GS1 DataBar Omnidirectional ・GS1 DataBar Truncated ○ ・GS1 DataBar Stacked ・GS1 DataBar Stacked Omnidirectional GS1 conversion (setting required) ○ GS1 DataBar Limited GS1 DataBar Expanded ・GS1 DataBar Expanded ○...
