Model No.
Manufacturing
Specification No.
Issue No.
Issue Date
Approved by
営業
営業管理
Master Specification
Data Collector with Bluetooth
OPN-3002i
XF2OPN3002
2013- -
4 - 1 2 - 1 7 T s u k a g o s h i W a r a b i - s h i , S a i t a m a
C S
Q A/QC
DOC_ID SS13001
st
Edition
1
O p t o e l e c t r o n i c s C o . , L t d .
照査
3 3 5 - 0 0 0 2 J a p a n
TEL +81-48-446-1183
FAX +81-48-446-1184
作成
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Optoelectronics OPN-3002i
Summary of Contents for Optoelectronics OPN-3002i
- Page 1 Master Specification Data Collector with Bluetooth Model No. OPN-3002i Manufacturing XF2OPN3002 DOC_ID SS13001 Specification No. Issue No. Edition Issue Date 2013- - Approved by O p t o e l e c t r o n i c s C o . , L t d .
- Page 2 OPN-3002i DOC ID：SS12003 Revision History DOC_ID ：SS12003 Model No. ：OPN-3002i Edition Date Section Description of Changes 2013- - （Initial Issue）...
-
Page 3: Table Of Contents
OPN-3002i DOC ID：SS12003 page Index 1. ABSTRACT ..........................1 2. OVERVIEW..........................1 3. BASIC SPECIFICATION ......................2 4. DETAILED VIEW........................5 5. ELECTRICAL SPECIFICATIONS .................... 6 ＵＳＢ............................6 5.1. Charging Cradle ........................6 5.2. 6. INTERFACE ..........................6 USB ............................6 6.1. - Page 4 OPN-3002i DOC ID：SS12003 Export Administration Regulations..................18 13.4. Bluetooth..........................18 13.5. Frequency Band........................18 13.6. 14. PRODUCT LABEL ........................20 15. PACKAGING SPECIFICATIONS ................... 21 Individual Packaging Specification ..................21 15.1. Collective Packaging Specification ..................21 15.2. 16. WARRANTY..........................22 Warranty period........................
-
Page 5: Abstract
This manual provides specifications for the OPN-3002i 2D Imager Barcode Scanner. 2. Overview The OPN-3002i scanner enables data transmission of barcode using Bluetooth wireless thechnology. The OPN-3002i is handy and simple data collector. Data transmission is performed via a USB or Bluetooth. -
Page 6: Basic Specification
OPN-3002i DOC ID：SS13001 3. Basic Specification Item Spedification Note 32bit CISC/96MHz FROM 512Kbyte + 32KByte SRAM 96Kbyte FROM(strage) 1Mbyte For user data Key type 2 keys: Trigger, Function bi-colors(red and green) 2pcs, a blue LED Tone:variable frequency, Volume:3-level Beeper variable... - Page 7 OPN-3002i DOC ID：SS13001 Possible to read: UPC 100% moving at 2 m/s (DOF: Motion tolerance 100 mm) Resolution (0.127) 65 - 105 Code 39 Resolution (0.254) 45 - 185 Depth Resolution (0.508) 50- 250 field (mm) Code 128 Resolution (0.2) 65 - 150 Resolution (0.33)
- Page 8 OPN-3002i DOC ID：SS13001 Item Specification Note Main Battery Lithium-ion polymer battery 600mAh(typ.) When a barcode is scanned Up-time 10hours or more twice in 10 sec. at 25 deg. C Range of Operation(Charging) 4.5 - 5.5 V Voltage Current consump Charging <500mA...
-
Page 9: Detailed View
OPN-3002i DOC ID：SS13001 4. Detailed View Figure 1:Detailed View Description Name Scanning Window Laser light is emitted through this window to read bar codes. Scanning Window The laser light is emitted through this window. Trigger Key A trigger key used to read bar codes... -
Page 10: Electrical Specifications
： Hi-Power ( 500mA max ) ・Current consumption ： <500mA 5.2. Charging Cradle ： 4.5-5.5V ・Voltage 6. Interface The OPN-3002i supports USB, Bluetooth and serial interfaces. 6.1. USB This interface supported FULL Speed USB. 6.1.1. Connector ..Signal Pin No. -
Page 11: Bluetooth
OPN-3002i DOC ID：SS13001 6.2. Bluetooth The OPN-3002i supported Bluetooth. Frequency : 2402MHz - 2480MHz Specification : Bluetooth Ver2.1 Communication : 10ｍ distance Output level : Class 2 (2dBm Max.) Supported profiles : SPP/HID Topology of connection : Point-to-point Operating mode... -
Page 12: Aiming Pattern
OPN-3002i DOC ID：SS13001 7.2. Aiming Pattern Figure 4 : Aiming Pattern and Imaging Range 7.3. Imaging Range The range is ±5% from the following values. [mm] L: Distance from the front edge of scanner [mm] H: Horizontal imaging range [mm]... -
Page 13: Technical Specifications
Barcode Test Sample (1D and 2D) Specified below. < Test chart > For 1D codes, OPTOELECTRONICS test samples For GS1 Databar, stacked codes and 2D codes, printed by a dedicated printer for bar code 8.1. Bar code Test Sample 1D Bar Codes <Code 39>... - Page 14 OPN-3002i DOC ID：SS13001 2D Codes <PDF417> Resolution Error Correction Size (mm) No. of Character 0.169 mm (6.7 mil) 23 × 10 Level-3 0.254 mm (10 mil) 35 × 15 <QR Code: Model-2> Resolution Error Correction Size (mm) No. of Character 0.212 mm (8.4 mil)
-
Page 15: Scan Area And Depth Of Field
OPN-3002i DOC ID：SS13001 8.2. Scan Area and Depth of Field 0.127 0.254 [ Unit ： mm ] Code 39 ：0.508 0.20 Code 128 0.33 UPC 100 % 0.169 PDF 417 0.254 0.212 QR Code 0.381 0.254 Data Matrix Figure 5: Depth of Field 8.3. -
Page 16: Minimum Resolution
OPN-3002i DOC ID：SS13001 8.4. Minimum Resolution 1D Code : 0.127 mm (5 mil) Code 39 specified in Chapter 8.1 GS1-Databar : 0.169 mm (6.7 mil) GS1 Databar Limited specified in Chapter 8.1 Stacked Code : 0.169 mm (6.7 mil) PDF417, GS1 Databar Limited Composite specified in Chapter 7.1 2D Code : 0.212 mm (8.4 mil) -
Page 17: Curvature
OPN-3002i DOC ID：SS13001 γ β Figure 7 : Pitch, Skew and Tilt 8.7. Curvature 0.33 mm 12-digit UPC : R ≧ 20 mm 0.15 mm 10-digit Codabar : R ≧ 16 mm <Conditions> Bar Code Sample : 0.33 mm UPC, 0.15 mm Codabar specified in Chapter 7.1... -
Page 18: Environmental Specifications
Power Supply Voltage : 3.7 V * Be sure that the direct light or specular reflection from the light source does not enter the light receiving section of the OPN-3002i. 9.4. Dust and Drip Proof IEC IP42 equivalent Protection against solid objects: Level 4 Protected against solid objects greater than 1.0 mm... -
Page 19: Vibration Strength(Without Packing)
OPN-3002i DOC ID：SS13001 9.5. Vibration Strength(without packing) There shall be no sign of malfunction after the following vibration test. Vibration test: Increase the frequency of the vibration from 10Hz to 100Hz at an accelerated velocity of 19.6m/s2 (2.0 G) for 30 minutes (60 minutes for a cycle) in the non-operating state. Repeat this in each X, Y and Z direction. -
Page 20: Regulatory Compliance
Wireless may void the user's authority to operate this equipment. RF Exposure The OPN-3002i unit (FCC ID: UFOOPN3002I) complies with FCC radiation exposure limits set forth for uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. The unit has very low level of RF... -
Page 21: Other
10.4. Other Bluetooth logo certification MFi License Program The OPN-3002i uses Bluetooth module which qualifies as radio equipment for low-power radio stations as specified in the Radio Law 38-24-1. Specified Radio Equipment： Low power data communications system in the 2.4GHz band in Article 2 paragraph 1 item (19), Ordinance of MPT. -
Page 22: Radio Low
It may have an effect on the communication speed or communication range of this data collector. ・ The use of OPN-3002i outside of the European Union, the United States and Canada is punishable under the law. - Page 23 OPN-3002i DOC ID：SS13001 license for such as manufacturing lines at factories, specific power-saving radio station requiring no license and amateur radio station are managed. 1. Please make sure that “other radio stations” are not managed in the frequency band 2.4 GHz before using this product.
-
Page 24: Product Label
OPN-3002i DOC ID：SS13001 14. Product Label The labels shown below are attached to the back side of the data collector. Figure 10: Product & Laser Caution Label... -
Page 25: Packaging Specifications
OPN-3002i DOC ID：SS13001 15. Packaging Specifications 15.1. Individual Packaging Specification Assembled package size: 125 x 112 x 40 (WDH mm) <TBD> Figure 11: Individual Packaging 15.2. Collective Packaging Specification Assembled package size: 595 x 520 x 245 (WDH mm), 100 pieces/box <TBD>... -
Page 26: Warranty
16. Warranty 16.1. Warranty period OPTOELECTRONICS Co., Ltd. warrants that this product is free of defects or malfunctions for a period of twelve (12) months from its shipment. In case of having defects or malfunctions caused by normal usage in accordance with this specification during the foregoing warranty period, OPTOELECTRONICS shall repair or adjust the product free of charge. -
Page 27: Mechanical Drawing
OPN-3002i DOC ID：SS13001 17.3. Mechanical Drawing Figure 13: Mechanical Drawing... -
Page 28: Supported Symbologies
OPN-3002i DOC ID：SS13001 18. Supported Symbologies The OPN-3002i is set to default settings by reading the following menu label regardless of the interface types. Default @MENU_OPTO@ZZ@SO@ZZ@OTPO_UNEM@ 18.1. 1D symbologies Minimum Code type Default Remarks length ○ UPC Add-on 2 UPC Add-on 5 EAN(JAN) ○... -
Page 29: Gs1 Databar, Composite Code
OPN-3002i DOC ID：SS13001 18.2. GS1 Databar, Composite Code Code type Default Remarks GS1 DataBar ・GS1 DataBar Omnidirectional ・GS1 DataBar Truncated ○ ・GS1 DataBar Stacked ・GS1 DataBar Stacked Omnidirectional GS1 conversion (setting required) GS1 DataBar Limited ○ GS1 DataBar Expanded ・GS1 DataBar Expanded ○...
