Instructions; Handling Vinyl Records; Playing Vinyl Records - SIGNIFY EA1394 Instruction Manual

Instructions

Handling Vinyl Records

NOTE: Only handle vinyl records with clean hands and hold them by the edge or the label. Do not
touch the record grooves.
1. Keep your vinyl records in protective sleeves when not in use to avoid dust and scratches.
2. Store vinyl records upright. Records stored horizontally may bend and warp.
• Avoid placing vinyl records in direct sunlight, close to any heat source (radiator, stoves etc.)
or in a location that may be subject to vibration, excessive dust, heat, cold or moisture.
• To clean a vinyl record, gently wipe the surface in a circular motion using a soft anti-static
cloth.

Playing Vinyl Records

To play a vinyl record, follow the steps below.
1. Turn the Power/Volume Dial (No. 1 on the Front and Rear Control Panels parts list) clockwise
until you hear a 'click' sound. The LED Power Indicator Light will illuminate red, indicating that the
Turntable with Legs is now turned on.
IMPORTANT: Before playing a vinyl record, turn down the volume of the Turntable with Legs to
avoid possible loud crackling noises. The crackling noises made by the stylus coming into contact
with the vinyl record could damage the unit. Wait until the stylus is completely placed on the vinyl
record, and then turn up the volume.
2. Set the Auto Stop Switch (No. 5 on the Turntable parts list) to the ON position. The unit will now
be set to automatically stop after the completion of play of the vinyl record. If the Auto Stop
Switch is set to the OFF position, the unit will not stop automatically.
3. Choose the desired playing speed using the Speed Selection Switch (No. 4 on the Turntable
parts list) between 33⅓, 45 and 78 RPM.
NOTE: When playing a 45 RPM record, use the included 45 RPM adaptor on the record spindle.
4. Carefully place the vinyl record on the turntable.
5. Unlock tone arm lock by moving it up and away from the tone arm itself.
6. Raise the tone arm using the arm raise lever or carefully with your hand.
7. Place the tone arm vertically over the first track of the record or over the outer edge of the vinyl
record. The turntable will start spinning.
IMPORTANT: If an auxiliary cable is connected to the unit, the turntable will not spin.
8. Lower the stylus onto the vinyl record.
AFTER SALES SUPPORT
1300 777 137
12
MODEL: EA1394 PRODUCT CODE: 63485 11/2018
