- Page 1 Retro Turntable Briefcase Model Number: EA1345 INSTRUCTION MANUAL AFTER SALES SUPPORT 1300 777 137...
-
Page 2: Welcome
Congratulations on choosing to buy a Signify product. All products brought to you by Signify are manufactured to the highest standards of performance and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty and customer technical support line. -
Page 3: Table Of Contents
Contents Welcome Warranty Details General Information and Safety Instructions Product Overview Getting Started Instructions Handling Vinyl Records Playing Vinyl Records Playing a USB Drive/Micro SD Card Playback Controls Using the Headphone Output Using the Auxiliary Input Using the RCA Audio Output Replacing the Stylus Frequently Asked Questions Repair and Refurbished Goods or Parts Notice... -
Page 4: Warranty Details
Retro Turntable Briefcase Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws. -
Page 5: General Information And Safety Instructions
General Information and Safety Instructions RETAIN FOR FUTURE USE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire; electric shock and injury when correctly adhered to. - Page 6 General Information and Safety Instructions (cont.) 16. Ensure that power sockets are not overloaded by operating several electrical products that exceed the power supply of the socket. Review the rating label of each electrical product being operated to ensure that they do not exceed the capacity of the power socket. Always turn off and unplug any electrical product that is not being used.
- Page 7 General Information and Safety Instructions (cont.) 30. We recommend that, where possible, to avoid moving the unit unnecessarily once placed. 31. For the protection of the Turntable Briefcase, we recommend that it is placed on a protected surface to prevent any damage. 32.
-
Page 8: Product Overview
Product Overview Front View 1. Lock Latch 2. Dust Cover 3. Turntable 4. Speakers 5. Handle 6. Control Panel (for USB drive/Micro SD card playback) service@unclebills.com.au AFTER SALES SUPPORT 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018... - Page 9 Product Overview (cont.) Turntable 1. Spindle 8. Power Indicator Light 2. 45 RPM Adaptor 9. Power/Volume Dial 3. Cue Lever 10. Auxiliary Input 4. Control Panel (for USB drive/Micro SD card 11. Stylus playback) 12. Tone Arm Lock 5. Speed Selection Switch (33, 45, 78 RPM) 13.
- Page 10 Product Overview (cont.) Front and Rear Control Panels 1. Micro SD Input 2. USB Input Button Button Button 6. RCA Audio Output 7. DC Power Input Included (not pictured): 1x Power Adaptor, 1x Instruction Manual and 1x Warranty Card. service@unclebills.com.au AFTER SALES SUPPORT 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018...
-
Page 11: Getting Started
Getting Started Before First Use Prior to using your Turntable Briefcase, please read all safety and operating instructions thoroughly. Please ensure you follow the steps below before using this device. We recommend you keep the original packaging for storing your Turntable Briefcase when not in use. Removing the Turntable Protective Packaging 1. -
Page 12: Instructions
Instructions Handling Vinyl Records NOTE: Only handle vinyl records with clean hands and hold them by the edge or the label. Do not touch the record grooves. • Keep your vinyl records in protective sleeves when not in use to avoid dust and scratches. •... -
Page 13: Playing A Usb Drive/Micro Sd Card
Instructions (cont.) 9. Turn the Power/Volume Dial clockwise to turn the volume up, or turn the Power/Volume Dial anticlockwise to turn the volume down. 10. To stop playing, lift the Tone Arm and place it back into the armrest. Secure the Tone Arm once more by engaging the Tone Arm Lock. -
Page 14: Using The Headphone Output
Instructions (cont.) Using the Headphone Output The Turntable Briefcase features a 3.5mm headphone output (No. 6 on the Turntable parts list). When headphones or external speakers with a 3.5mm pin are attached to the Turntable Briefcase via the headphone output, all sound will be diverted to the headphones or external speakers, and no sound will be played via the unit's inbuilt speakers. -
Page 15: Using The Rca Audio Output
Instructions (cont.) Using the RCA Audio Output The Turntable Briefcase features a RCA audio output located on the rear of the unit, which allows you to connect the unit to connect to external speakers. To use the RCA audio output, follow the steps below. -
Page 16: Replacing The Stylus
Instructions (cont.) Replacing the Stylus 1. Unlock Tone Arm Lock by moving it up and away from the Tone Arm itself. 2. Remove the protective cover from the stylus cartridge to expose the needle. 3. Separate the cartridge from the cartridge holder. 4. - Page 17 Instructions (cont.) 5. Carefully insert the audio-lines into the new cartridge. 6. Make sure the audio-lines are not touching each other. 7. Carefully slide the cartridge into the cartridge holder. 8. Gently clip the cartridge into the cartridge holder. AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018...
-
Page 18: Frequently Asked Questions
Frequently Asked Questions Q: Can I carry the Turntable Briefcase by the handle? A: Yes. But only when the dust cover is locked down using the latch. Never carry the Turntable Briefcase without the dust cover locked down. Q: Why is the Turntable Briefcase not powering on? A: Ensure that each end of the power adaptor has been correctly and securely connected, and the power socket has been switched on. -
Page 19: Repair And Refurbished Goods Or Parts Notice
Turntable Briefcase Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. -
Page 20: Other Useful Information
Other Useful Information Cleaning and Maintenance Before cleaning the Turntable Briefcase, ensure the unit is switched off and disconnected from the power source. The Turntable Briefcase is likely only to require regular “dusting” to keep it clean. Use a standard duster, or dry soft microfibre cloth to remove the dust from the unit. -
Page 21: Responsible Disposal
Other Useful Information (cont.) Responsible Disposal At the end of its working life, do not throw this appliance out with your household rubbish. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately. Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling. - Page 22 Notes service@unclebills.com.au AFTER SALES SUPPORT 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018...
- Page 23 Notes AFTER SALES SUPPORT service@unclebills.com.au 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018...
- Page 24 service@unclebills.com.au AFTER SALES SUPPORT 1300 777 137 MODEL: EA1345 PRODUCT CODE: 63818 12/2018...
