Microsensor MDM4901FL Operation Manual page 4

Power Supply: 15V~28VDC
Output: 2-wire 4mA~20mADC
3-wire 0/1V~5/10VDC，0mA~10/20mADC
Operation Temperature: -30℃~80℃（4-pin
Storage Temperature:-40℃~120℃ -20℃～85℃（Cable）
Response: ≤1ms
Insulation: 100MΩ， 50VDC
Housing Protection: IP65
3 Outline Construction and Installation
3.1 Construction and Mounting Dimension
G1/4 female
8
-20℃~70℃（cable material: PE, PVC）
-20℃~80℃ (cable material: PUR)
(50)
27
G1/4 female
32 8
58
Fig.1
Plug、M12×1
G1/4 female
8
Fig.2
Plug）
Unit:mm
27
G1/4 female
32 8
58
