- Page 1 HOLLISTON ACCENT CHAIR PRODUCT NO. 168-0145-8 ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888-670-6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
- Page 2 From on-trend furniture pieces to holiday décor and all your outdoor living essentials, CANVAS™ makes it easy to refresh your space to reflect your unique style and the way you live every day. We would love to hear from you and welcome your thoughtful feedback.
- Page 3 TABLE OF CONTENTS Parts List Before You Begin Assembly Step-by-step Guide Technical Data Troubleshooting Caring for Your Item Warranty WARNING! TO REDUCE THE RISK OF SERIOUS INJURY, READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE ASSEMBLING AND USING THE PRODUCT. • Please read and understand this entire manual before attempting to assemble, operate, or install the product.
- Page 4 PARTS LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Seat Cushion Backrest Left Side Frame Right Side Frame Front Stretcher Middle Stretcher Back Upper Stretcher Back Middle Stretcher HOLLISTON ACCENT CHAIR...
- Page 5 EXPLODED PARTS HOLLISTON ACCENT CHAIR...
- Page 6 HARDWARE LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Bolt 1/4” x 63 mm Bolt 1/4” x 38 mm Lock Washer Flat Washer Screw M4x50mm Tapping Bolt M6.5x65 mm Bolt 5/16” x 40 mm Hex Wrench Touch Up Pen EXTRA HARDWARE BAG HOLLISTON ACCENT CHAIR...
- Page 7 Place packing materials back in the box. Do not dispose of packaging materials until assembly is complete. READ EACH STEP CAREFULLY Make sure you understand each step. If you have any questions, contact CANVAS™ customer service at 1-888-660-6684 (toll-free). HOLLISTON ACCENT CHAIR...
- Page 8 STEP-BY-STEP GUIDE STEP 1 Align and attach the front stretcher ( to the left side frame by inserting two 1/4” x 63 bolts Secure the middle stretcher ( to the left side frame by inserting two 1/4” x 38 bolts Fasten the back stretchers ( to the left side frame with two 65mm tapping...
- Page 9 STEP-BY-STEP GUIDE STEP 2 Repeat the same procedure to attach the right side frame NOTE: Do not tighten bolts all the way until you have assembled the chair. Once assembly is complete, tighten each bolt. HOLLISTON ACCENT CHAIR...
- Page 10 STEP-BY-STEP GUIDE STEP 3 Pick up the seat cushion and pull back the bottom non-woven fabric. Align and attach the seat cushion onto the backrest by inserting four 5/16” x 40 bolts with the washers ( ). Make sure the cushion faces up after assembly. Replace the non-woven fabric onto the bottom side of the seat cushion by engaging the velcro strips.
- Page 11 STEP-BY-STEP GUIDE STEP 4 With the pre-attached wood dowels on the middle stretcher as a guide. Align and fit the assembled seat cushion onto the stretchers ( and fasten it in place with four 50mm screws HOLLISTON ACCENT CHAIR...
- Page 12 STEP-BY-STEP GUIDE STEP 5 Stand the assembled unit upright on a flat floor. Sit down on the chair with bolts not fully tightened. That will level all legs and then proceed to fully tighten all the bolts. The chair is now fully assembled. HOLLISTON ACCENT CHAIR...
- Page 13 TECHNICAL DATA 27.75 in (70.5 cm) 30.25 in (76.8 cm) 17.62 in (44.8 cm) SPECIFICATIONS ASSEMBLED DIMENSIONS (W x D x H) 28.875 x 27.75 x 30.25 in 73.4 x 70.5 x 76.8 cm ASSEMBLED WEIGHT 27.12 lb 12.3 kg MAXIMUM WEIGHT CAPACITY 300 lb 136 kg...
- Page 14 ASSEMBLY TROUBLESHOOTING HAVING TROUBLE? LET US HELP YOU! TOLL-FREE: 1-888-670-6684 BEFORE CALL US, If you have questions regarding your product or require RETURNING WE CAN HELP warranty assistance, please call our customer service helpline. PRODUCT TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTION The chair is shaky The hardware has loosened.
- Page 15 WARRANTY INFORMATION This CANVAS™ product carries a one (2) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
