FEATURES
• Heavy Duty 24"x18" Compacting Plate
• Swing-over Handle Allows Instant Operation on Both Sides
• 5400 Vibrations per Minute
• 4496 lbs Compaction Force
• Heavy Duty Frame Features a Central Lifting Point for Easy Loading/Unloading
• Powerful 212 cc 4 Stroke Engine
• Low Oil Automatic Shutoff
• 1 Gallon Fuel Tank Capacity
• Engine Meets EPA Emission Standards
Construction Zone
Plate Compactor
Item # 56035M
Owner's Manual
Manual del Propietario
Questions? Problems?
Please call our customer help line:
(888) 315-3080
M-F 8-5 CST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 56035M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wen 56035M

Summary of Contents for Wen 56035M

  • Page 1 Construction Zone Plate Compactor Item # 56035M Owner’s Manual Manual del Propietario Questions? Problems? Please call our customer help line: (888) 315-3080 M-F 8-5 CST FEATURES • Heavy Duty 24"x18" Compacting Plate • Swing-over Handle Allows Instant Operation on Both Sides •...

  • Page 2: Plate Compactor Identification

    PLATE COMPACTOR IDENTIFICATION (888) 315- For information and questions, please contact the Customer Service Help Line by calling 3080 . Certain information will be requested by the Customer Service Representative and to facilitate that, please fill in the information below. Refer to the illustration below for the location of Serial Number.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PLATE COMPACTOR IDENTIFICATION .................i SERVICE RECORD .........................i INTRODUCTION ..........................1 SAFETY INFORMATION......................2 GENERAL SAFETY PROCEDURES ...................3 IMPORTANT SAFETY INSTRUCTIONS ...................5 PLATE COMPACTOR COMPONENTS..................6 ASSEMBLY ............................7 PLATE COMPACTOR PREPARATION..................8 Using the Plate Compactor for the First Time................8 Step 1 - Fill Oil ...........................8 Step 2- Add Gasoline........................9 STARTING THE PLATE COMPACTOR..................11 SUBSEQUENT STARTING OF THE PLATE COMPACTOR ..........12...

  • Page 4: Introduction

    INTRODUCTION Thank You for Purchasing a WEN Construction Zone Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. Construction Zone reserves the right to change this product and specifications at any time without prior notice.

  • Page 5: Safety Information

    SAFETY INFORMATION Before operating this plate compactor read and observe all warnings, cautions, and instructions on this sheet, on the plate compactor, and in the Owner’s Manual. NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.

  • Page 6: General Safety Procedures

    GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the (888) 315-3080 M-F 8-5 CST product, please call before using the plate compactor. DANGER : CARBON MONOXIDE. Using an plate compactor indoors CAN KILL YOU IN MINUTES.
  • Page 7 WARNING : This plate compactor produces heat when running. Temperatures near exhaust can exceed 150º F (65º C). • Do not touch hot surfaces. Pay attention to warning labels on the plate compactor identifying hot parts of the machine. • Allow engine to cool down after use before touching engine or areas of the engine that become hot during use.

  • Page 8: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS – This manual contains important instructions for plate compactor product that should be followed during installation and maintenance of the plate compactor. • Plate compactors vibrate in normal use. Have damaged items repaired or replaced as necessary.

  • Page 9: Plate Compactor Components

    PLATE COMPACTOR COMPONENTS When unpacking, check to make sure all the parts shown on the parts list is included. (888) 315-3080 If there are any damaged or missing parts, please call M-F 8-5 CST for customer service Please familiarize yourself with the locations and functions of the various components and controls of your plate compactor.

  • Page 10: Assembly

    ASSEMBLY In order to best protect the plate compactor while in the package, this product comes with some components disassembled. Please complete the following assembly step before proceeding to use the plate compactor. If after reading this section, you are unsure about how to perform any of the steps, please call (888) 315-3080 M-F 8-5 CST for customer service.

  • Page 11: Plate Compactor Preparation

    PLATE COMPACTOR PREPARATION Using the plate compactor for the First Time The following section describes steps necessary to prepare the plate compactor for use. If after reading this section, you are unsure about how to perform any of the steps please call (888) 315-3080 M-F 8-5 CST for customer service.

  • Page 12: Step 2- Add Gasoline

    Figure 3- Unscrewing the oil cap Figure 4- filling oil Step 2- Add Gasoline WARNING: This plate compactor may emit highly flammable and explosive gasoline vapors, which can cause severe burns or even death if ignited. A nearby open flame can lead to explosion even if not directly in contact with gasoline.
  • Page 13 • Avoid letting dirt or water into the fuel tank. • Gasoline can age in the tank and make it hard to start up the plate compactor in the future. Never store plate compactor for extended periods of time with fuel in the tank. Model number 56035 Fuel tank...

  • Page 14: Starting The Plate Compactor

    STARTING THE PLATE COMPACTOR Before starting the plate compactor, make sure you have read and performed the steps in the “Plate compactor Preparation” section of this manual. If you are unsure about how to (888) 315-3080 M-F 8-5 CST perform any of the steps in this manual please call customer service.

  • Page 15: Subsequent Starting Of The Plate Compactor

    SUBSEQUENT STARTING OF THE PLATE COMPACTOR If this is not the first time using the plate compactor, user should take the following steps to prepare it for operation. IMPORTANT: At this point the user should be familiar with the procedures described in the section titled “Using the Plate compactor for the First Time.”...

  • Page 16: Using The Plate Compactor

    USING THE PLATE COMPACTOR This plate compactor is designed for compacting loose, granular soils, gravel, and paving stones. It is intended to be used in confined areas and areas next to structures such as walls, curbs, and foundations. This plate compactor is not recommended for compacting cohesive soils with heavy clay content. Run the engine at full throttle and allow the plate to pull itself along at its normal speed.

  • Page 17: Stopping The Plate Compactor

    STOPPING THE PLATE COMPACTOR To stop the plate compactor: 1. Move handle lever to MIN position to disengage the compactor. 2. Turn the engine switch to the “OFF” position. 3. Turn the fuel valve to the “OFF” position. WARNING: Allow the engine to cool for several minutes before touching areas that become hot during use.

  • Page 18: Maintenance / Care

    MAINTENANCE / CARE Proper routine maintenance of your plate compactor will help prolong the life of your machine. Please perform maintenance checks and operations according the schedule in figure 6. If you have questions about any of the maintenance procedures listed in this manual, please call (888) 315-3080 M-F 8-5 CST.

  • Page 19: Changing/ Adding Oil

    Figure 7- Checking the oil Changing/ Adding Oil Change the oil according to the maintenance schedule in figure 6. Change the oil when the engine is warm. This will allow for complete drainage. Change oil more often if operating under heavy load or high ambient temperatures.

  • Page 20: Air Cleaner Maintenance

    Air Cleaner Maintenance Routine maintenance of the air cleaner helps maintain proper air flow to the carburetor. Check that the air cleaner is free of excessive dirt. 1. Remove air cleaner cover (a). Remove both elements and inspect them for holes or tears. Replace damaged elements.

  • Page 21: Spark Plug Maintenance

    Spark Plug Maintenance The spark plug is important for proper engine operation. A good spark plug should be intact, free of deposits, and properly gapped. To inspect the spark plug: 1. Pull on the spark plug cap to remove it. 2.

  • Page 22: Storage / Transport Procedures

    STORAGE / TRANSPORT PROCEDURES CAUTION: Never place any type of storage cover on the plate compactor while it is still hot. If the plate compactor is being stored for short periods of time (30 – 60 days), add stabilized fuel to the fuel tank until full.

  • Page 23: Specifications

    SPECIFICATIONS Plate compactor Compacting Plate Size 24"x 18" Vibrations per Minute 5400 Compaction Force 4496 lbs Forward Travel Up to 82 Feet per Minute Weight 240 lbs Engine 4-stroke OHV single cylinder with forced air Engine type cooling system Ignition system non-contact transistor Displacement 212 cc...

  • Page 24: Troubleshooting

    TROUBLESHOOTING IMPORTANT: If trouble persists please call our customer help line at (888) 315-3080 M-F 8-5 Central Time. Problem Cause Solution Engine will not Engine switch is set start to "OFF". Set engine switch to "ON". Fuel valve is turned to "OFF".

  • Page 25: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST...
  • Page 26 EXPLODED VIEW AND PARTS LIST No. Part Number Description Specification Qty. 56035-045 Engine 56035-047 5*40 56035-020 Pulley 56035-019 Washer M8×30×6 56035-018 Spring Washer Ø 8 56035-017 Hex Bolt M8*30 56035-005-3 Washer Ø 10 56035-048 Handle Fixed Plate 56035-049 Handle Rubber Damper 56035-050 Locked Nut 56035-005...
  • Page 27 ENGINE EXPLODED VIEW AND PARTS LIST...
  • Page 28 ITEM STOCK# DESCRIPTION ITEM STOCK# DESCRIPTION 56035-E-001 CYLINDER HEAD GASKET 56035-E-051 ADJUSTING NUT 56035-E-002 CYLINDER HEAD COVER 56035-E-052 VALVE LOCK NUT 56035-E-003 HEAD COVER GASKET 56035-E-053 VALVE SPRING 56035-E-004 BREATHER TUBE 56035-E-054 RECOIL STARTER ASSY 56035-E-005 BOLT 56035-E-055 BOLT 56035-E-006 STUD 56035-E-056 REEL END CAP...
  • Page 29 EXPLODED VIEW AND PARTS LIST Part Number Description Specification Quantity 56035-G-001 Eccentric block 56035-G-002 Oil Seal 28×50×10 56035-G-003 Bearing Cover 56035-G-004 Bearing 6306 56035-G-005 Bearing Seat 56035-G-006 6×6×20 56035-G-007 Main shaft 56035-G-008 Inner Hexagon bolt M6×16 56035-G-009 Spring Gasket Ø6 56035-G-010 Clip Ø24...
  • Page 30 NOTES:...

  • Page 31: Warranty Statement

    WEN® will repair or replace, at its discretion, any part that is proven to be defective in materials or workmanship under normal use during the one (1) year warranty period. Warranty repairs or replacements will be made without charge for parts or labor.
