Installation Guide
Barometric Relief Hood
Used with Medium Foundation Light
Commercial Rooftops
M M o o d d e e l l # # : : BAYBARO310A
U U s s e e d d w w i i t t h h : : EBC 090-150, GBC 090-150
Only qualified personnel should install and service the equipment. The installation, starting up,
and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and
requires specific knowledge and training. Improperly installed, adjusted or altered equipment
by an unqualified person could result in death or serious injury. When working on the
equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
May 2021
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
R R T T - - S S V V N N 0 0 3 3 8 8 A A - - E E N N

Advertisement

Table of Contents
loading

Related Manuals for Trane BAYBARO310A

Summary of Contents for Trane BAYBARO310A

  • Page 1 Used with Medium Foundation Light Commercial Rooftops M M o o d d e e l l # # : : BAYBARO310A U U s s e e d d w w i i t t h h : : EBC 090-150, GBC 090-150 S S A A F F E E T T Y Y W W A A R R N N I I N N G G Only qualified personnel should install and service the equipment.

  • Page 2: Warnings, Cautions, And Notices

    Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all refrigerants containing these compounds have the same potential impact to the environment. Trane advocates the responsible handling of all refrigerants-including industry replacements for CFCs and HCFCs such as saturated or unsaturated HFCs and HCFCs.
  • Page 3 W W A A R R N N I I N N G G P P r r o o p p e e r r F F i i e e l l d d W W i i r r i i n n g g a a n n d d G G r r o o u u n n d d i i n n g g R R e e q q u u i i r r e e d d ! ! Failure to follow code could result in death or serious injury.
  • Page 4 Non-Trane personnel should always follow local regulations. Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.

  • Page 5: Pre-Installation

    Pre-Installation Unit Inspection To protect against loss due to damage incurred in transit, perform inspection immediately upon receipt of the unit. Exterior Inspection If the job site inspection reveals damage or material shortages, file a claim with the carrier immediately. Specify the type and extent of the damage on the bill of lading before signing.

  • Page 6: General Information

    P P r r e e - - I I n n s s t t a a l l l l a a t t i i o o n n General Information The barometric relief hood is sized to provide up to 100% relief. It is designed to meet low leak requirements to prevent infiltration of air when closed.

  • Page 7: Installation

    Figure 1. 5. Close the unit disconnect switch. Figure 1. BAYBAR0310 installation view FIELD SUPPLED AND INSTALLED DUCT WORK. 28.500 DUCT MOUNT RELIEF HOOD CUT IN DUCT, BAYBARO310A 27.750 NO LARGER THAN 27.75" WIDE x 28.5" TALL RT-SVN038A-EN...
  • Page 8 For more information, please visit trane. com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
