MODEL #
CM7952CK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PT)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7952CK
Summary of Contents for Furniture of America CM7952CK
- Page 1 MODEL # CM7952CK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PT) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 2 / 9...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X 9...
- Page 5 CM7952CK #1 1pc #2 2pcs #3 4pcs #4 2pcs Slat Headboard Footboard Siderail #5 8pcs (Ø1/4") Slat support leg 167x30x30mm #A 8pcs #B 8pcs #C 8pcs Half Moon Ø5/16" Bolt Ø5/16" x 3" Hex Nut Ø5/16" #F 8pcs #D 1pc...
- Page 6 Carton Disignation Part Hardware #A x8pcs #B x8pcs #C x8pcs #D x1pc #E x8pcs #F x8pcs...
-
Page 7: Exploded View
Exploded View 7 / 9... - Page 8 ASSEMBLY INSTRUCTIONS Attach threaded bolts (#A) to the headboard (#1) and footboard (#2), then align side rails (#4) to the Part #1 x1pc headboard (#1) and footboard (#2). Secure by using hex nuts (#B) with Part #2 x1pcs washers (#E,C). Part #4 x2pcs Hardware #A x8 pcs Hardware #B x8 pcs...
- Page 9 ASSEMBLY INSTRUCTIONS Align slats (#3) to the side rails (#4), then secure by using screws Hardware #E x8 pcs (#E). 9 / 9...
