MODEL #
CM7184CK
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7184CK
Summary of Contents for Furniture of America CM7184CK
- Page 1 MODEL # CM7184CK Questions? GIVE US A CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X 1 0...
- Page 5 CM7184CK #1 1pc #2 1pc #3 2pcs Headboard Headboard Leg(L&R) H/B Support Rail #4 1pc #5 2pcs #6 4pcs Footboard HB Legs Finial #7 4pcs #8 8pcs #9 2pcs Slat support leg Slat Side rail 30x30x195mm #C 8pcs #A 8pcs #B 8pcs Lock Washer Ø5/16"...
-
Page 6: Exploded View
Exploded View 6 / 10... - Page 7 CM7184CK is packed in 3 cases Carton Disignation Part Hardware #A x 8pcs Headboard #B x 8pcs H/B Support #C x 8pcs Rail CM7184CK-HB #D x 1pc HB Leg(L&R) (2pcs) (2pcs) Finial Footboard #E x 8pcs Legs (2pcs) CM7184CK-FB (2pcs)
- Page 8 ASSEMBLY INSTRUCTIONS Align the HB legs (#3R/L) to the Part #1 x1pc headboard (#1) and HB support Part #2 x1pc (#2), then secure by using bolts Part #3 x2pcs (#A) with washers (#B,C). Attach Part #6 x2pcs finials (#6) to the headboard (#1). Hardware #A x 8pcs Hardware #B x 8pcs Hardware #C x 8pcs...
- Page 9 ASSEMBLY INSTRUCTIONS Align and latch the side rails (#9) to the grooves of the headboard (#1) and Part #9 x2pcs footboard (#4). Align and attach support legs (#8) to the slats (#7). Part #7 x1pc Part #8 x2pcs Leveler 9 / 10...
- Page 10 ASSEMBLY INSTRUCTIONS Align slats (#7) to the side rails (#9), then secure by using screws (#E). Hardware #E x8pcs 10 / 10...
