ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7185CK-1/2/3/4/5
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 18-03-16
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7185CK-1
Summary of Contents for Furniture of America CM7185CK-1
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7185CK-1/2/3/4/5 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 10pcs #1 x 1pc Headboard Panel Bolt Ø5/16"x1-3/8" #2 x 2pcs #B x 10pcs Headboard Post (L/R) Spring Washer Ø5/16"...
- Page 4 Exploded View Align headboard (#1) to the holes of the headboard posts (#2R/L), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Page 4 of 6...
- Page 5 #A x 4pcs #B x 4pcs #C x 4pcs Align footboard (#3) to the holes of the footboard posts (#4R/L), then secure by using bolts (#A) with washers (#B,C). Align and hook the side rails (#5) to the grooves of the headboard (#1) and footboard (#3).
- Page 6 Attach support legs (#7) to the holes of the slats (#6), then adjust the leveler on the bottom of the support legs (#7) according to ground level. Align slats (#6) to the side rails (#5), then secure by using screws (#E). #E x 8pcs Page 6 of 6...
