- Page 1 I N S T R U CT I O N M A N UA L HF Series Compressed Air Filters Models HF(grade)-12 through HF(grade)-48 F O R M N O . : 4 0 1 1 2 0 3 R E V I S I O N : 1 0 / 2 0 1 5 R E A D A N D U N D E R S TA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT.
-
Page 2: Table Of Contents
General Safety Information 1. Pressurized devices • Do not exceed maximum operating pressure indicated on serial number tag. • Make certain filter is fully depressurized before servicing. 2. Breathing Air • Air treated by this equipment may not be suit- able for breathing without further purification. -
Page 3: Model Number Configuration
Model Number Configuration (1) Filter Grade (2) Housing (3) Connection Sizes (4) Features 11 - Mechanical Separator Number Capacity D = Internal Automatic Drain Mechanism scfm [m hr] @ 9 - Separator/Filter P = Differential Pressure Slide 100 psig [7 kgf/cm 7 - Air Line Filter Indicator 20 [35]... -
Page 4: Installation
1.0 Installation A. Where Used/Air Quality After Filtration Solid particle Liquid removal Maximum inlet Remaining Grade Where used removal (maximum efficiency (at liquid loading oil content size in microns) rated conditions) ppm w/w ppm w/w Separator - downstream of an aftercooler —... - Page 5 B. Mounting C. Piping 1. Wall mounting brackets - Mount bracket to filter 1. Before installing, blow out pipe line to remove scale head: and other foreign matter. (1) remove four (4) screws holding black plastic top 2. This unit has DRYSEAL pipe threads; use pipe com- cap to filter head pound or tape sparingly to male threads only.
- Page 6 b. Threaded heads D. Drain provisions Use four carriage bolts, nuts and o-ring (sold as 1. Internal Automatic Drains - Drain line kit). Remove black plastic top caps, apply gen- The bottom of internal automatic drains are pro- er ous amount of lubricant to o-ring, install o-ring vided with 1/8"...
-
Page 7: Operation
2.0 Operation Grades 11,9,7,5,3 Check to see that filter is installed level to insure Do not operate filter at pressures in proper drainage. excess of Maximum Working Pressure indicated on Check that manual drains are drained periodically or Serial Number Tag. that automatic drains are functioning. -
Page 8: Maintenance
C. Flow Capacity 3.0 Maintenance Maximum air flow for the various filters at 100 psig A. When to Replace Filter Element (7 kgf/cm ) is indicated in Table 1. To determine maximum air flows at inlet pressures other than 100 psig (7 kgf/cm NOTE: Grades 7,6,5,3,1 - complete element is replaced;... - Page 9 Remove bowl After making certain that o-ring inside top of bowl (and on bayonet mount heads, wave spring) are in a. For models 12 through 28 - bayonet mount - place, reassemble bowl to head. push bowl up, turn bowl 1/8th turn to your left, and pull bowl straight down NOTE: Make certain o-ring is generously lubricated.
-
Page 10: Dimensions And Weights
Dimensions and Weights... -
Page 11: Warranty
WARRANTY he manufacturer warrants the product manufactured by it, when properly installed, operated, applied, and main- tained in accordance with procedures and recommendations outlined in manufacturer’s instruction manuals, to be free from defects in material and workmanship for a period of one (1) year from date shipment to the buyer by the manufacturer or manufacturer’s authorized distributor provided such defect is discovered and brought to the manu- facturer’s attention within the aforesaid warranty period. - Page 12 4647 S.W. 40th Avenue Ocala, Florida 34474-5788 U.S.A. P: (724) 745-1555 F: (724) 745-6040 E: hankison.americas@spxflow.com www.spxflow.com/hankison Improvements and research are continuous at SPX FLOW, Inc. Specifications may change without notice. ISSUED 10/2015 Form No.: 4011203 Revision: D COPYRIGHT ©2015 SPX FLOW, Inc.
