Summary of Contents for Aurora FOLIO

  • Page 1 FOLIO Please retain these instructions in a safe place for further reference. Leggere il manuale d'uso. Conservare con cura le istruzioni per ogni futura consultazione.
  • Page 2 220mm min. 50cm Min. 15cm :6mm / L:35mm 4 mm 15cm 15cm min. 60cm...
  • Page 4 ENGLISH INSTALLATION AND OPERATING MANUAL Before operating the heater, please read these instructions thoroughly to avoid damage and hazardous situations. Any use of this heater other than that stipulated in this instruction manual may cause fire, electric shock or injury, and voids all warranties. Warranty does not apply to any defect, deterioration, loss, injury or damage caused by, or as a result of, the misuse or abuse of this heater.
  • Page 5 CAUTION — Some parts of this product can become very ❑ hot and cause burns. Particular attention has to be given where children and vulnerable people are present. Make sure that your supply rating corresponds to what ❑ specified on the rating plate: 230V~, 50Hz. This heater is water resistant to IPX4.
  • Page 6 2. Wall mounting ❑ Only fix the heater in vertical position with the air outlet grid downward; ❑ This heater is fitted with a double electrical insulation circuit (class II) and therefore does not require an earth connection. ❑ It must never be possible for people in the bath tub or shower to reach the adjustment knobs. ❑...
  • Page 7 temperature will be. The highest position of the thermostat corresponds to approximately 35°C, the bottom one (*) to about 5°C. To adjust the thermostat, see the USING THE THERMOSTAT section above. Rapid heating Adjust the ambient thermostat to the required temperature and then turn the timer knob to select the required operating time.
  • Page 8 ITALIANO MANUALE DI INSTALLAZIONE E D’USO Si prega di leggere attentamente queste istruzioni, prima di utilizzare il prodotto, in modo da evitare danneggiamenti o comunque il verificarsi di situazioni di pericolo. Qualsiasi utilizzo del prodotto diverso da quanto indicato nel presente manuale può causare incendi, pericoli elettrici o ferite e rende nulla qualsiasi garanzia.
  • Page 9 ATTENZIONE: Alcune parti di questo prodotto possono ❑ diventare molto calde e causare bruciature. Particolare attenzione deve essere prestata in presenza di bambini o persone vulnerabili. Assicuratevi che l’alimentazione di rete corrisponda ai dati di ❑ targa: 230V~, 50Hz. Questo termoventilatore ha un gradi di protezione IPX4 e può ❑...
  • Page 10 di personale specializzato al fine di evitare qualunque rischio di danneggiamento. Il termoventilatore deve essere posizionato in modo tale che ❑ la presa di alimentazione sia sempre raggiungibile. Non installate il prodotto su pareti di materiale sintetico. ❑ 2. Montaggio a muro ❑...
  • Page 11 Iniziando dalla posizione antigelo, contrassegnata dal simbolo “”, ruotate la manopola del termostato in senso orario fino a quando non si sente un “click”: il prodotto inizia così a funzionare a 1000W di potenza ed il segnalatore luminoso si illumina. Il termostato mantiene la temperatura ambiente desiderata accendendo e spegnendo automaticamente il termoventilatore.
  • Page 12 ISFOL001_R0...
