Heater Trolly
1
Safety advises
2
Device description
3
Function description
4
Mounting informations
5
Usage
6
Technical data
7
Electrical connection
8
Maintenance
9
Spare parts
10
Optional accessories
11
Fault diagnosis
author: 29.01.1999 KH
date/name
a) 8268 23.07.02 KH d) 9708 28.06.04 KH
b) 9193 09.01.04 KH e) 10132 01.12.04 KH
c)
9641 02.06.04 KH f) 10199 11.01.05 KH
status: 14.07.05
Technical Information
A U R O R A
Konrad G. Schulz GmbH & Co.KG
Südring 4
D-69427 Mudau
Tel.: 0 62 84 / 92 02-0
Fax: 0 62 84 / 92 02 99
info@aurora-eos.com
www.aurora-eos.com
Technical modifications reserved
checked: 20.07.05 W.Le
date/name
no.
912-100-0108
released: 20.07.05 W.Le
date/name
g) 10682 14.07.05 KH
h
i
page
1/11
j
k
l
Advertisement
Related Manuals for Aurora 151-701-0000
Summary of Contents for Aurora 151-701-0000
-
Page 1: Technical Information
A U R O R A Konrad G. Schulz GmbH & Co.KG Südring 4 D-69427 Mudau Tel.: 0 62 84 / 92 02-0 Fax: 0 62 84 / 92 02 99 info@aurora-eos.com www.aurora-eos.com Technical modifications reserved author: 29.01.1999 KH checked: 20.07.05 W.Le released: 20.07.05 W.Le... - Page 2 Be careful by touching them. This also applies to the resistance on the blower when working at the opened unit and the construction part has not completely cooled down. 2 Device description This technical information is valid for the following versions: AURORA- nominal blower air outlet part no.
- Page 3 You can choose between 1-,2-,and 3-speed level blower versions. The blower will be operated with a switch, e.g. the AURORA Control-Panel, deliverable as an option. Example for a version with three speed level:...
- Page 4 Please pay attention to the actual technical supplement to the general terms of sale and the safety instructions in contact & Info of www.aurora-eos.com. Take care of the mounting position of the Trolly. The axis of the blower motor must be in a horizontal position.
- Page 5 Cooling water circuit: When refilling the cooling water quality has to be considered. When using AURORA water valves the warranty expires when defects occur due to contamination in the water circuit. (see TI 971-190-0003 anticorrosion/antifreeze solution. Please order in the case of need)
- Page 6 page Technical Information 912-100-0108 6/11 spare parts list for Trolly 151-701-0002 description part no. heat exchanger ∅15 mm 283-701-0001 twin radial blower DRG 370 131-101-0061 cable set 2-speed 217-100-0008 resistor 413-300-0001 spare parts list for Trolly 151-701-0004 description part no. heat exchanger ∅15 mm 283-701-0002 twin radial blower DRG 370...
- Page 7 page Technical Information 912-100-0108 7/11 spare parts list for Trolly 151-701-0007 and 151-702-0007 description part no. part no. heat exchanger ∅15 mm 283-701-0001 283-701-0001 twin radial blower DRG 370 131-101-0061 131-102-0061 resistor 413-300-0001 413-300-0002 cable set 2-speed 217-700-0008 217-700-0006 socket ∅42 mm 431-420-0012 431-420-0012 spreading rivet...
- Page 8 page Technical Information 912-100-0108 8/11 spare parts list for Trolly 151-701-0019 description part no. part no. heat exchanger ∅15 mm 283-701-0001 283-701-0001 twin radial blower DRG 370 131-101-0068 131-102-0068 resistor 413-300-0001 413-300-0002 cable set 3-speed 217-100-0007 217-100-0007 socket ∅55 40 long 431-420-0014 431-420-0014 spreading rivet...
- Page 9 page Technical Information 912-100-0108 9/11 11 Fault diagnosis Fault Cause Remedy Blowers will not work Fuse defective or loose Is the fuse correctly seated? If necessary insert correctly. Renew defective fuses. If a new defect occurs within a short time this indicates a possible short-circuit.
- Page 10 page Technical Information 912-100-0108 10/11 Fault Cause Remedy Blowers will not Micro-temperature Exchange resistor and check the operate at all speeds fusing (MTS) has blower motor for the cause of been triggered functional faults Free up intake/outlet openings and exchange resistor Blower switch Exchange blower switch defective...
- Page 11 page Technical Information 912-100-0108 11/11 Fault Cause Remedy Heating will not Vehicle engine is not Start engine function running Cooling water still Wait until the engine reaches operating cold temperature Water valve closed Open valve Water lines kinked or Eliminate fault by installing correctly. squashed Water pump pressure Heat exchanger does not have cooling...
