  • Page 1 Busbar system unibar H 800 A to 4000 A System manual...

  • Page 2: Table Of Contents

    Table of contents Table of contents About this manual Warranty and Liability Copyright Revision index Why a busbar system? Construction and characteristics Characteristics of the busbar system System components: Overview Busbar elements: Design 3.3.1 Double body system (from 2500 A) 3.3.2 Dimensions according to rated current Busbar elements: Features...
  • Page 3 Table of contents Drill holes for connecting flanges 4.6.1 Standard type 4.6.2 Other types Cable feeder 4.7.1 Cable end feeder 4.7.2 Cable intermediate feeder Tap-off units 4.8.1 Type key for tap-off units 4.8.2 Tap-off units for plug-in 4.8.3 Tap-off units for connection joints Accessories 4.9.1 End flange...
  • Page 4 Table of contents 7.3.8 Fitting tap-off units to plug-in (125 - 630 A) 7.3.9 Fitting tap-off units to connection joints (250 - 1250 A) Operation, maintenance and enlargement 7.4.1 Maintenance 7.4.2 Enlargement Comments for specifications for tenders Formula characters and abbreviations in accordance with EN 61439-1/-6 10 Glossary 11 Index...

  • Page 5: About This Manual

    H busbar trunking systems. Warranty and Liability These instructions do not extend the Sales and Delivery Conditions of Hager. No new claims concerning the warranty and guarantee, which extend beyond the Sales and Delivery Conditions, can be derived from this manual.

  • Page 6: Why A Busbar System

    Energy distribution must not only be flexible and low priced, but also space-saving, safe and with a long service life. unibar H busbar systems from Hager are just that: efficient and reliable. With this system energy can be transported and distributed precisely: from the transformer to the low voltage switchgear and through the entire building.
  • Page 7 Why a busbar system? Flexible We comply with the customer’s specifications when creating the routing plan for the busbar system. The route is adapted to local circumstances and can be modified at any time. Modifications and expansions with unibar components are possible at any time after the installation of the busbar trunking system.

  • Page 8: Construction And Characteristics

    Construction and characteristics Construction and characteristics Characteristics of the busbar system Compliance with the IEC 61439-1 and 61439-6 international standards, as well as all European and national standards derived from them; CE-marking. Voltages up to 1000 V, frequency 50/60 Hz Protection type IP55 / IP65 or IP68 (cast resin system, only for energy transport), also feasible combined within one busbar run The inner conductor of the busbar elements is made either from a tinned...

  • Page 9: System Components: Overview

    Construction and characteristics System components: Overview Terminal connection Straight length, with or without plug-in Bracket, vertical (knee) Bracket, horizontal T-pieces (T-boxes) Double bracket, vertical / Z-knee (Z-box) Tap-off unit (symbolic representation) for plug-in (125 - 630 A, can be plugged in when voltage is applied on busbar run) for connection j oints (250 - 1250 A) Fastening material (symbolic representation)
  • Page 10 Construction and characteristics Technical changes reserved...

  • Page 11: Busbar Elements: Design

    Construction and characteristics Busbar elements: Design For standard applications with 4 inner bars: the neutral conductor N has the same cross-section as L1/L2/L3. The protective earth PE corresponds to the housing. If a larger cross-section is demanded for the PE, an additional inner bar (PE2) is inserted.

  • Page 12: Double Body System (From 2500 A)

    Construction and characteristics 3.3.1 Double body system (from 2500 A) Busbar elements with high rated currents I for 2500 A / 3200 A / 4000 A consist of two parallel conductor bundles (Double body system, doubled conductor system) In this case the conductors are installed together in two packs in one housing.

  • Page 13: Busbar Elements: Features

    Construction and characteristics Busbar elements: Features 4-pole (N, L1, L2, L3) and 5-pole (N, L1, L2, L3, PE2) available, each with PE housing Neutral conductor has same cross-section as the phases (L1, L2, L3 conductors) System elements available as single conductor or double conductor (double body system) according to rated current Protection type for standard housing: IP55 Phases labelled at both ends of the busbar element...
  • Page 14 Construction and characteristics Single bolt clamp(s) The joint block is fitted with single bolt clamp(s) to clamp and connect the conductors of adjacent busbar elements. The joint block is provided with 1, 2, or 4 bolt clamps, depending on the rated current and number of internal conductors in the busbars.

  • Page 15: Straight Length Busbar Elements

    Construction and characteristics Connection joints for protection type IP68 Connection joints in busbar elements with protection type IP68 (cast resin system) are formed with essentially the similar joint block as for protection type IP55. The torque for the clamping block in the connection joints for adjacent busbar elements is approx.

  • Page 16: Feeder Units

    Standardized feed options for transformers, terminals and cable feeder are available Terminal elements for different rated current, direction and conductor configurations Type-tested terminal elements to Hager unimes H energy distribution system (connection up to 4000 A) Connection of unibar H to unimes H Cable intermediate feeder Cable intermediate feeder for connection joint between two adjacent straight busbar elements.

  • Page 17: Tap-Off Units For Plug-In (125 - 630 A)

    Construction and characteristics Tap-off units for plug-in (125 - 630 A) Tap-off units for plug-in are available for straight busbar elements with plug-in in protection type IP55. They can be used on straight busbar elements with plug-in of any rated current. Tap-off units for plug-in with currents up to 630 A can be installed while operating (without disconnecting the busbar run).

  • Page 18: Tap-Off Units For Connection Joints (250 - 1250 A)

    Construction and characteristics Tap-off units with fused switch disconnector, or MCCB Tap-off units for plug-in are equipped with circuit breakers (MCCB) or HRC fused switch disconnector. Empty tap-off units for self configuration are also available. Tap-off units with HRC fused switch disconnectors are available for the following fuses (delivery always without fuses): HRC fuse Rated current of tap-off unit...
  • Page 19 Construction and characteristics Notices Technical changes reserved...

  • Page 20: Product Selection

    Type key for busbar elements Examples: 4 bars, straight length, 800 A, 2 m, aluminium conductors, IP55, RAL7035: KEH33S80LMA 4 bars, straight length, 1600 A, 2 m, aluminium conductors, IP55, RAL7035: KEH36S80LMA For further types please ask your hager partner. Technical changes reserved...
  • Page 21 Product selection Tab. 2 Element type Tab. 1 Rated current Element type Ref. No. Code Straight length up to 3m Straight length up to 2m Straight length up to 1m 1000 Straight length with plug-in* 1250 Straight length with plug-in* 1600 Horizontal elbow, N inside 424004...

  • Page 22: Straight Busbar Elements

    Product selection Straight busbar elements 4.2.1 Straight busbar elements without plug-in Straight busbar elements without plug-in in standard lengths (conductor material: aluminium) Rated current I Order number 1 m Order number 2 m Order number 3 m KEH33S81Z1LMA KEH33S80Z2LMA KEH33S00Z3LMA 800 A KEH34S81Z1LMA KEH34S80Z2LMA...
  • Page 23 Product selection Straight busbar elements without plug-in in selectable lengths (conductor material: aluminium) Rated current I Order number Order number Order number 760 mm to 1 m 1.76 m to 2 m 2.51 m to 3 m KEH33S81S1LMA KEH33S80S2LMA KEH33S00S3LMA 800 A KEH34S81S1LMA KEH34S80S2LMA...

  • Page 24: Straight Busbar Elements With Plug-In

    Product selection 4.2.2 Straight busbar elements with plug-in Straight lengths with plug-in, length 3 m (conductor material: aluminium) Rated current I Order number 3 m KEH33S09Z3LMA 800 A KEH34S09Z3LMA 1000 A KEH35S09Z3LMA 1250 A KEH36S99Z3LMA 1600 A KEH37S99Z3LMA 2000 A KEH31D99Z3LMA 2500 A KEH32D99Z3LMA...

  • Page 25: Fire Barrier

    Product selection 4.2.3 Fire Barrier Fire Barrier (conductor material: aluminium) Rated current I Order number Dimensions in mm Length Width Height 800 A KEH33S19 1000 A KEH34S19 1250 A KEH35S19 1600 A KEH36S19 2000 A KEH37S19 2500 A KEH31D19 3200 A KEH32D19 4000 A KEH33D19...

  • Page 26: Expansion Compensation Unit

    Product selection 4.2.4 Expansion compensation unit The materials within any busbar runs are frequently subjected to temperature changes. This leads to differing temperature behaviours and hence to differing expansions. This expansion must be compensated for long straight busbar runs and if a busbar run is crossing an expansion joint between two parts of a building.

  • Page 27: Change Directions

    Product selection Change Directions 4.3.1 Elbow, horizontal Elbow, horizontal (conductor material: aluminium) Rated current I Order number* KEH33S01N1LMA 800 A KEH34S01N1LMA 1000 A KEH35S01N1LMA 1250 A KEH36S01N1LMA 1600 A KEH37S01N1LMA 2000 A KEH31D01N1LMA 2500 A KEH32D01N1LMA 3200 A KEH33D01N1LMA 4000 A *Order numbers for Ref.

  • Page 28: Knee, Vertical

    Product selection 4.3.2 Knee, vertical Knee, vertical (conductor material: aluminium) Rated current I Order number KEH33S02N1LMA 800 A KEH34S02N1LMA 1000 A KEH35S02N1LMA 1250 A KEH36S02N1LMA 1600 A KEH37S02N1LMA 2000 A KEH31D02N2LMA 2500 A KEH32D02N2LMA 3200 A KEH33D02Z2LMA 4000 A Rated current I Dimensions in mm (A = B) 800 A...

  • Page 29: Double Horizontal Change Direction (Z-Element)

    Product selection 4.3.3 Double horizontal change direction (Z-element) Double horizontal elbow (Z-element, conductor material: aluminium) Rated current I Order number KEH33S21N1LMA 800 A KEH34S21N1LMA 1000 A KEH35S21N1LMA 1250 A KEH36S21N1LMA 1600 A KEH37S21N1LMA 2000 A KEH31D21N1LMA 2500 A KEH32D21N1LMA 3200 A KEH33D21N1LMA 4000 A Dimensions in mm...

  • Page 30: Double Vertical Change Direction (Z-Element)

    Product selection 4.3.4 Double vertical change direction (Z-element) Double vertical knee (Z-element, conductor material: aluminium) Rated current I Order number* KEH33S22N1LMA 800 A KEH34S22N1LMA 1000 A KEH35S22N1LMA 1250 A KEH36S22N1LMA 1600 A KEH37S22N2LMA 2000 A KEH31D22N2LMA 2500 A KEH32D22N2LMA 3200 A KEH33D22Z2LMA 4000 A *Order numbers for Ref.

  • Page 31: Offset Change Direction (Offset Elbow/Knee)

    Product selection 4.3.5 Offset change direction (offset elbow/knee) Offset change direction (conductor material: aluminium) Rated current I Order number* KEH33S13N1LMA 800 A KEH34S13N1LMA 1000 A KEH35S13N1LMA 1250 A KEH36S13N2LMA 1600 A KEH37S13N2LMA 2000 A KEH31D13N2LMA 2500 A KEH32D13N2LMA 3200 A KEH33D13N2LMA 4000 A *Order numbers for Ref.

  • Page 32: T-Elements

    Product selection T-elements 4.4.1 T-element, horizontal T-element, horizontal (conductor material: aluminium) Rated current I Order number 800 A KEH33S07Z2LMA 1000 A KEH34S07Z2LMA 1250 A KEH35S07Z2LMA 1600 A KEH36S07Z2LMA 2000 A KEH37S07Z2LMA 2500 A KEH31D07Z2LMA 3200 A KEH32D07Z2LMA 4000 A KEH33D07Z2LMA Dimensions in mm Rated current I 800 A...

  • Page 33: T-Element, Vertical

    Product selection 4.4.2 T-element, vertical T-element, vertical (conductor material: aluminium) Rated current I Order number KEH33S06Z2LMA 800 A KEH34S06Z2LMA 1000 A KEH35S06Z2LMA 1250 A KEH36S06Z2LMA 1600 A KEH37S06Z2LMA 2000 A KEH31D06Z2LMA 2500 A KEH32D06Z2LMA 3200 A KEH33D06Z2LMA 4000 A Dimensions in mm Rated current I 800 A 1000 A...

  • Page 34: Connection Elements

    Product selection Connection elements 4.5.1 Transformer connection element Transformer connection element (conductor material: aluminium) Rated current I Order number KEH33S83Z2LMA 800 A KEH34S83Z2LMA 1000 A KEH35S83Z2LMA 1250 A KEH36S83Z2LMA 1600 A KEH37S83Z2LMA 2000 A KEH31D83Z2LMA 2500 A KEH32D83Z2LMA 3200 A KEH33D83Z2LMA 4000 A The exact dimensions depend on the size and construction of the transformer.

  • Page 35: Terminal Elements

    Product selection 4.5.2 Terminal elements Terminal elements (conductor material: aluminium) Rated current I Order number 800 A KEH33S03N1LMA 1000 A KEH34S03N1LMA 1250 A KEH35S03N1LMA 1600 A KEH36S03N1LMA 2000 A KEH37S03N1LMA 2500 A KEH31D03N1LMA 3200 A KEH32D03N1LMA 4000 A KEH33D03N1LMA Rated current I Order number* 800 A KEH33S11N1LMA...
  • Page 36 Product selection Conductor configurations of terminal elements Standard for unimes H: Another phase sequence is possible Other possibilities: Technical changes reserved...
  • Page 37 Product selection Dimensions of the connection flanges for terminal elements Rated current In Material Dimensions 1600 A Aluminium 2000 A Aluminium 2500 A Aluminium Other versions on request. Technical changes reserved...

  • Page 38: Drill Holes For Connecting Flanges

    Product selection Drill holes for connecting flanges 4.6.1 Standard type Drill holes in connecting flanges (aluminium conductors) Al 1600 A Al 2000 A Al 2500 A Al 3200 A Al 4000 A Other versions on request. Technical changes reserved...

  • Page 39: Other Types

    Product selection 4.6.2 Other types Drill holes in connecting flanges of terminal elements Aluminium Technical changes reserved...
  • Page 40 Product selection Copper Technical changes reserved...

  • Page 41: Cable Feeder

    Product selection Cable feeder 4.7.1 Cable end feeder Cable end feeder (conductor material: aluminium) Rated current I Order number* 800 A KEH33S51Z0LMA 1000 A KEH34S51Z0LMA 424014 1250 A KEH35S51Z0LMA 1600 A KEH36S51Z0LMA 2000 A KEH37S51Z0LMA 2500 A KEH31D51Z0LMA 3200 A KEH32D51Z0LMA 4000 A KEH33D51Z0LMA...

  • Page 42: Tap-Off Units

    Product selection Tap-off units The distribution of energy using tap-off units is only possible for a busbar system with protection type IP55 / IP65 (the busbar system with protection type IP68 is intended exclusively for energy transport). Selection, assembly and installation of tap-off units and protective equipment may only be undertaken by electrical specialists.

  • Page 43: Tap-Off Units For Plug-In

    Product selection 4.8.2 Tap-off units for plug-in The tap-off units can be plugged into plug-in on straight busbar elements while voltage is applied (taking account of EN 50110 and national regulations). They can be plugged into any busbar system with IP55 / IP65, regardless of the rated current of the straight busbar elements.
  • Page 44 Product selection Tap-off unit, empty or for HRC fuses Rated current I Order number Switchgear Number of Cable size poles 125 A KEA440E1 empty 125 A KEA470D1 125 A KEA470F1 HFD312 95 mm² 125 A KEA450F1 HFD412 95 mm² 250 A KEA441E1 empty 250 A...

  • Page 45: Tap-Off Units For Connection Joints

    Product selection 4.8.3 Tap-off units for connection joints The tap-off units can be installed between all straight busbar elements of protection type IP55/IP65, regardless of the rated current of the busbar elements. In the case of tap-off units for connection joints, a suitable joint block appropriate for the rated current of the busbar system must be ordered at the same time.

  • Page 46: Accessories

    Product selection Accessories 4.9.1 End flange End flange (conductor material: aluminium) Rated current I Order number KEH33S10Z0LMA 800 A KEH34S10Z0LMA 1000 A KEH35S10Z0LMA 1250 A KEH36S10Z0LMA 1600 A KEH37S10Z0LMA 2000 A KEH31D10Z0LMA 2500 A KEH32D10Z0LMA 3200 A KEH33D10Z0LMA 4000 A 4.9.2 Fastening material Hanger assembly (conductor material: aluminium)

  • Page 47: Joint Block, Standard (Spare Part)

    Product selection 4.9.3 Joint block, standard (spare part) Standard joint block (conductor material: aluminium) Rated current I Order number KEH33S29 800 A KEH34S29 1000 A KEH35S29 1250 A KEH36S29 1600 A KEH37S29 2000 A KEH31D29 2500 A KEH32D29 3200 A KEH33D29 4000 A The insulating material is temperature...

  • Page 48: Sketches Of Busbar Elements

    Sketches of busbar elements Sketches of busbar elements Straight lengths 3 m (code 00), 2 m (code 80) and Fire barrier (code 19) 1 m (code 81) without plug-in Straight lengths with plug-in Horizontal elbow, N inside (code 04) Horizontal elbow, N outside (code 01) Vertical knee (code 02) Technical changes reserved...
  • Page 49 Sketches of busbar elements Z-element horizontal (code 21) Z-element vertical, N on left (code 22) Z-element vertical, N on right (code 23) Offset change direction (code 16) Offset change direction (code 15) Offset change direction (code 14) Technical changes reserved...
  • Page 50 Sketches of busbar elements Offset change direction (code 13) Cable end feeder, N on right (code 51) Cable end feeder, N on left (code 52) Standard distributor connection (code 03) Terminal connection with knee, N on outside (code 11) Terminal connection with knee, N on inside (code 31) Technical changes reserved...
  • Page 51 Sketches of busbar elements Terminal connection with knee, N on left (code 32) Terminal connection with knee, N on right (code 12) T-element, vertical (code 06) T-element, horizontal, N on right (code 08) T-element, horizontal, N on left (code 07) Technical changes reserved...

  • Page 52: Technical Data

    Technical data Technical data Conductors aluminium, 4 bars (N, L1, L2, L3), PE housing Rated current I 1000 1250 1600 2000 2500 3200 4000 Rated insulation voltage U 1000 1000 1000 1000 1000 1000 1000 1000 Rated operating voltage U 1000 1000 1000...
  • Page 53 Technical data Rated current I 1000 1250 1600 2000 2500 3200 4000 Rated insulation voltage U 1000 1000 1000 1000 1000 1000 1000 1000 Rated operating voltage U 1000 1000 1000 1000 1000 1000 1000 1000 Rated frequency f [Hz] 50/60 50/60 50/60...

  • Page 54: Conductors Copper, 4 Bars (N, L1, L2, L3), Pe Housing

    Technical data Conductors copper, 4 bars (N, L1, L2, L3), PE housing Rated current I 1000 1250 1600 2000 2500 3200 4000 Rated insulation voltage U 1000 1000 1000 1000 1000 1000 1000 Rated operating voltage U 1000 1000 1000 1000 1000 1000...

  • Page 55: Conductors Copper, 5 Bars (N, L1, L2, L3, Pe2), Pe Housing

    Technical data Conductors copper, 5 bars (N, L1, L2, L3, PE2), PE housing Rated current I 1000 1250 1600 2000 2500 3200 4000 Rated insulation voltage U 1000 1000 1000 1000 1000 1000 1000 Rated operating voltage U 1000 1000 1000 1000 1000...

  • Page 56: Calculating The Voltage Drop

    Technical data Calculating the voltage drop ∆V = Actual current / Rated current x strand length x Factor V/m = Voltage loss For energy distribution using tap-off units, the result must be divided by 2. Aluminium conductors: Factor V/m according to power factors and rated current Rated current [A] cosϕ...

  • Page 57: Temperature Derating

    Technical data Temperature derating Influence of ambient temperature on the current-carrying capability of the busbars. EMC values Values at a distance of 1 m: Rated current [A] Magnetic field [µT] 1000 1250 1600 2000 2500 3200 4000 All details refer to aluminium busbar elements, 4 conductors (N, L1, L2, L3) and PE housing (sheet steel).

  • Page 58: Sprinkler Test

    Technical data Sprinkler test Sprinkler systems are used in buildings for fire protection. Sprinkler systems are automatic fire extinguishing systems. Their function is to detect outbreaks of fire by early detection and to extinguish them as quickly as possible by direct sprinkler irrigation.

  • Page 59: Functional Endurance

    Technical data Functional endurance Applicable regulations Fire protection equipment and fire protection measures for electrical installations are particularly necessary for structural installations of special type and use. Such structural installations include hospitals or places of public assembly. In this case the electrical installations must, according to DIN VDE 0100-560 Structural Installations for Public Assembly and DIN VDE 0100-710-(precursor DIN VDE 0107) Medical Locations or the statutory regulations of the countries, remain operational for certain times, even...
  • Page 60 Technical data Versions Important elements in fulfilling functional maintenance are special components for the functional maintenance duct, as well as the support structure for the duct and the unibar H busbar trunking system. Depending on the ambient conditions, various versions of duct and support structure (fastening with threaded rods or wall brackets) are possible.

  • Page 61: 6.10 Connecting To Unimes H Energy Distributor

    Technical data 6.10 Connecting to unimes H energy distributor Standard versions: Cabinet type U-TE, height 2000 mm ACB type Rail type Operating Depth Width Position of Connection of M-BB the busbar current of busbar AR208S KEH33S Bottom AR208S KEH33S Bottom AR208S KEH33S Bottom...
  • Page 62 Technical data ACB type Rail type Operating Depth Width Position of Connection of current of M-BB the busbar busbar AR325S KEH31D 2500 Bottom AR325S KEH31D 2500 Bottom AR325S KEH32D 3200 Bottom AR325S KEH32D 3200 Bottom AR325S KEH32D 3200 Bottom AR325S KEH32D 3200 Bottom...

  • Page 63: Installation, Handling And Maintenance For Your Safety

    Installation, handling and maintenance Installation, handling and maintenance For your safety Take note of the assembly instructions before starting assembly, installation or other work on the BTS busbar trunking system. 7.1.1 Intended use The unibar H busbar system is used to set up fixed, enclosed busbar trunking systems, BTS for energy transport between the transformer station and the low voltage main distribution board (LVMD)
  • Page 64 Meets EN 61439-1/-6 The unibar H busbar systems are manufactured in accordance with EN 61439-1/-6. The connection is type tested up to 4000 A on the Hager unimes H energy distribution system. Switchgear combinations conforming to EN 61439-1/-2 are constructed from the system proposal for the unimes H energy distribution system.

  • Page 65: Requirements For Authorised Personnel

    Connecting busbar elements (strand disconnected) Product life cycle phase Minimum training, qualification or competence Planning Electrically skilled persons, carried out by Hager in coordination with the user. Transport Transport specialist personnel Assembly, installation Hager or a switchgear manufacturer licensed by Hager,...

  • Page 66: Observe The Assembly Instructions

    Installation, handling and maintenance 7.1.3 Observe the assembly instructions Read and follow the assembly instructions for the unibar H busbar system. In the assembly instructions you will find safety-related information on transport, storage, assembly, operation, inspection and finally the disposal of system components.

  • Page 67: Transport And Storage

    Installation, handling and maintenance Transport and storage 7.2.1 Lifting busbar elements The following must be avoided when transporting busbar elements Damage to the busbar elements, particularly at the ends, Damage to the painting. Transport is always carried out in the horizontal plane, lying flat. The busbars and busbar elements can be lifted manually (weight-dependent), using non-metallic slings,...

  • Page 68: Storage

    Installation, handling and maintenance 7.2.2 Storage Horizontal storage, protected at room temperature Straight busbar elements must be stacked horizontally on one another. A maximum of 5 straight busbar elements may be laid on one another. All unibar components must be stored in a dry, clean and dust-free environment at room temperature before they are installed.

  • Page 69: Assembling The Unibar H System

    Installation, handling and maintenance Assembling the unibar H system The fastening spacing is 3 m for the upright installation position and 2 m for the flat installation position. For double systems (in aluminium rails from 2500 A, identifier D ) the fastening spacing is always 2 m. If straight busbar elements are installed in the horizontal direction with the conductors flat, the neutral conductor must be in the lower position.

  • Page 70: Mounting Direction And Installation Position

    Installation, handling and maintenance 7.3.2 Mounting direction and installation position Direction / mounting direction The direction describes the direction in which the busbars are mounted: horizontal or vertical. Horizontal direction Vertical direction Changes of direction are implemented with standardized system components such as change directions, Z-elements and T-elements.
  • Page 71 Installation, handling and maintenance Wall and ceiling distances The specified distances must be observed in order to enable the assembly of the system and to enable adequate heat removal. Wall and ceiling distances Wall and ceiling distances Upright installation position Flat installation position All dimensions in mm.

  • Page 72: Assembly Principle For Connection Joints With Protection Type Ip55/Ip65

    Installation, handling and maintenance 7.3.3 Assembly principle for connection joints with protection type IP55/IP65 Step Action Remove the two transport protection steel plates at the end of the busbar / busbar element (on the non-jointed side) and dispose of them. Remove the 4 covers for the joint block (flanges of the joint block).
  • Page 73 Installation, handling and maintenance Step Action Fit the top and bottom flanges. Tighten all the bolts. Seal the bolt hole with the cap. Result: The connection has been made. Observe the assembly instructions for safe assembly. It is not permissible to fit a fire barrier over a joint block. Technical changes reserved...

  • Page 74: Assembly Principle For Connection Joints With Protection Type Ip68

    Installation, handling and maintenance 7.3.4 Assembly principle for connection joints with protection type IP68 Step Action Remove the two transport protection steel plates at the end of the busbar elements (on the non-jointed side) and dispose of them. Remove the 4 covers for the joint block (flanges of the joint block). Before connecting, make sure that the ends of the busbar elements and the joint block are clean and undamaged.
  • Page 75 Installation, handling and maintenance Step Action Fit the top and bottom flanges. Tighten all the bolts. Insert the seals. Prepare the casting resin mixture according to the instructions and then fill the joint block. Seal the filling hole with the cover. Result: The connection has been made.

  • Page 76: Cable Feeds

    Installation, handling and maintenance 7.3.5 Cable feeds The installation of feeder units requires the busbar trunking run to be free of applied voltage (disconnected and secured from being switched on again). Cable end feeder The cable end feeder is supplied complete with joint block. Assembly is carried out according to the principle of assembly of connection joints.

  • Page 77: Fire Barrier

    Installation, handling and maintenance 7.3.6 Fire barrier Fire barriers are required for busbar elements which pass through fire area. They are fitted to the busbar element during the manufacturing process. Comment: After assembling the busbar run, seal the joints in the fire barrier or fire ceiling with dimensionally stable, non-flammable construction material (Class A1 or A2-s1;...

  • Page 78: End Flange

    Installation, handling and maintenance 7.3.7 End flange End flanges are used to cap busbar elements at the end of a run safely. End flanges are fastened with bolts. Technical changes reserved...

  • Page 79: Fitting Tap-Off Units To Plug-In (125 - 630 A)

    Installation, handling and maintenance 7.3.8 Fitting tap-off units to plug-in (125 - 630 A) The installation of units for plug-in is only possible on straight busbar elements with plug-in. These tap-off units can be installed without switching off the busbar trunking run.
  • Page 80 Installation, handling and maintenance Step Action Align the position lever (Lever). Unfasten screw D until the rear clamps have closed. Unfasten screw B until screws C have moved from position 1 to position 2 and the front clamps have closed. Technical changes reserved...

  • Page 81: Fitting Tap-Off Units To Connection Joints (250 - 1250 A)

    Installation, handling and maintenance 7.3.9 Fitting tap-off units to connection joints (250 - 1250 A) Tap-off units can only be installed on connection joints between straight busbar elements. Installing a tap-off unit requires the power to be disconnected from the busbar trunking run (disconnected and secured from being switched on again).

  • Page 82: Operation, Maintenance And Enlargement

    Installation, handling and maintenance Operation, maintenance and enlargement Extensive information can be found in the assembly instructions. The initial operation after assembly and installation of the busbar trunking elements is carried out at the user’s site by an electrically skilled person with testing experience.

  • Page 83: Enlargement

    Hager, a design verification must be created. A routine verification is not sufficient in this case. Use only type-tested components from Hager. In this way you will avoid the need to create a type verification.

  • Page 84: Comments For Specifications For Tenders

    Comments for specifications for tenders Comments for specifications for tenders Basic description of busbar trunking systems 800 - 4000 A Busbar trunking system must be supplied and fitted as a low voltage switchgear combination conforming to IEC / EN 61439-1 and IEC / EN 61439-6 in a ready-to-connect implementation.
  • Page 85 Comments for specifications for tenders Bars of double body systems for the same phase have balanced at each connection joint to ensure equal current distribution. Special components for phase compensation are not permitted. Heat is dissipated by the housing. The temperature rise of the housing at the particular rated current must not exceed 55 °, regardless of the installation position.

  • Page 86: Formula Characters And Abbreviations In Accordance With En 61439-1/-6

    Formula characters and abbreviations in accordance with EN 61439-1/-6 Formula characters and abbreviations in accordance with EN 61439-1/-6 Important formula characters first mentioned in EN 61439-1/-6* Abbreviation Description Standard section 61439-1/-6* (initial mention) Comparative figure of tracking EN 61439-1, 03/06/2016 Low voltage EN 61439-1, 03/07/2011 Electromagnetic compatibility...

  • Page 87: 10 Glossary

    Glossary 10 Glossary Busbar elements Busbar trunking unit BTU. Busbar trunking units / busbar elements can take various geometric shapes, such as, for example Straight length: straight busbar element Change directions T-elements Busbar trunking run / BTR If a busbar trunking system BTS consists of connected busbar trunking units, one speaks of a busbar trunking run.
  • Page 88 If a busbar trunking unit has been designed by the original manufacturer (Hager) so that tap-off units can be connected at defined points, one speaks of a busbar trunking unit with plug-in. The variant of the Hager unibar H busbar system with protection type IP55/IP65 provides various options for connecting tap-off units to busbar trunking units with plug-in.
  • Page 89 Glossary Parts of EN 61439 standard Part of Content European standard EN 61439-1 Low-voltage switchgear and controlgear assemblies - Part 1: General rules EN 61439-2 Low-voltage switchgear and controlgear assemblies - Part 2: Power switchgear and controlgear assemblies (PSC) EN 61439-3 Low-voltage switching controlgear assemblies - Part 3: Distribution boards intended to be operated by ordinary persons...
  • Page 90 - Circuits and consumers - Installation and ambient conditions - Operating and maintenance. Planning is carried out by Hager in cooperation with the user (agreements, circumstances on site) Is responsible for verifying the design by means of verification tests, Original...

  • Page 91: Index

    Index Intended use • 64 Index Knee, vertical • 29 Accessories • 47 Assembling the unibar H system • 70 Assembly principle for connection joints with Lifting busbar elements • 68 protection type IP55/IP65 • 73 Assembly principle for connection joints with protection type IP68 •...
  • Page 92 Hager Electro GmbH und Co. KG Zum Gunterstal 66440 Blieskastel GERMANY Tel.: +49 6842 945 0 Fax: +49 6842 945 4625 www.hager.de Version: 1.0 10/2018...
