Homeright PaintStick Instruction Sheet

PaintStick Piston
1. Separate inner and outer handles by quickly pulling apart. If you
cannot separate, set PaintStick on floor, put your foot on collar and
roll to loosen.
PaintStick EZ-Twist Piston
1. Grasp clear tube firmly and turn handle counterclockwise to unscrew.
Remove piston from clear outer tube. NOTE: If paint is on the piston
remove paint with a damp rag.
PaintStick & PaintStick EZ-Twist Valve Body
1. Pop out retainer with a screwdriver. Remove foam wiper and pry out
valve.
PaintStick
2. Take off and discard old o-rings. Install new o-rings and lubricate with
petroleum jelly.
2. Take off and discard old quad-rings. Install new quad-rings and
lubricate with petroleum jelly.
2. Discard old parts. Clean area. Install new valve and wiper. Press in
retainer.
& PaintStick
®
3. Insert inner handle into outer handle and push together. Be careful not
to pinch o-rings.
3. Insert inner handle into outer handle and push together. Be careful not
to pinch o-rings. To reassemble, hold the tube securely and turn the
handle clockwise until secure.
3. Put a small amount of petroleum jelly into the fill port to lubricate the
foam wiper.
EZ-Twist
®
Tune-up Kit Instruction Sheet
®
