- Page 1 Ice Tower Quick Guide (read installation manual before installing) (Rev B) Big Air Pylons Inc. 5305 Robert Lee Rd Duncan, OK 73533 580-252-5314 Toll free: 855-252-5314 www.bigairwaketowers.com...
- Page 2 Required Tools: • Level • Tape measure • Variable Speed Drill • Metric Allen set • 3/8” (10mm) Drill bit • 9/16” Drill bit ASSEMBLY 1. Find the mounting locations 40 to 60 inch stance (at the centers of the gaskets) from front to back of the boat.
- Page 3 To lay the tower down: If the rear mounts are completely parallel: 1. Loosen the 10 mm bolts on the rear legs to allow the tower to tilt back. 2. Unthread the 10mm bolts connecting the front legs to the base mount on each side. 3.
