  • Page 1 Tower Installation and Instruction Manual Installation and Instruction Manual Installation and Instruction Manual Installation and Instruction Manual (Rev A) Big Air Waketowers Big Air Waketowers Inc. Inc. Big Air Waketowers Big Air Waketowers Inc. Inc. 5305 Robert Lee Rd 5305 Robert Lee Rd...
  • Page 2 IMPORTANT NOTES FOR INSTALLING YOUR BIG AIR TOWER • The Fusion Tower is designed to fit a hull between 58” and 103” wide. Please measure your intended mounting locations to make sure they fall within this range. • ALWAYS apply a layer of grease to all bolts before attaching to the joining connection (some connections will call out blue Loctite).
  • Page 3 Thank you for purchasing Big Air’s Fusion Tower. Installation of the tower is relatively simple and should take two people 3 to 6 hours. You will need someone to help you measure and assemble the tower. No special tools are needed other than those listed below.
  • Page 4 Base Gasket Base plate Base bolt 14mm nylock Swivel Swivel mount bolt Heim joint Quick Release Knob...
  • Page 5 H-member H-member H-member Right hand Left hand threads threads Rear Corners Note: shorter length Front Corners Note: longer length Step # 1. Decide where to locate your tower • The Fusion can face either direction based on your preference. • You can mount your tower anywhere along the boat’s hull where there is access under the gunnel to install the backing hardware.
  • Page 6 • Level the floor of your boat. (typically done using your trailer jack) • Typically it’s best to mark the location for the rear leg mount on the side of the gunnel and wait on the front leg locations. • We suggest you use masking tape to cover the area where you will be placing the mounts.
  • Page 7 Step #3: Install Rear Base Mount Bar Assembly Install the base bolts into the base using an allen wrench inserted into the end and secure • tightly (use blue Loctite on threads into the base) Base Mount Gasket Base Bolt Secure the bases using a rubber gasket and the aluminum plate retained by the 12mm •...
  • Page 8 Step #5: Assemble Tower Structure (Careful, don’t slide the legs in too far or you may damage the finish of pipe that will be exposed when installation is finished.) • We recommend that you mark each corner with a sharpie marker showing the distance from the end to the corner.
  • Page 9 • Remove the threaded ends from the H-member. (Note, the left/port side threads are left handed.) • Slide the left hand threaded caps on to the port/left hand corners. • Slide the right hand threaded caps on the starboard/right hand corners. •...
  • Page 10 • Install the strut braces Port/left Starboard/right strut end Strut end Port/left Side strut Starboard/right Side strut Hinge Joint Adjust the tower to match the approximate width of the base mounts. • Place the tower on the boat connecting at the rear mounts using the quick release •...
  • Page 11 We recommend that you secure the center of the H-member to the front of the • boat with a rope or strap to help ensure that stays in place and movement is minimal. The marks on the corners you made with the marker will help you keep the H-member centered.
  • Page 12 To lay the tower down 1. Remove the front leg quick release knobs. 2. Lay the tower backwards. 3. Release the set screws on the front leg connections. 4. Remove the socket head bolts connecting the struts. 5. Pull the front legs free. 6.

  • Page 13: Trouble Shoots

    Trouble Shoots: 1. Apply a thin later of grease to all bolts to prevent galling. 2. Use mineral spirits to remove tape residue after install. 3. If screws become loose, use a thread locker such as loctite on the threads to help prevent the bolts from vibrating loose (note: when using thread locker, you should not use grease).
  • Page 14 Drilling Fiberglass Drilling holes in fiberglass bodies and accessories can be very tricky business. If not done properly, you can chip off significant pieces of gel-coated surface or cause spider web cracks. Trying to cut through gel-coat with the shallow rake angle of a drill bit is what actually causes the chipping.

  • Page 15: Wiring Tips

    Most customers choose to drill a hole through their hull to allow the wires to pass through. We recommend using the expandable sleeving through this opening also. Quick release outdoor wiring quick disconnects to pass through your hull can be purchased directly from Big Air.
  • Page 16 Mast/Navigation Light Installation If you have purchased a Mast/Navigation light, the instructions below offer directions for installation. Included in the installation kit are 1) Mast Light, 2) light adapter plate and 3) two 4mm screws. 1. Remove tow knob cap as shown in image below by simply inserting a screw driver into the side of the cap and rotating it...
  • Page 17 By submitting your photographs, you certify that you own the rights to these photos. You understand that you will give Big Air Waketowers the right to use and publish your photos in which way they see fit for advertising, without compensation. Your personal information will not be sold or rented to any third parties.
  • Page 18 Returns: Within 30 days of receiving your order from Big Air Pylons Inc., you may return any non-custom product. All parts must be in their original condition and packaging, and cannot be assembled, installed, or damaged. Items that do not meet these criteria will be returned to you and you will be charged for return shipping (All parts that have been assembled or installed are not returnable).
