Blind control system
Wind sensor Standard
Wind sensor Standard
Order No. : 0913 00
Operating instructions
1 Safety instructions
Electrical equipment may only be installed and fitted by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or
load. At the same time, take into account all circuit breakers that supply dangerous
voltage to the device or load.
Danger of electric shock. Not suitable for controlling 24 V Venetian blind inserts. If there
is a fault, 230 V might enter the 24 V network.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
82523842
Figure 1
07.08.2014
1/6
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gira 0913 00
Summary of Contents for Gira 0913 00
- Page 1 Blind control system Wind sensor Standard Wind sensor Standard Order No. : 0913 00 Operating instructions 1 Safety instructions Electrical equipment may only be installed and fitted by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully.
- Page 2 Blind control system Wind sensor Standard Figure 2 (1) Evaluation unit (2) Test LED (3) Housing lid screws (4) Wind sensor 3 Function Intended use The evaluation unit and wind sensor are used to protect a blind/shutter against destruction due to excessively strong winds. The blind/shutter is moved to a safe end position and locked there until the wind drops below the set wind speed value.
- Page 3 Blind control system Wind sensor Standard Connecting the evaluation unit DANGER! Electrical shock when live parts are touched. Electrical shocks can be fatal. Before working on the device, disconnect all the corresponding miniature circuit breakers. Cover up live parts in the working environment. Remove the housing lid of the evaluation unit by slackening the two screws (3).
- Page 4 Blind control system Wind sensor Standard Figure 4: Connection diagram for connecting the evaluation unit to the Venetian blind controller The evaluation unit has a relay with two potential-free NO contacts. To control the Venetian blind insert (11) from the same conductor, place a bridge (12) between the relay input and the conductor.
-
Page 5: Warranty
The warranty is provided in accordance with statutory requirements via the specialist trade. Please submit or send faulty devices postage paid together with an error description to your responsible salesperson (specialist trade/installation company/electrical specialist trade). They will forward the devices to the Gira Service Center. 82523842 07.08.2014... - Page 6 Blind control system Wind sensor Standard Gira Giersiepen GmbH & Co. KG Elektro-Installations- Systeme Industriegebiet Mermbach Dahlienstraße 42477 Radevormwald Postfach 12 20 42461 Radevormwald Deutschland Tel +49(0)21 95 - 602-0 Fax +49(0)21 95 - 602-191 www.gira.de info@gira.de 82523842 07.08.2014...
