Hella RFCommSafe AS3000 Mounting Instructions

AS3000 RFCommSafe
Mounting instructions
Operating Instructions
PLEASE OBSERVE THE FOLLOWING:
Adhere to the maximum temperature requirements of the work lamp.
The lamp may not be operated in small enclosed spaces.
The distance between the lens and any combustible materials must be at least 1 metre.
Avoid looking directly into the intensive light.
HELLA-New Zealand Ltd
™ Work Lamp - 12V DC
Please retain for future reference
958 315-36 V02
AS3000 RFCommSafe
HELLA LED lighting offers many advantages over conventional bulb lamps.
Significantly reduced power consumption, ultra long life and high tolerance to shock and vibration
make HELLA LED lamps the ideal choice for the harsh automotive and mining environments.
Housing Material
Lens Material
Bracket Material
Colour Temperature
Cable
Operating Voltage
Power Consumption
Operating Temperature
Degree of Protection
Weight
Light Output
RFCommSafe™ Electromagnetic Compatibility (EMC)
Every LED lamp contains electronic circuitry. It is essential that this circuitry does not cause harmful
interference to other devices and at the same time is not susceptible to radiation from other devices.
RFCommSafe™ products were developed in recognition that some radio communication equipment can
self-tune to be very sensitive in remote areas. In these situations the limits prescribed by regulatory
requirements and as defined in international standards such as CISPR15 or relevant UNECE Standards may
not be sufficient to ensure there is no interference with very sensitive radio communication equipment.
Lamps marketed as RFCommSafe™ are designed to go well beyond the requirements of CISPR15,
CISPR25 and UNECE Standards.
4 HELLA-New Zealand Ltd
™ Work Lamp - 12V DC
Mounting instructions
Please retain for future reference
Technical Data
Die cast aluminium body. Non-stick surface coating
Heavy duty Grilamid ®
316 stainless steel
5000K (Daylight White)
Pre-wired with 2.5m three core cable
10 - 16V DC
Full Output Mode: 45W Dimmed Output Mode: 20W
-40°C to +50°C
IP6K7 IP6K9K - Completely Sealed
2.6 kg (including cable)
3000 lumens
Dimensions
958 315-36 V02 1
