Hella 959037 Series Mounting Instructions

Duraled multi-flash high intensity signal lamp

Download this manual

8.2mm

Position of cable

entry through base

959 149-65 V02

959 149-65 V01

Part No. 2XD 959 037-xx

for:

DuraLED

Multi-Flash High Intensity Signal Lamp

DuraLed

Multi Flash

drill hole(s) 6.5mmØ

Fixing Centres

Template

(Actual size)

13.6mm

MOUNTING INSTRUCTIONS

Part No. 959037xx

MOUNTING INSTRUCTIONS

for:

LED High Intensity Signal Lamp

Please retain for future reference

drill hole(s) 6.5mmØ

177

100

148

Page 1 MOUNTING INSTRUCTIONS Part No. 959037xx MOUNTING INSTRUCTIONS for: Part No. 2XD 959 037-xx for: DuraLED Multi-Flash High Intensity Signal Lamp ® ® DuraLed Multi Flash LED High Intensity Signal Lamp Please retain for future reference Please retain for future reference drill hole(s) 6.5mmØ...
Page 2 33 volts without damage to the circuit. Warranty: Hella branded products are covered by a warranty against Cable routing manufacturing or material defects. Lamp is sealed and does not have any serviceable parts inside; opening the lamp will invalidate warranty.
Page 3 OPERATING INSTRUCTIONS Part No. 959037xx OPERATING INSTRUCTIONS for: Part No. 2XD 959 037-xx for: DuraLED Multi-Flash High Intensity Signal Lamp ® ® DuraLed Multi Flash LED High Intensity Signal Lamp Please retain for future reference Please retain for future reference Operating Modes •...
Page 4 Electric Welding Electric Welding may damage the LED lamps. For LED lamps, Hella recommends the negative connection to be wired isolated from the vehicle chassis. If the lamp uses the chassis as the earth return it is recommended that this earth return is disconnected during electric welding.
