MIDcounter AND PowerMeter INSTALLATION

If the MIDcounter is installed together with the PowerMeter, they must be connected as shown
in the diagram below:
Eletrical panel
Utility Meter
Utility Meter
Both devices must be connected on the same communication bus. Connect the Modbus
communication cables as follows:
Th
Eletrical panel
PowerMeter
PowerMeter
A SC B
A SC B
GND B
GND B A
CN12 Port
MIDcounter
MIDcounter
A SC B
PowerMeter
A SC B
MIDcounter
A
CN12 Port
Wallbox
Wallbox
RS485 Port CN12
Wallbox
Loads
Loads
PowerMeter
MIDcounter
Wallbox
RS485 Port CN12
4
