MIDcounter INSTALLATION

The MIDcounter is a certified energy meter that allows you to safely and reliably monitor the
consumption of your wallbox during each charging session.
Do not try to install the energy meter if you are not qualified as a professional
electrician. Such behavior can cause serious danger and harm to you and to the
people, things or animals around you.
Only energy meters provided by Free2move eSolutions S.p.A. are compatible.
Installation must be performed by qualified personnel in accordance with local
regulations. Please refer to local regulations and user and wallbox installer
manuals on www.esolutions.free2move.com/document-library/ for more
information about the installation process.
Before carrying out any installation or maintenance work on the device, it is
must be ensured that the power supply is switched off.
1.
Place the MIDcounter provided on the wallbox electrical line, after the RCD and MCB.
Eletrical panel
Utility Meter
MIDcounter Wallbox
Loads
RS485 Port CN12
