OPERATOR'S MANUAL
Hydraulic Body/Frame Repair Kit
! !
WARNING:
FOR YOUR SAFETY, PLEASE READ THESE INSTRUCTIONS CAREFULLY.
THE OWNER AND OPERATOR SHALL HAVE AN UNDERSTANDING OF THIS
PRODUCT AND SAFE OPERATING PROCEEDURES PRIOR TO INITIAL USE.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE
FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
TO PROPERTY AND/OR SERIOUS PERSONAL INJURY. PLEASE KEEP THIS
INSTRUCTION MANUAL SAFE FOR FUTURE USE.
PROD. NO. 030256
MOD. NO. BRK-20SHD
M20-SA030256-FA
