- Page 1 HD5 Maintenance Quick Guide © 2020 Radio Engineering Industries, Inc.
-
Page 2: Table Of Contents
2 System Maintenance Check 3 Laptop Setup when Using a Web User Interface 4 Conduct Ping Test to Verify Connectivity 5 HD5 Maintenance Check Off Sheet HD5 System Maintenance Check Radio Engineering Industries, Inc. | 6534 L Street | Omaha, NE 68117 ©... -
Page 3: Introduction
HD5 System Maintenance Check Introduction This document outlines the step-by-step process for conducting a system maintenance check for HD5 series DVRs. SERVICE HOT LINE USA & CANADA 1-877-726-4617 Toll Free 1-402-339-2200 HD5 System Maintenance Check Radio Engineering Industries, Inc. | 6534 L Street | Omaha, NE 68117 ©... -
Page 4: System Maintenance Check
HD5 System Maintenance Check System Maintenance Check The vehicle must be powered on. Assure the DVR is in record mode by checking that the hard drive is locked in the DVR. The REC light is illuminated when this occurs. REC Light Indicates Record Mode is Active The monitor video cable and the USB mouse should be plugged in the front of the DVR. - Page 5 HD5 System Maintenance Check Video Should Appear on Active Channels Assure there is video appearing on all the activated channels. If a blue screen appears, it could be caused by the following: • The camera is not plugged in •...
- Page 6 HD5 System Maintenance Check Checking Firmware Version The Event Marker/Panic Button illuminates when the DVR is recording. It can be verified that when the Panic button is pressed, it will be indicated as PB on the Info/Inputs field as depicted below.
- Page 7 HD5 System Maintenance Check Warning: All video data will be lost during formatting. Selections made to Format/Clear HDD After the drive is formatted, check if the following indicators are illuminated on the front of the DVR: Off: VLOSS Inputs have three different types: School Bus, Transit, and Custom. The inputs to test for School Bus...
-
Page 8: Laptop Setup When Using A Web User Interface
HD5 System Maintenance Check Verify the Accelerometer is working by checking if the X:, Y:, and Z: Coordinates are visible. An illuminated green light in the check box next to the Accelerometer indicates a good connection. Verify if the GPS is working by checking if the LON: and LAT: data indicators are visible. An illuminated green light in the check box next to GPS indicates a good connection. - Page 9 HD5 System Maintenance Check Right click adapter and select Properties. Selecting Properties Select Internet Protocol Version 4 (TCP/IPv4) and select properties. Adapter Configuration Settings Configure adapter with settings as depicted above. Click OK to finalize. Connect ethernet cable to front port.
-
Page 10: Conduct Ping Test To Verify Connectivity
HD5 System Maintenance Check Conduct Ping Test to Verify Connectivity Open the command prompt. Searching for and Opening the Command Prompt Enter “ping 192.168.200.200” and press enter. HD5 System Maintenance Check Radio Engineering Industries, Inc. | 6534 L Street | Omaha, NE 68117 ©... - Page 11 HD5 System Maintenance Check Enter IP address at Prompt Successful Ping Test After the ping test is successful, the DVR web user interface can be accessed using Google Chrome or Microsoft Edge browser. The default password is 11111111. HD5 System Maintenance Check Radio Engineering Industries, Inc.
-
Page 12: Hd5 Maintenance Check Off Sheet
HD5 System Maintenance Check Initial View of DVR Web User Interface HD5 Maintenance Check Off Sheet Hard Drive Locked DVR Recording Video on all channels Time and Date confirmed Firmware up to date Event marker/Panic Button light when DVR in Record mode... - Page 13 HD5 System Maintenance Check Vehicle ID: Date: Technician: HD5 System Maintenance Check Radio Engineering Industries, Inc. | 6534 L Street | Omaha, NE 68117 © 2020 Radio Engineering Industries, Inc. 800.228.9275 | p: 402.339.2200 | f: 402.339.1704 | radioeng.com...
