Page 5: General Information
USB server for applications with additional influences of different kinds. It protects the devices among things like dirt, dust, and moisture. The outdoor protective housing can be used for any PI camera (lenses up to 90° FOV) and for CSlaser LT and CTlaser LT. The integrated heating and the blower result in an extended operating temperature. -
Page 6: Warranty
1.2 Warranty Each single product passes through a quality process. Nevertheless, if failures occur please contact the customer service at once. The warranty period covers 24 months starting on the delivery date. After the warranty is expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted product components. -
Page 7: Technical Data
Technical Data 2 Technical Data 2.1 General Specifications -40 °C … +50 °C Temperature range Heating PTC heater (automatically starting at T < 15 °C) / fan for homogeneous temperature distribution Power supply 24 V DC Power 70 W Current draw 3 A (short term: 6 A) Protective window Germanium (Ge), zinc sulfide (ZnS), Borofloat or foil... -
Page 8: Dimensions
2.2 Dimensions Figure 1: Dimensions [mm] with wall mount... - Page 9 Technical Data Figure 2: Dimensions for wall mount...
-
Page 10: Electrical Connections
2.3 Electrical Connections Power supply Industrial PIF and USB server Figure 3: Connection circuit board... -
Page 11: Air Purge Laminar
Technical Data 2.4 Air Purge Laminar The lens must be always kept clean from dust, smoke, fumes, and other contaminants in order to avoid reading errors. These effects can be reduced by using an air purge laminar. Make sure to use oil-free, technically clean air only. -
Page 12: Installation
Loosen the two screws and open the outdoor protective housing, as shown in Figure 4. Figure 4: Opening the housing Inside the protective housing is the electronic circuit board, where all loads are connected (see Figure 3). The heating element and the fan are already integrated and connected. To supply the outdoor protective housing... - Page 13 Installation with voltage, you must connect a 24 V line. This is connected to the marked side of the board. Observe the correct polarity and ensure that no voltage is present. The USB server and the industrial PIF are connected to the board as shown and are supplied by 24 V.
-
Page 14: Installation (With Visible Camera) [Hier Variante B]
3.2 Installation (with visible camera) [hier Variante B] Connect the network cable to a PoE 3.3 Mounting of the USB server Insert the USB server at a slanted angle to the designated disk (Figure 6). If necessary, remove the clip from the USB server (Figure 7) and turn the USB server (Figure 6) until the clip is locked into the bracket (Figure 8). - Page 15 Installation The USB server is now ready mounted (Figure 9): Figure 9: USB server ready mounted...
-
Page 16: Mounting Of The Pi Camera
3.4 Mounting of the PI camera Step 1: Loosen the knurled screw from the mounting plate (Figure 10). Figure 10: Loosen the knurled screw from mounting plate... - Page 17 Installation Step 2: Carefully remove the mounting plate (Figure 11). Figure 11: Remove the mounting plate...
- Page 18 Step 3: Mounting the PI cameras Figure 12: PI 400i/ 450i/ 640i/ 1M/ 08M/ 05M attachment Mount the PI 400i/ 450i/ 640i/ 1M/ 08M/ 05M to the mounting plate using the supplied 1/4 x 3/8 UNC inch screw and a washer DIN125A-6,4 A2 (Figure 12). After the camera is fully assembled, the mounting plate can be attached back to the outdoor protective housing with the provided screw.
- Page 19 Installation Figure 13: Fully assembled PI camera on mounting plate Figure 14: Fully assembled PI camera in outdoor protective housing...
-
Page 20: Mounting Of The Xi Camera
Loosen the mounting nut and mounting bracket from the Xi camera. Now screw the camera into the provided adapter plate. For an exact positioning of the camera, the camera can also be attached by turning the clamping ring. Figure 15: Xi camera mounted in adapter plate Figure 16: Fully assembled Xi camera in outdoor protective housing... -
Page 21: Mounting Of Cslaser/Ctlaser
Installation 3.6 Mounting of CSlaser/CTlaser Follow steps 1 and 2 as described in chapter 3.4. Mounting of CSlaser/CTlaser Attach the device with the corresponding bracket. Mount the CSlaser or CTlaser to the mounting plate using the supplied 1/4 x 3/8 UNC inch screw and a washer DIN125A-6,4 A2 (Figure 17). - Page 22 Figure 18: Mounted CSlaser or CTlaser on the mounting plate Figure 19: CSlaser or CTlaser in outdoor protective housing...
-
Page 23: Accessoires
In addition to the installation of the camera and the USB server, the industrial PIF (without housing) can be integrated into the outdoor protective housing as shown in Figure 20. The industrial PIF without housing can be purchased under the order number ACCJAPIPIFMA (for PI series and Xi 400) or under ACOPHXIPIF (Xi 80/ 410). -
Page 24: Wall Mount
(see chapter 3.4 Mounting of the PI camera or 3.5 Mounting of the Xi camera). 4.3 Wall mount The outdoor protective housing can be attached to a wall using a wall mount. This is available as an option under the part number ACOPHWM. -
Page 25: Replacement Of Protective Foil / Protective Window
Replacement of protective foil / protective window 5 Replacement of protective foil / protective window If necessary, the protective foil of the outdoor protective housing can be replaced (only for Part-Number: ACPIOPHF). To change the protective foil a screwdriver and a scalpel is needed. - Page 26 Figure 24: Remove air purge laminar...
-
Page 27: Removing And Inserting The Protective Foil
Replacement of protective foil / protective window 5.2 Removing and inserting the protective foil Step 1: Remove the old protective foil by removing the tension ring attachment and the tension ring. Figure 25: Remove old protective foil... - Page 28 Step 2: Replace the old protective foil with the new protective foil. Step 3: Insert the O-ring 2 in the air purge laminar. Step 4: Place the protective foil on the center of the air purge laminar and press it with the aid of the tension ring and the tension ring attachment until the tension ring attachment is level with the air purge laminar.
-
Page 29: Cut The Protective Foil
Replacement of protective foil / protective window 5.3 Cut the protective foil Step 1: Take a scalpel and cut along the inside of the nut. Figure 27: Cut the protective foil with the scalpel Figure 28: Cut the protective foil along the nut inner surface... - Page 30 Step 2: Insert the O-ring 1 into the nut of the air purge laminar and repeat the steps in chapter 5.1 reverse. Make sure that the air purge laminar is pressed against the adapter plate when you tighten the screws again! O-ring 1 Figure 29: Air purge laminar Figure 30: Insert O-ring 1 in air purge laminar...
-
Page 31: Assembly Protective Window
Replacement of protective foil / protective window 5.4 Assembly protective window O-ring 50x1,5 Clamping ring O-ring 47x1,5 protective window Clamping ring attachment Figure 31: Assembly protective window... -
Page 32: Appendix A - Declaration Of Conformity
Appendix A - Declaration of Conformity...
