Table of Contents Table of Contents Table of Contents ............................. 3 General Information ..........................5 Description ............................5 Warranty ............................6 Scope of Supply ..........................6 Technical Data ............................7 General Specifications ........................7 Dimensions ............................8 Electrical Connections ........................9 Air Purge Collar ..........................
Page 4
Mounting of the USB server ......................13 Mounting of the PI camera ......................15 Mounting of the Xi camera ......................19 Mounting of CSlaser/CTlaser ......................20 Accessoires ............................22 Industrial Process Interface (PIF) ....................22 Wall mount ............................. 23 Replacement of protective foil ......................25 Disassembling air purge collar .......................
USB server for applications with additional influences of different kinds. It protects the devices among things like dirt, dust and moisture. The outdoor protective housing can be used for any PI camera (lenses up to 90° FOV) and for CSlaser LT and CTlaser LT. The integrated heating and the blower result in an extended operating temperature.
1.2 Warranty Each single product passes through a quality process. Nevertheless, if failures occur please contact the customer service at once. The warranty period covers 24 months starting on the delivery date. After the warranty is expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted product components.
Technical Data 2 Technical Data 2.1 General Specifications -40 °C … +50 °C Temperature range Heating PTC heater (automatically starting at T < 15 °C) / fan for homogeneous temperature distribution Power supply 24 V DC Power 70 W Protective window Germanium (Ge), zinc sulfide (ZnS), Borofloat or foil Environmental rating IP66...
2.4 Air Purge Collar The lens must be kept clean at all times from dust, smoke, fumes and other contaminants in order to avoid reading errors. These effects can be reduced by using an air purge collar. Make sure to use oil-free, technically clean air only.
Installation 3 Installation 3.1 Electrical installation Loosen the two screws and open the outdoor protective housing, as shown in Figure 3. Figure 3: Opening the housing...
Page 12
Inside the protective housing is the electronic circuit board, where all loads are connected (see Figure 2). The heating element and the fan are already integrated and connected. To supply the outdoor protective housing with voltage, you must connect a 24 V line. This is connected to the marked side of the board. Observe the correct polarity and ensure that no voltage is present.
Installation 3.2 Mounting of the USB server Insert the USB server at a slanted angle to the designated disk (Figure 5). If necessary, remove the clip from the USB server (Figure 6) and turn the USB server (Figure 5) until the clip is locked into the bracket (Figure 7).
Page 14
The USB server is now ready mounted (Figure 8): Figure 8: USB server ready mounted...
Installation 3.3 Mounting of the PI camera Step 1: Loosen the knurled screw from the mounting plate (Figure 9). Figure 9: Loosen the knurled screw from mounting plate...
Page 16
Step 2: Carefully remove the mounting plate (Figure 10). Figure 10: Remove the mounting plate...
Page 17
Installation Step 3: Mounting the PI cameras Figure 11: PI 4xx/ 640/ 1M/ 05M Figure 12: PI 160 attachment Figure 13: PI 2xx attachment attachment Mount the PI4xx/ 640/ 1M/ 05M to the mounting plate using the supplied 1/4 x 3/8 UNC inch screw and a washer DIN125A-6,4 A2 (Figure 11).
Page 18
After the camera is fully assembled, the mounting plate can be attached back to the outdoor protective housing with the provided screw. Figure 14: Fully assembled PI camera on mounting plate Figure 15: Fully assembled PI camera in outdoor protective housing...
Installation 3.4 Mounting of the Xi camera Loosen the mounting nut and mounting bracket from the Xi camera. Now screw the camera into the provided adapter plate. For an exact positioning of the camera, the camera can also be attached by turning the clamping ring.
3.5 Mounting of CSlaser/CTlaser Follow steps 1 and 2 as described in chapter 3.3. Mounting of CSlaser/CTlaser Attach the device with the corresponding bracket. Mount the CSlaser or CTlaser to the mounting plate using the supplied 1/4 x 3/8 UNC inch screw and a washer DIN125A-6,4 A2 (Figure ...
Page 21
Installation Figure 20: CSlaser or CTlaser in outdoor protective Figure 19: Mounted CSlaser or CTlaser on the mounting plate housing...
In addition to the installation of the PI camera and the USB server, the industrial PIF (without housing) can be integrated into the outdoor protective housing as shown in Figure 21. The industrial PIF without housing can be purchased under the order number ACCJAPIPIFMA (for PI series and Xi 400) or under ACOPHXIPIF (Xi 80).
Accessoires 4.2 Wall mount The outdoor protective housing can be attached to a wall using a wall mount. This is available as an option under the part number ACOPHWM. Figure 22: Outdoor protective housing with wall mount The wall bracket is mandatory for a mounting of the protective housing!
Page 24
Figure 24: Fully assembled CSlaser or CTlaser in Figure 23: Fully assembled CSlaser or CTlaser on mounting plate outdoor protective housing...
Replacement of protective foil 5 Replacement of protective foil If necessary, the protective foil of the outdoor protective housing can be replaced (only for Part-Number: ACPIOPHF). To change the protective foil a screwdriver and a scalpel is needed. 5.1 Disassembling air purge collar Step 1: Unscrew the 9 screws from the adapter plate using a screwdriver and remove them together with the washers.
Page 26
Step 2: Gently remove the air purge collar with O-ring 1. Figure 27: Remove air purge collar...
Replacement of protective foil 5.2 Removing and inserting the protective foil Step 1: Remove the old protective foil by removing the tension ring attachment and the tension ring. Figure 28: Remove old protective foil...
Page 28
Step 2: Replace the old protective foil with the new protective foil. Step 3: Insert the O-ring 2 in the air purge collar. Step 4: Place the protective foil on the center of the air purge collar and press it with the aid of the tension ring and the tension ring attachment until the tension ring attachment is level with the air purge collar.
Replacement of protective foil 5.3 Cut the protective foil Step 1: Take a scalpel and cut along the inside of the nut. Figure 30: Cut the protective foil with the scalpel Figure 31: Cut the protective foil along the nut inner surface...
Page 30
Step 2: Insert the O-ring 1 into the nut of the air purge collar and repeat the steps in chapter 5.1 reverse. Make sure that the air purge collar is pressed against the adapter plate, when you tighten the screws again! Figure 33: Insert O-ring 1 in air purge collar Figure 32: Air purge collar...
