VERSION # 20-12-01
1 / 8
MODEL #
CM6514 VN
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM6514
Summary of Contents for Furniture of America CM6514
- Page 1 MODEL # CM6514 VN Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 8...
- Page 5 SOFA CM6514 VN #2 1pc #1 1pc #3 1pc Right Leg Chaise Left Sofa #5 3pcs #4 1pc Left Leg #A 11pcs # B 1pc Screw #8 x 45mm Power Line 5 / 8...
- Page 6 CM6514 VN is packed in 2 cases Disignation Part Hardware Carton Left Sofa CM6514 -1 #A x 11pcs Chaise #B x 1pc Right Leg CM6514 -2 Left Leg 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Remove parts from the hidden compartment of the chaise (#2). Part #2 x1pc Part #3 x1pc Part #4 x1pc Part #5 x3pcs Align corner legs (#3,4) and round legs (#5) to the chaise (#2) as shown in the image, then secure by using screws (#A). There will be no pre-drilled holes.
- Page 8 ASSEMBLY INSTRUCTIONS Align and hook the metal brackets of the chaise (#2), to the metal brackets of the left sofa (#1). Part # 1 x1pc Hardware # B x1pc Outlet Back 8 / 8...
