Furniture of America CM6514-VN Assembly Instructions

Download this manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM6514-VN

DIFFICULT

Tools Required For Assembly:

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 5

(Not Included)

Rev: 19-06-26

Need help?

Do you have a question about the CM6514-VN and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM6514-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Phillips Screwdriver easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 11pcs Left Sofa Screw #8 x 45mm #2 x 1pc Chaise #3 x 1pc Right Leg #4 x 1pc...
Page 4 Remove parts from the hidden compartment of the chaise (#2). Align corner legs (#3,4) and round legs (#5) to the chaise (#2) as shown in the image, then secure by using screws (#A). There will be no pre-drilled holes. #A x 11pcs Page 4 of 5...
Page 5 Align and hook the metal brackets of the chaise (#2), to the metal brackets of the left sofa (#1). Page 5 of 5...
