3 Way Mixer Tap
Under Bench Filtration Systems
Installation and
Operating Instructions
MTC-HF1M (Chrome finish)
HF1M
HF1M-R
and MTCM-HF1M (Matt finish)
High Flow Under
Replacement
3 Way Mixer Tap and Under
Bench Filtration Kit
Cartridge
Bench Filtration Systems
Tested in compliance with
for use in contact with safe drinking water
Warning: Microlene under bench system installation must be in compliance with
all local legislative requirements, and installed by a licensed plumber.
Please pass these instructions on to the operator of this equipment.
Advertisement
Table of Contents
Related Manuals for Microlene DAVEY MTC-HF1M
Summary of Contents for Microlene DAVEY MTC-HF1M
- Page 1 Tested in compliance with for use in contact with safe drinking water Warning: Microlene under bench system installation must be in compliance with all local legislative requirements, and installed by a licensed plumber. Please pass these instructions on to the operator of this equipment.
-
Page 2: Table Of Contents
Microlene makes it that easy. These instructions are also available in soft copy via email from Microlene Customer Service or on line at the Davey website: daveywater.com TABLE OF CONTENTS Specifications ..........................4... -
Page 3: Specifications
Water Quality Parameters The Microlene HF1M-R purification cartridge used in MTC-HF1M, MTCM-HF1M and HF1M is designed to purify and filter household drinking water only. The HF1M-R cartridge can be used on both mains water (sanitised) as well as rains water. -
Page 4: Kit Components
Carton One: Component Description Quantity Picture Mixer tap (chrome or matt finish as applicable) with three 1/2” flexible hoses Connector (1/2” male thread x G1/4” tube) Tap base ring - Stainless steel Washers (small & large) Plastic gasket Horseshoe sealing gasket... - Page 5 Retainer screw - long thread Retainer screw - brass nut Pressure limiting valve Connector to tube (filter x G1/4” tube) Smart Tee (T piece, isolating valve and back flow valve) Flexible plastic 1/4’ tubing (Total 2 metres)
- Page 6 Carton Two (or HF1M when sold separately): Component # Description Quantity Picture 1/2” Non return valve 1/2” braided hose 450mm long 1/2” MXF Brass adaptor Filter assembly including mounting bracket / connection head, cartridge and mounting screws 1/2” Brass nipple Instruction and Operating Instructions...
-
Page 7: Installation
Installation MTC-HF1M and MTCM-HF1M 3 Way Mixer Tap (carton one) with High Flow Under Bench Cartridge (carton two). General tap layout Purified Aerator water Purified outlet water Mixer handle handle Purified Cold water water water Mixer water handle 1. Raise the lever handle to turn on the water. Push down to stop. 2. - Page 8 Tap Base Ring (Item 3) Washer (item 4) Filtered Cold Fitted to Plastic gasket (item 1) (item 5) Horseshoe sealing gasket (item 6) Retainer screw Retainer screw nut...
- Page 9 Mixer Connector to tube (filter x G1/4” tube) (Item 10) Connector (1/2” male thread x G1/4” tube) (Item 2) Pressure Limiting Valve (item 9) Filter Cartridge (Item 16) Smart Tee (item 11) Cold Flexible plastic 1/4’ tubing (item 12)
- Page 10 3 & 4 NOTE: Where the filter assembly is required to be mounted further than directly below the sink additional lengths of item 14 (1/2” braided hose 450mm long) joined using item 17 ( 1/2” brass nipple) can be attached to the braided filtered water line and then to the mixer tap.
- Page 11 6. Using a flat head screwdriver tighten the Retainer Screws into the bottom of the 7. The tap fits through a 33mm diameter hole. Ensure the hole is correctly positioned to allow the tap to discharge into the sink correctly. 8.
- Page 12 Filter cartridge assembly and water supply 1. Connect the hot water hose (red band) to the hot water supply. 2. Fit the Smart Tee (Item 11) to the cold water supply using the brass adaptor (item 15). 3. Connect the cold water hose to the straight through outlet. Water to the filter will go out via the Smart Tee (Item 11).
-
Page 13: Way Mixer Tap And Under Bench Filtration Systems
Installation HF1M High Flow Under Bench Filtration System for plumbing into existing tap. Installation Procedures: NOTE: All male pipe threads must have adequate thread tape affixed for correct sealing. 1. Ensure all parts and tools required are ready for use. 2. -
Page 14: Replacing The Filtration Cartridge
Replacing The Filtration Cartridge (HF1M-R) Depending on the incoming water quality the filter cartridge will need periodic replacement. In any case, to maintain safe operation, a new cartridge should be installed when any of the following occur: • 6 months since installation or last cartridge change •... -
Page 15: System Troubleshooting
Pipework not correctly assembled + Review and/or reinstall pipework as required • Cartridge not installed correctly + Check sealing ring + Check cartridge is tightened into mounting bracket/connection head correctly If you are experiencing other issues contact your Microlene dealer for further advice. -
Page 16: Warranty
Davey Warranty Davey Water Products Pty Ltd (Davey) warrants all products sold will be (under normal use and service) free of defects in material and workmanship for a minimum period of one (1) year from the date of original purchase by the customer as marked on the invoice, for specific warranty periods for all Davey products visit daveywater.com.
