Housing Kits
Warranty Instructions
Housing kit only models: AS10A, AS10J & AS20J
Rainwater Solution – KAS10J and KAS20J
Mains Water Solution – KAS10JM and KAS20JM
DO NOT DISASSEMBLE ANY COMPONENTS UNTIL YOU HAVE FULLY READ
THESE INSTRUCTIONS. Unit is supplied fully assembled.
Installation on a flooded suction is recommended. Installation under vacuum is
not advised, any damage to persons or associated equipment will not be covered
under this guarantee.
Maximum operating pressure is identified overleaf. If the maximum pressure is
exceeded or if operating close to this pressure fit a suitable pressure limiting valve
before the filters.
WARNING: This system operates under pressure. Under no circumstances should
the system be disassembled unless the internal pressure of the unit has been
relieved. Failure to observe this warning will expose persons to the possibility of
personal injury and may result in damage to the product or other property.
This unit is designed to filter the cold water line at ambient temperatures
(0ºC to 50ºC).
The appliance is not intended for use by young children or infirm persons without
supervision. Young children should be supervised to ensure they do not play with
the appliance.
If installing on Australian Municipal water sources, a dual check valve and back
flow prevention device must be fitted prior to this system.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
FOR THE CORRECT OPERATING AND MAINTENANCE OF THIS PRODUCT,
IT IS ESSENTIAL TO OBSERVE THE MANUFACTURER'S INSTRUCTIONS
Please pass these instructions on to the operator of this equipment.
Twin Filter
Installation and
Supplied with filters models:
Advertisement
Table of Contents
Related Manuals for Microlene AS10A
Summary of Contents for Microlene AS10A
- Page 1 Twin Filter Housing Kits Installation and Warranty Instructions Housing kit only models: AS10A, AS10J & AS20J Supplied with filters models: Rainwater Solution – KAS10J and KAS20J Mains Water Solution – KAS10JM and KAS20JM DO NOT DISASSEMBLE ANY COMPONENTS UNTIL YOU HAVE FULLY READ THESE INSTRUCTIONS.
-
Page 2: Model Selection
Introduction Congratulations on your purchase of a high quality, Microlene Twin Filter Housing Kit. All components have been designed and manufactured to provide reliable operation. Model Selection Davey offer our Microlene Twin Filter Housing Kits with two purchasing options: KAS#J Models – Include preselected filters for treating harvested water, 20 micron for removal of dust and sediment, followed by 1 micron for finer sediment and cyst removal. -
Page 3: Specifications
Specifications 40 lpm (subject Dual to filter selection) Purchase 10” Standard 20mm (3/4”) to suit small AS10A Separately 0 - 880kPa 0° - 40°C 0° - 50°C Standard housing BSP Female unit, bungalow kit only or single point of use... -
Page 4: Special Notes
Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts. Filter must be protected against freezing, which can cause cracking of the filter and water leakage. -
Page 5: Mounting, Plumbing And Start-Up
Mounting, Plumbing and Start-up The 10” Standard unit (AS10A) has 20mm (3/4”) BSP female plumbing connections requiring 20mm (3/4”) BSP male plumbing. The 10” Jumbo and 20” Jumbo models (AS10J, KAS10J, KAS10JM, AS20J, KAS20J and KAS20JM) have 25mm (1”) BSP female plumbing connections requiring 25mm... -
Page 6: Sediment Cartridge Filter Life
Mounting holes Pressure Pressure Relief Valve Relief Valve Housing Top (cap/cover) Metal Bracket Housing Bowl (sump) Stage 1 Stage 2 Filter Housing Filter Housing *AS10J Pictured in above illustration. Sediment Cartridge Filter Life Once the housing is properly installed, a reduction in flow/pressure (to such an extent as to cause inconvenience) will indicate when the cartridge is becoming clogged and needs replacing/cleaning. -
Page 7: Filter Cartridge Replacement
Filter Cartridge Replacement A. Turn off water supply to filter. Depress blue pressure-relief button to release trapped air. B. Place a bucket or container under the housing if needing to protect surface underneath from any spilled water. C. Remove bottom of filter housing by turning clockwise (if required use spanner included with product upon initial purchase). - Page 8 Davey Warranty Davey Water Products Pty Ltd (Davey) warrants all products sold will be (under normal use and service) free of defects in material and workmanship for a minimum period of one (1) year from the date of original purchase by the customer as marked on the invoice, for specific warranty periods for all Davey products visit daveywater.com.
