BLUELIGHT SJT-WVF-V User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SJT-WVF-V Group Control User Manual
(Version 2018)
Shenyang Bluelight
2018.7.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJT-WVF-V and is the answer not in the manual?

Questions and answers

Related Manuals for BLUELIGHT SJT-WVF-V

Summary of Contents for BLUELIGHT SJT-WVF-V

  • Page 1 SJT-WVF-V Group Control User Manual (Version 2018) Shenyang Bluelight 2018.7.9...

  • Page 2: Table Of Contents

    SJT-WVF-V Elevator Group Control User Manual Table of Contents Chapter 1 Elevator Group Control System Introduction ..............2 On Duty Mode ............................2 Off Duty Mode ............................2 Balance Mode ............................. 2 Standby Mode ............................2 Chapter 2 Elevator Group Control System Description ..............3 LCD Keypad Operation Description ....................

  • Page 3: Chapter 1 Elevator Group Control System Introduction

    SJT-WVF-V Elevator Group Control User Manual Chapter 1 Elevator Group Control System Introduction The SJT-WVF5 Group Control System is composed of Group Control Card QKB2 and every distributed elevator main control board (BL-6 or BL-3 or BL-2000/3000.**). It is applying the serial communication network CAN centralize system to communicate with all elevator controller to exchange information.

  • Page 4: Chapter 2 Elevator Group Control System Description

    SJT-WVF-V Elevator Group Control User Manual Chapter 2 Elevator Group Control System Description 2.1 LCD Keypad Operation Description LCD Keypad has six keys, the arrangement and definition as below: - Elevator number Running direction A B C D E F G H...

  • Page 5: Lcd Display Flowchart And Description

    SJT-WVF-V Elevator Group Control User Manual 2.2 LCD Display Flowchart and Description A B C D E F G H -1 2 4 15 * * * * > Enter Enter Balance mode Elevator state Elevator state Input Password Sys: Ok...

  • Page 6: Lcd Display Main Menu Description

    SJT-WVF-V Elevator Group Control User Manual 2.3 LCD Display Main Menu Description Running direction Elevator number AB C D E F G H -1 2 3 4 G * 19 * Actual floor number A, B, C, D, E, F, G and H are representing the eight elevator numbers; the arrow beside it is indicating the elevator running direction;...

  • Page 7: Each Elevator Status And Description

    SJT-WVF-V Elevator Group Control User Manual 2.5 Each Elevator Status and Description Enter Enter Elevator State Elevator State  A01 A02 A03 Enter A-Enter A04 A05    A08 A09    A12 A13    Elevator State H-Enter A16...

  • Page 8: Password Setting

    SJT-WVF-V Elevator Group Control User Manual 2.7 Password Setting Password (User Level or Factory Level) must be correctly entered in order to enter into Parameter Setting menu. Input Password 0000 Enter In the Input Password menu, use “Λ” key to increase the number, or “V” key to decrease the number, use “>” key to scroll the desired password position.

  • Page 9: Change Password

    SJT-WVF-V Elevator Group Control User Manual 2.9 Change Password It is for changing and setting new User Password. Enter New Password New Password Enter 0 0 0 0 2.10 General Parameter Settings 2.10.1 Group able set Enter Group able set...
  • Page 10 SJT-WVF-V Elevator Group Control User Manual 2.10.3 Mode Select Enter Mode Select Mode Select Enter Mode 0: Yes/No Mode Select Mode 1: Yes/No Mode Select Mode 2: Yes/No Mode 0 : spare, not used. Mode 1 : On Duty Mode; if “Yes”, during the preset “On Duty” time, the Group system will enter the On Duty Mode.
  • Page 11 SJT-WVF-V Elevator Group Control User Manual 2.10.5 Set On Duty Time / Off Duty Time S Start Time Start time for On Duty Mode 08:20 S Stop Time Stop time for On Duty Mode 09:20 X Start Time Start time for Off Duty Mode...
  • Page 12 SJT-WVF-V Elevator Group Control User Manual 2.10.6 Set Non-Stop Floor Enter General Para A: Stop Floor Enter Enter B: Stop Floor Enter C: Stop Floor Enter H: Stop Floor Enter If there is any non-stop floors setting required in the Group control system, the non-stop floor setting in every main control board must be similar to the setting in Group control system.
  • Page 13 SJT-WVF-V Elevator Group Control User Manual Enter A: Stop Floor A: Stop Floor Enter 01: ON / OFF A: Stop Floor 02: ON / OFF A: Stop Floor 03: ON / OFF A: Stop Floor 64: ON / OFF 2.10.7 Set Homing Floor This function is available for software version 706_12 and higher versions.

  • Page 14: Setting Requirement For Group Control Versus Elevator Numbers (A, B, C

    SJT-WVF-V Elevator Group Control User Manual When the setting of Homing Floor is not “0”, the elevator will be distributed to the designated floor when it is idle for 5 minutes. Remarks: If Group control Homing Floor is not utilized (all set to “0”), the Group control system will distribute the elevators to average region for waiting calls.

  • Page 15: Appendix 1Group Control And Main Control Board System Block Diagram

    SJT-WVF-V Elevator Group Control User Manual Appendix 1Group Control and Main Control Board System Block Diagram Appendix 2Group Control Board Dimensions Shenyang Bluelight Page 14 Ver. 2007...

  • Page 16: Group Control Manual: Additional Description (2007-4-7)

    SJT-WVF-V Elevator Group Control User Manual Group Control Manual: Additional Description (2007-4-7) In case of Group control, the terminal resistor of main control board for group control communication must be removed except the Group control card QK-1 and the furthest Main control board. See below diagrams:-...
