- Page 1 Operating manual FLOCK Checker P a r t . N o . : 8 1 0 5 2 3...
-
Page 2: Table Of Contents
1.4. Nameplate 1.5. Warranty 1.6. Manufacturer Guide to these operating instructions Intended use Structure and overview 4.1 Structure of the FLOCK Checker Functional description 5.1. Commissioning 5.2. Display 5.3. Performing measurements 5.4. Charging the FLOCK Checker Menu and further functions 6.1. -
Page 3: Product And Manufacturer
The FLOCK Checker is a measuring device for determining the conductivity of flock fibers. To ensure high-quality flocking, the conductivity of the flock fibers used plays a major role. You can measure this easily and precisely with our FLOCK Checker and thus offer con- sistent quality of your flocked parts. -
Page 4: Warranty
Only with knowledge of these operating instructions errors can be avoided and safe and trouble-free operation be ensured. SCHNIER Elektrostatik GmbH does not accept any liability for damage resulting from non- observance of these operating instructions! 3. -
Page 5: Structure And Overview
4. Structure and overview 4.1 Structure of the FLOCK Checker 1 Electrode 2 Display 3 (I)-Button 4 Reset- / Save-Button 5 Cover charging socket 6 POAG Plug for grounding Operating manual 810523-BAL-EN-220609 Status 06.09.2022 Seite 5 von 12... -
Page 6: Functional Description
• The unit starts up and performs a self-test. • As soon as the value "0" is shown in the display [2], the FLOCK Checker is ready for measurement. The attachment electrode [1] must always be clean and dry. Mo- isture and impurities falsify the measurement result. -
Page 7: Display
5.2. Display 1 Battery indication and time 2 Current measured value 3 Maximum measured value 4 Number of stored measured values Operating manual 810523-BAL-EN-220609 Status 06.09.2022 Seite 7 von 12... -
Page 8: Performing Measurements
Before measuring, please remove the protective cap from the electrode. • Commissioning according to 5.1 • Dip the electrode of the FLOCK Checker into the flock to be measured and loosen it slightly. • Now press the electrode firmly onto the flock with constant pressure. -
Page 9: Menu And Further Functions
6. Menu and further functions To access the menu, briefly press the (I) button [3] upwards. By pressing the (I) button upwards, you can scroll through the menu items. To select an entry, press the (I) button [3] downwards. You can select from the following: 6.1. -
Page 10: Settings
(I) button upwards and confirm by pressing the (I) button down- wards. 6.6. Calibration This entry is protected with a password and is used exclusively for calibration by SCHNIER Elektrostatik GmbH. Operating manual 810523-BAL-EN-220609 Status 06.09.2022 Seite 10 von 12... -
Page 11: Error
This message means that the measured value is higher than 125 standard scale division [Nrm]. Simply delete it again by pressing the (I) button downwards. You can then carry out a new measurement. 8. Scope of delivery • FLOCK Checker • Attachment electrode with protective cover • Sturdy carrying case •... -
Page 12: Declaration Of Conformity
SCHNIER Elektrostatik GmbH Bayernstrasse 13 D-72768 Reutlingen Product: Measuring device Type: Conductivity meter SCHNIER Part.-No.: FLOCK Checker Part-No. 810523 Handelsbezeichnung: FLOCK Checker Function: Measuring instrument for determining the conductivity of flock fibers. DIN 54345-1:1992-02 Testing of textiles; Electrostatic behavior; Determination of electrical resistance quantities Rommelsbach 06.09.2022...
