- Page 1 Kirk Bedside Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 10/05/22...
- Page 2 Safety and Care Advice Product Details Kirk 1 DRW Bedside 3205912 Walnut Kirk 1 DRW Bedside 6793775 Oak IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Keep children and animals Assemble the item as close We do not to its final position (in the same away from the work area, small recommend the room) as possible.
- Page 3 Fittings (Shown to scale) Bag 1 32mm Metal Dowel x16 Locking Nut x16 30mm Wooden Dowel x10 35mm Screw x4 30mm Screw x1 25mm Handle x1 Ø15mm Foot Pad x 4...
-
Page 4: Tools Required
Tools required Phillips screwdriver (small & medium) Phillips screwdriver (small & medium) - Page 5 Panels Side Panel x2 (380 x 144mm) Top Panel x1 Drawer Front x1 (450 x 400mm) (448 x 138mm) Right Side Drawer x1 Left Side Drawer x1 (350 x 130mm) (350 x 130mm) Bottom Panel x1 Drawer Back x1 (450 x 400mm) (362 x 130mm) Back Panel x1 (422 x 154mm)
- Page 6 32mm Metal Dowel x16 Locking Nut x16 30mm Wooden Dowel x10 32mm Metal Dowel x16 35mm Screw x4 30mm Screw x1 25mm Handle x1 30mm Wooden Dowel x10 Ø15mm Foot Pad x 4 Peel off the back Ø15mm Foot Pad x 4 2 x2...
- Page 7 Locking Nut x 6...
- Page 8 Locking Nut x 6 Locking Nut x 4...
- Page 9 30mm Screw x1 35mm Screw x4 25mm Handle x1...
- Page 10 Assembly is complete.
