  • Page 1 Please read this manual before operating your units and keep it for future reference. VRinsight Virtual Reality Insight All stated here is subject to change without advanced notice for improvement. Tel : +82-31-284-7090~91 Fax : +82-31-284-7092 E-mail : tech@vrinsight.com Web site : www.vrinsight.com...
  • Page 2 This manual has been written out on a basis. μ- All software (& software versions) stated here is subject to change without advanced notice for improvement. If you want to download the latest driver version for panel & application programs, visit www.vrinsight.com...
  • Page 3 μ- VRinsight of VRinsight is a portable control and screen system for propel type aircraft. μ- All the gauges, buttons and knobs are displaying synchronized with Microsoft’s Flight Simulator propeller aircraft and most add-ons propeller aircrafts. Real knobs and push buttons provide the user an ultimately realistic flight experience with instant setup.
  • Page 4 Features • AIRSPEED indicator • ARTIFICIAL HORIZON with setting rotary knob • ALTIMETER with BARO setting rotary knob • TURN COORDINATOR • HEADING indicator with heading bug and gyro rotary knob • VERTICAL SPEED indicator • VOR1 indicator with OBS rotary knob •...

  • Page 5: Before Use

    “VRinsight HTML” document will be shown. Then click “VRiSim” (operating software) and install it at a proper folder. “VRiSim” is the main operating software of VRinsight used for all VRinsight flight panels. VRiSim software supports all functions of and completely interfaced with MSFS9 μ-...

  • Page 6: Monitor Setting

    Monitor setting 1. Check the current display properties in order that another sub monitor is connected or not. (See “Settings”) 2. Connect video cable of μ- to your computer. 3. Connect AC/DC adaptor to your μ- μ- 4. Check the display property in order that monitor is detected or not.
  • Page 7 * If the monitor (=Monitor 2) isn’t detected, check the connection of μ- video cable & AC/DC adaptor. * If your OS is VISTA, please restart your computer. 5. When the μ- monitor is recognized, click monitor 2(= μ- monitor). monitor.
  • Page 8 11-A-2. Go to “Set up multiple displays and check “Configured independently from each other (Dualview). Then the monitor of μ- will independently display your “Desktop” view.
  • Page 9 11-B. ATI 10-B-1. Launch “Catalyst(TM) Control Center”. The monitor of will automatically display your “Desktop” view. μ- 11-B-2. Go to “Displays Properties” and select monitor 2.
  • Page 10 Controls & Displays for each part Controllable gauges : VOR1, VOR2, HDG, ALT, Altitude indicator and Heading indicator Gauges display: Airspeed indicator, Turn coordinator, Altitude, Vertical speed. Programmable 2-position switch : Default functions are Trim & Flap up/down...
  • Page 11 Software Installation Driver and application software “VRiSim” is installed to make u-ProPit work in the PC. VRiSim is application software managing VRInsight's flight simulation hardware panels. Multiple hardware panels can be used with single instance of VRiSim. To reduce distributing file size, software installer is supplied as divided package;...
  • Page 12 Select Aircraft Open device’s tab to select “Aircraft”. Fly Now! As the aircrafts are specified to fly with VRi’s unit, press “Fly Now!” button. Remember that Flight Simulator should be running and you are in-cockpit before pressing this button. Otherwise, you will see following message.

  • Page 13: Before Flight

    μ- Preparing before Flight Step 1 : Initial check up Before flight with , please check the followings are done μ- A. Install of VRiSim. * Check that “Install USB-Serial Driver” is checked or not. Confirm that proper version of FSUIPC is installed or not (FSUIPC v3.80 or later for FS9 / FSUIPC v4.26 or later for FSX) C.
  • Page 14 Step 3 : Run panel linking application software “VRiSim”. Step 4 : Undock “Main Panel(uProPit)” window. Place the cursor on the Main Panel(uProPit) and press right button to undock If you can’t see the Main Panel(uProPit), configure it with “Panel Installer”.
  • Page 15 μ- Step 5. Press “Fly Now” to move the undocked Main Panel(uProPit) display to Step 6. Input the X & Y position of monitor and press “Redraw” μ- * For instance, If X & Y position is same as page 7, Put X=1680, Y=0.
  • Page 16 μ- Step 8. Confirm the Main Panel(uProPit) display has been moved to . . Then press “Save” for future purpose. With “Panel Config” window, you can adjust position and size of the display. See how to control them. X, Y X, Y Current position of gauges display window Current position of gauges display window...
