M80 & M83 SERIES RECTANGULAR CONNECTORS
SECTION
TITLE
1
Description of Connectors and Intended Applications
2
Marking of Connector and/or Package
3
Ratings
Appendix 1
Contact Orientations
Appendix 2
Coax Contact Details
Appendix 3
Gauges (Low Frequency)
Appendix 4
Test for Latch Integrity
Appendix 5
Instructions for the use of connectors fitted with Jackscrews
Appendix 6
Instructions for the use of
PREPARED BY:..........Matthew Perren ............
APPROVED BY:...........Mark Plested ..............
MAY 2015
Jackscrews
C0052
C0052
C0052
C00526 6 6 6
PAGE
2
2
3
7
10
12
13
14
15
Sheet:
1 of 15
Issue:
26
Date:
13.05.2015
C/Note:
12824

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M80 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Datamate M80 Series

  • Page 1 C0052 C0052 C0052 C00526 6 6 6 M80 & M83 SERIES RECTANGULAR CONNECTORS MAY 2015 SECTION TITLE PAGE Description of Connectors and Intended Applications Marking of Connector and/or Package Ratings Appendix 1 Contact Orientations Appendix 2 Coax Contact Details Appendix 3 Gauges (Low Frequency) Appendix 4 Test for Latch Integrity...

  • Page 2: Order Code

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 1. DESCRIPTION OF CONNECTOR AND INTENDED APPLICATION A range of 2mm pitch male and female rectangular, fully shrouded unsealed connectors with replaceable contacts for interconnecting board to board, cable to board and cable to cable. The range covers 2 to 50 ways, in various application methods.
  • Page 3 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 2.1. FINISH CODES (CONTINUED) 2.1.2. Contact Finish: Finish Code Finish Code Finish Code Finish Code 01 01 01 01 05 05 22 22 22 22 42 42 42 42 Gold on Contact area Gold on Contact area Gold all over Male PC Tail Tin /Lead on tail...
  • Page 4 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 3. RATINGS (continued) 3.1.2. Environmental characteristics (continued) Acceleration severity ....................... 490m/s² (50G) *The connector will function correctly using a simultaneous combination of high temperature and low air pressure down to 300mbar (Altitude of 9,144M/30,000ft) up to 360V DC. 3.1.3.

  • Page 5: Power Contacts

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 3. RATINGS (continued) 3.2. COAX CONTACTS (continued) V.S.W.R. (Voltage Standing Wave Ratio) ..........1.05 + (0.04 x Frequency) GHz max Operating Voltage (at 1013mbar, sea level) ..............180V AC at 500mA Maximum Voltage (at 1013mbar, sea level) ..............1,000V AC rms Contact Resistance........................
  • Page 6 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 Insertion force M80-PXX contacts ..................15.0N max Withdrawal force ........................0.5N min Contact wipe ........................... 1.30mm min Contact replacement in moulding ..................5 times max 3.4. SOLDERING DATA Solderability (for PC Tail & SMT product)…………………………………………………………..245°C for 5 seconds Soldering heat resistance (for SMT products only)…………………………………………….…260°C for 10 seconds - 6 -...

  • Page 7: Appendix 1 - Contact Orientations

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 1 – CONTACT ORIENTATIONS These diagrams show pin numbers with reference to the polarisation feature. They represent male connectors, shown looking onto the contact face. A1.1. SINGLE ROW 2-way 3-way 4-way 5-way 6-way 7-way 17-way Polarising Key...
  • Page 8 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 1 – CONTACT ORIENTATIONS (continued) These diagrams show pin numbers with reference to the polarisation feature. They represent male connectors, shown looking onto the contact face. A1.3. DOUBLE ROW 14-way 6-way 10-way 20-way 26-way 34-way 42-way...
  • Page 9 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 1 – CONTACT ORIENTATIONS (continued) These diagrams show pin numbers with reference to the polarisation feature. They represent male connectors, shown looking onto the contact face. A1.5 3 ROW All signal contacts only A1.6.

  • Page 10: Appendix 2 - Coax Contact Details

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 2 – COAX CONTACT DETAILS A2.1. COAX INTERFACE DIMENSIONS Male Female A2.2. COAX ASSEMBLY INSTRUCTIONS – M80-305/306/307, M80-315/316/317 1) Strip cable to dimensions shown against relevant part (see appropriate engineering drawings). Outer Insulator Braid Inner Insulator Inner Conductor...
  • Page 11 COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 2 – COAX CONTACT DETAILS (continued). A2.3. COAX ASSEMBLY INSTRUCTIONS – M80-308/309, M80-318/319. 1) Strip cable to dimensions shown against relevant part (see appropriate engineering drawings). Outer Insulator Braid Inner Insulator Inner Conductor 2) Identify pieces of coax connector to be assembled.

  • Page 12: Appendix 3 - Gauges (Low Frequency)

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 3 – GAUGES (LOW FREQUENCY) NOTES: Material = Steel to BS1407 or equivalent. Gauging surfaces to be hardened/ground to 650 H.V.5 minimum. These gauges to be used for testing fully assembled components only. Ultimate wear limit of 0.005mm is allowable on gauging diameters.

  • Page 13: Appendix 4 - Test For Latch Integrity

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 4 – TEST FOR LATCH INTEGRITY A4.1. LATCH INTEGRITY GAUGE Dim ‘A’ Remove all burrs and sharp edges ‘A’ and ‘B’ stamped in positions shown Dim ‘B’ No. of contacts No. of contacts No.

  • Page 14: Appendix 5 - Instructions For The Use Of Connectors Fitted With Jackscrews

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 5 – INSTRUCTIONS FOR THE USE OF CONNECTORS FITTED WITH JACKSCREWS Connectors are fitted with jackscrews where it is considered necessary to provide mechanical assistance in ensuring a satisfactory engagement and separation of the connector. This may apply in cases where engagement and separation forces are so high as to prevent satisfactory hand engagement, or where access to connector is restricted.

  • Page 15: Appendix 6 - Instructions For The Use Of

    COMPONENT SPECIFICATION C00525 C00525 C00525 C00525 APPENDIX 6 – INSTRUCTIONS FOR THE USE OF JACKSCREWS 1. Before engaging, the slot on the jackscrew should be at right angles to the length of the connector. 2. Push the connectors together. Once the connectors are mated, use a screwdriver to push down onto each 101Lok Jackscrew until the spring is compressed.
