Please read this instruction carefully for correct use of the product and preserve it for reference purposes. Thank you for purchasing our product. There may be several technically incorrect places or printing errors in this manual. The updates will be added into the new version of this manual.
1 Introduction 1.1 Introduction This network keyboard is fully compatible with the NVMS/CMS of our company, which can control camera, screen, monitor, etc. It’s easy to use for users due to the menu display on the screen. 1.2 Rear Panel Instructions Name Description When the network keyboard is working, the power indicator...
Introduction 1.3 Front Panel Instructions Name Functions SETUP Local setup, such as keyboard ID, network setup. Local information, such as ID, model, network parameters. INFO SHIFT Auxiliary key for main interface shift or PTZ shift or security questions shift. Lock keyboard; press this key to lock the keyboard. LOCK Set the output (monitor).
Introduction MACRO Macro function key; set and call macro instructions. ALARM Set the first image of the current output as an alarm large image. Input the number/ alphabet /symbol. Cancel the number/alphabet; cancel the operation; return to the previous menu. Enter menu or confirm to save the current settings.
Introduction 1.5 Joystick Control Figure Operation Function In PTZ control mode: control the speed dome to move up. In PTZ control mode: control the speed dome Down to move down. In PTZ control mode: control the speed dome Left to move left. In PTZ control mode: control the speed dome Right to move right.
2 Setup 2.1 Startup the Keyboard First connect the network cable to the keyboard and then connect the power. After the device starts, please input the default password (8888) and then press “Enter” key to go to main interface (see left figure). Press “Setup” key to go to the system setup menu (see right two figures).
Setup 2.2.2 Keypad ID Setup Select the keypad ID setup menu and press “Enter” key to go to keypad ID setup. The effective value of the ID is from 1 to 32. To set keypad ID, press digital number and enter key (eg. press 32 and then press “Enter” to set the keypad ID at 32).
Setup Alternate server: the default alternate server is 4.4.4.4. Please input it according to the actual network. HTTP port: the default http port is 4000. Please input it according to the actual network. PLAT IP Setup Select “PLAT IP setup” and press “Enter” to set the PLAT IP address. IP address: input the IP address of the TV Wall Client of the ECMS/NVMS 5000.
Setup 2.5 Test Select it and press “Enter” to test if the button is available. User can also check if the silk-screen on the button and display on the screen is consistent which is not use for operating equipment.
3 PTZ Mode 3.1 Mode Setup Platform mode and PTZ mode are optional. Select PTZ mode and press “Enter” to select. Some models may connect 256 PTZs and control PTZs which support ONVIF. Tips: Some models support a default mode (platform mode or PTZ mode), namely it will restore to the last working mode after restart.
PTZ Mode 3.4 PTZ Shift Some models support shifting the PTZs by pressing “Number plus SHIFT”. Select other PTZ and setup the IP address, port, name and password. Please see 3.2 PTZ IP Setup for more details. Press “SHIFT” to switch the PTZs of which the IP address is setup well.
4 Decoding Before using the network keyboard to control video output of the decoder, please make sure the authentication server, media transfer server, storage server, alarm server and TV wall server of the ECMS/NVMS5000 all starts and they are all connected well with the decoder. Note: Here we only take platform mode as example.
Decoding As a result, you will see the image of NO.3 camera in NO.3 window and 4 screens display mode will be seen in NO.1 monitor. You can check the relationship between camera number and channel from ECMS/NVMS5000 (go to TV wall client -> Setup -> Channel-NO. mapping). Note: The effective value of the camera is form 1 to 999999.
Decoding 1. Select monitor (output). For example, input 1 and then press “MON” to select NO.1 monitor. 2. Select screen display mode. For example, input 4 and then press “MULT” to select 4 screens display mode. 3. Select camera group. For example, input 2 and press “CAM-G” to select NO. 2 camera group. 4.5 Call Layout You may set the input or output scheme in advance and then call it through network keyboard.
Decoding Input digital number and then press “MACRO” to call NO. 2 macro instruction. Moving the joystick down can display all information of this macro instruction. Press “ESC” key of the keyboard to return to the main menu of the keyboard. 4.7 Alarm Window Setup You can set the designated window as an alarm window.
Decoding Note: The camera input to the above example of NO. 3 window must be a PTZ device (or speed dome), or the calling is invalid. The effective value of the preset is from 1 to 255. The effective value of the cruise is from 1 to 8 and. The effective value of track is from 1 to 4. If the calling number is beyond the range, an invalid tip will be displayed on the screen.
Decoding To stop cruise/track 1. Select the output. For example, input 1 and press “MON”. 2. Select the window. For example, input 3 and press “WIN”. 3. Select the cruise/track. For example, input 0 and press “CRUISE/TRACK” or press “CRUISE/TRACK” directly. 4.8.4 Focus +/- To set focus +/- 1.
Decoding 4.8.7 Start or Stop Auto Scan To start or stop auto scan 1. Select the output. For example, input 1 and press “MON”. 2. Select the window. For example, input 3 and press “WIN”. 3. Press “AUTO” to start auto scan; press “AUTO” again to stop auto scan. 4.8.8 Enable/Disable Light To enable or disable light 1.
Decoding 4.9 Record Playback 4.9.1 Start Playback You can play back the record saved in the storage server of the ECMS/NVMS1000. To play the record 1. Select the output. For example, input 1 and press “MON”. 2. Select the window. For example, input 3 and press “WIN”. 3.
5 Others 5.1 View Information You may check the keyboard, model, SN, current mode, version, date, local IP, subnet mask and so on by pressing “INFO” key on the keyboard. Check the next page of the information by moving the joystick down. 5.2 Lock You can lock the keyboard by pressing “LOCK”...
6 Web 6.1 Web Access In order to view the keyboard from a network it may be connected to a LAN or internet. The net- work setup should be done accordingly. ① The keyboard shall be powered on and connected to the network. Please see 2.5 Local IP Setup for details.
6.2 Upgrade Get the software from your vendor when there is a new software version. 1. Click “Browse” button to select the save path of the upgrade file. 2. Click “Upgrade server firmware” to start upgrading the application program. 3. After successfully update the software, the device will restart automatically. Notice: You can’t disconnect to PC or close the keyboard during upgrade.
Network Keyboard Quick Start Guide 7 Specifications Local Display Local Joystick Four-dimensional Four functional areas RJ45 10/100M×1 Network Control Mode Platform mode/ PTZ mode RS485 RS485 ×1 Serial Port Baudrate 1200bps, 2400bps, 4800bps, 9600bps, 19200bps Power DC12V Power Consumption ≤8W Working Temperature -10°C~ +60°C Others...
Appendix Digital number/ alphabet input rules are listed in the following table. The relationship between the frequency of key-press and input display three seven eight nine four five once twice times times times times times times times blank...
