- Page 1 NK500-A1 MANUAL NETWORK KEYBOARD...
- Page 2 Safety Instruction These instructions are intended to ensure that users can use the product correctly to avoid danger or property loss. The precaution measures are divided into “Warnings” and “Cautions” Warnings: Serious injury or death may be caused if any of these warnings is neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
- Page 3 EU Conformity Statement 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
-
Page 4: Table Of Contents
Table of Contents Chapter 1 Product Introduction ....................1 1.1 Introduction ............................1 1.2 Product Key Functions ......................... 1 1.3 Appearance ............................ 2 1.4 Operation Panel..........................3 1.5 Keyboard Joystick ........................4 1.6 Keyboard Shuttle .......................... 5 Chapter 2 Operation Guide ......................6 2.1 User Account .......................... -
Page 5: Chapter 1 Product Introduction
Chapter 1 Product Introduction 1.1 Introduction AVYCON Network Keyboard AVK-NK500-A1 is positioned to control PTZ Cameras. It adopts a network connection for easy connection and control, eliminating unwanted complexity and simplifying the overall installation process. Built-in Web Servers can support the use of a browser to manage and maintain the keyboard easily. -
Page 6: Appearance
Product Introduction 1.3 Appearance Figure 1.3-1 AVYCON Network Keyboard Operation Panel Figure 1.3-2 AVYCON Network Keyboard Interfaces... -
Page 7: Operation Panel
Product Introduction 1.4 Operation Panel Description of Functional Buttons Button Description 1) Return to previous menu. 2) Long press 10s to reset all settings to factory deault. Long press 2s to enter keyboard settings interface. Note: Only admin user has the permission. Lock/Unlock the keyboard. -
Page 8: Keyboard Joystick
Product Introduction 0-9/A-Z Number input or letter input. Dot. Confirm operation. ENTER PRESET In PTZ mode, select or set the preset. PATROL In PTZ mode, select the patrol. PATTERN In PTZ mode, select the pattern. Call the defined Preset, Patrol and Pattern in PTZ mode. CALL/STOP Stop the Patrol and Pattern operation in PTZ mode. -
Page 9: Keyboard Shuttle
Product Introduction 1) In PTZ mode, control the PTZ to move right. Right 2) In PTZ playback interface, video rewind 30s. Left up/Left down/ In PTZ mode, control the PTZ to move Left up/Left down/Right Right up/Right down up/Right down. In PTZ mode, Zoom in. -
Page 10: Chapter 2 Operation Guide
Chapter 2 Operation Guide 2.1 User Account There are two types of keyboard user account: admin and operator. The admin user is authorized with the following operation permissions: Add a maximum of 9 operator accounts. Configure the keyboard parameters. Add, edit and delete devices. Add, edit and delete operator users. -
Page 11: Shut Down
Operation Guide Note: 1. The default user name and password of the Network Keyboard is admin and 1234. 2. Inputting the user name is not compulsory for the keyboard. Just input the password of the user, the Network Keyboard will automatically distinguish the password belongs to which user. 3. - Page 12 Operation Guide Network Figure 2.3.2-2 Network Interface There are two options (NET MODE/CURRENT IP) in Network Interface: NET MODE: STATIC or DHCP is available for you to set up a local IP address for the keyboard. After configuring, the keyboard will prompt “REBOOT NOW?”. Then confirm the reboot operation, the setting will take effect;...
- Page 13 Operation Guide System Figure 2.3.2-4 System Interface There are five options (SOUND/BACK LIGHT/LANGUAGE/PASSWORD/DEFAULT) in SYSTEM interface: SOUND: Sway joystick to the left and right to turn on or turn off the keypad tones, then press [ENTER] button to confirm and save the setting. BACK LIGHT: Sway joystick to the left and right to select the retention time of screen back light, then press [ENTER] button to confirm and save the setting.
-
Page 14: Keyboard Operation
Operation Guide 2.4 Keyboard Operation After adding the devices, you can use the keyboard to control all devices you added. 2.4.1 Device Connection ID: Device number. Step 1. Press the [ID] button, then input the ID number of the device you want to connect. Figure 2.4.1-1 Step 2. -
Page 15: Ptz Control
Operation Guide Figure 2.4.1-3 NVR Mode 2.4.2 PTZ Control The keyboard can operate the PTZ via the joystick and PTZ function buttons. PTZ Cameras Network Keyboard PTZ Cameras Figure 2.4.2-1 PTZ Control Press the [SHIFT] button to select the PTZ mode: Figure 2.4.2-2 PTZ Mode... - Page 16 Operation Guide PRESET Setting : PRESET+Num+ENTER Delete : DEL+PRESET+Num+ENTER Call : CALL+PRESET+Num+ENTER PATROL Call : CALL+PATROL+Num+ENTER Pause : STOP PATTERN Call : CALL+PATTERN+NUM+ENTER Pause : STOP Through the [ZOOM+], [ZOOM-], [FOCUS+], [FOCUS-], [IRIS+], [IRIS-] buttons, you can adjust the lens of the PTZ camera. Note: 1.
-
Page 17: Chapter 3 Keyboard Configuration By Web Server
Chapter 3 Keyboard Configuration by WEB Server 3.1 Login Figure 3.1-1 WEB Login Page Step 1. Input the IP address of keyboard in browser. Step 2. Input the password of admin user to login. 3.2 Device Management Figure 3.2-1 WEB Device Management... - Page 18 Keyboard Configuration by WEB Server Add Devices Method 1. Add devices via searching function 1. Click [Search] button to quickly search the devices in LAN. Figure 3.2-2 Search Device 2. Click to select one device, then click [Add] button to add the selected device. Figure 3.2-3 Add One Device...
- Page 19 Keyboard Configuration by WEB Server Click [Add All] button to add all the devices which have been searched out. Figure 3.2-4 Add All Devices 3. Click [Save] button to confirm the operations you have done. Method 2. Add devices manually 1.
-
Page 20: Keyboard Management
Keyboard Configuration by WEB Server Configure Added Devices Click the [Delete] button to delete an added device. Click the [Del All] button to delete all devices which have been added. Click the [Sort] button to sort the devices which have been added by ID number, Device type, and IP address. - Page 21 Keyboard Configuration by WEB Server User Figure 3.3-2 User On the Users page, you can add, edit and delete operator users; Also, you can edit the password of the Admin user. Hardware Figure 3.3-3 Hardware On the Hardware page, you can turn on/off the keypad tones. Also, you can select the retention time of the screen backlight.
- Page 22 Keyboard Configuration by WEB Server System Figure 3.3-4 System All information about the MAC address and software version of the keyboard can be checked on this page. Click Reboot to reboot the keyboard. Click Reset to reset keyboard to factory defaults. System Upgrade: Step 1.
-
Page 23: Chapter 4 Services
Chapter 4 Services AVYCON, provides customers with timely and comprehensive technical support services. End-users can contact your local dealer to obtain technical support. Distributors and resellers can contact directly with AVYCON for technical support. U.S. Headquarters 16682 Millikan Ave, Irvine, CA 92606 Tel: 949.752.7606... - Page 24 Copyright © AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...
