BUILT-IN BEER DISPENSER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND
OPERATING INSTRUCTIONS.
Keep proof of original sales date (such as your sales slip) with this
manual to establish the warranty period.
Write the Serial Number here. You'll find it on a plate located either
on the back of the appliance or on an interior wall.
_____________________________________
SBC635MBI Series
Use and Care Guide
0
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit SBC635MBIIF
Summary of Contents for Summit SBC635MBIIF
- Page 1 BUILT-IN BEER DISPENSER SBC635MBI Series Use and Care Guide BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Keep proof of original sales date (such as your sales slip) with this manual to establish the warranty period. Write the Serial Number here.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS WARNING! To reduce the risk of fire, electric shock or injury when using this appliance, follow these basic precautions: 1. Read all instructions before using the appliance. 2. The appliance must be correctly connected to the power supply. 3. - Page 3 7. The beer dispenser requires an AC power supply of 110~120V/60Hz and pulls a current of over 10A. The fuse or circuit breaker should be rated at 15A. 8. If the leakage of a combustible gas is detected, turn off the gas valve and open the doors and windows.
-
Page 4: Location Of Parts
LOCATION OF PARTS Beer tower assembly Upper cover guardrail Collar Drip tray Top cover Display and control panel Cabinet Evaporator regulator valve Ball valve gas cylinder Beer keg tank supporter Control board device Door Compressor chamber cover Bottom pad Leveling leg BEFORE USING FOR THE FIRST TIME The SBC635MBI is designed for dispensing beer only, and is not recommended for storing perishable foods such as meats or dairy products. -
Page 5: Placement And Installation
PLACEMENT AND INSTALLATION Choosing the Right Place To ensure that your beer dispenser works at the maximum efficiency it was designed for, install it in a location where there are proper air circulation and electrical connections. Choose a location where the beer dispenser will be away from any heat sources and will not be exposed to direct sunlight. - Page 6 Reversing the Door Swing (select units only) Figure 1 (Default position) Figure 2 (After door reversal) 1. Upper hinge cover 6. Screws 2. Screws 7. Hole cover 3. Upper hinge 8. Cabinet 4. Door 9. Pin cap 5. Lower door hinge Depending on your door finish, the beer dispenser can be opened from either the right side or the left.
- Page 7 Installing the Beer Dispenser as a Built-In Unit This beer dispenser is designed to be built in under your counter. Simply follow the steps below for a quick and easy installation. NOTE: Not all models have built-in capability. Only models with letters BI are built-in compatible.
- Page 8 Instructions for Building-In Find the mid-point: From left to right the width is about 24¼". From back to front, the dimension is about 25⅜". Therefore the mid-point is located wherever these coordinates cross each other. Use a pencil or marker to note this spot. Note: 12⅛...
- Page 9 Installation of Accessories Diagram of overall structure Collar Drip tray Soft red CO tube Beer keg handle Beer keg Leveling legs or Universal wheels Installation components Tap handle Draft beer tap tank bracket and bolt Drip tray assembly hose clamp Installation steps 1.
- Page 10 wheels will keep the unit from moving if you step on the foot brakes (See Figure 2): 2. Install the beer tower assembly and the mixed ball valve: a) Plug the beer tower assembly into the top cover of the beer dispenser: 3.0”...
- Page 11 d) Place the CO tank and CO regulator valve component into the cabinet and fix the CO tank with tank bracket and bolt (See Figure 8). 4. Install the beer keg: Place the beer keg into the cabinet and firmly connect the keg’s opening to the connection port of the mixed ball valve (See Figure 10).
-
Page 12: Operation
OPERATION Control Panel The control panel is located just above the door, and looks like this: DOWN: Lowers UP: Raises Display module Fahrenheit/Celsius Rapid temperature temperature switching cooling Setting the Temperature Adjust the DOWN or UP button on the control panel until the display module shows the desired temperature. - Page 13 Automatic Defrosting There is usually no need to defrost the beer dispenser because the ice deposited on the inner back wall is automatically defrosted. Ice deposits on the inner back wall during compressor operation. Later on, when the compressor is not operating, the ice defrosts and water drains through the outlet in the inner back wall into the drain pan situated above the compressor where it evaporates.
- Page 14 5. Hold the glass steady at a 45° angle. When it is 2/3 full, start straightening the glass. Proper foam should be a tight, creamy head and the collar on an average glass should be 3/4" to 1" high. Note: It is normal to see condensation forming on the tap. It is caused by the difference in temperature between the cold beer and the inner surfaces of the tap when beer is flowing through the line.
- Page 15 MAINTENANCE OF THE BEER DISPENSER Cleaning To optimize cooling and to save energy at the same time, dust the back of the beer dispenser periodically. The interior should be cleaned regularly. Use a soft towel or sponge that has been dampened in a solution of mild detergent. Rinse with clean water and dry with a cloth.
-
Page 16: Disposing Of A Worn-Out Appliance
DISPOSING OF A WORN-OUT APPLIANCE • When your appliance finally wears out, dispose of it. • Before you dispose of an old appliance: Take the door or doors off but leave any shelves or drawers in place so that children cannot easily climb inside. •... - Page 17 DRAFT BEER TROUBLESHOOTING Problem Cause Correction Beer is cloudy: Excessively low Drain a few ounces before drinking. The beer in the temperatures Raise the temperature setting of the unit. glass appears may cause hazy and not clear. hazy or cloudy beer, particularly when the beer...
- Page 18 Beer has off taste: Improper Brush and clean the tap properly. It should be Often bitter and cleaning of the scoured using a detergent, then rinsed clean. bite-y; sometimes completely lacking Contaminated Beer tube should be examined. If contaminated, flavor and zest. It air line it should be replaced.
-
Page 19: General Troubleshooting
GENERAL TROUBLESHOOTING If there is a problem with the beer dispenser itself, see if you can find it listed in the chart below. You may be able to save yourself the cost of a service visit. Problem Possible Cause The beer dispenser doesn’t Power supply not firmly connected. -
Page 20: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
