COFFEE DISPENSERS
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model No. and Serial No. (from
back of unit) here:
________________________________
________________________________
Models SBC570NCF
SBC570CF
SBC570CMTWIN
Instruction Manual
SBC570NCF
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
ww.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit SBC570NCF
Summary of Contents for Summit SBC570NCF
- Page 1 COFFEE DISPENSERS Models SBC570NCF SBC570CF SBC570CMTWIN SBC570NCF Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Model No. and Serial No. (from An ISO 9001:2015 registered company back of unit) here:...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS IMPORTANT – All persons who will operate this equipment must read and become thoroughly familiar with all operating procedures and safety precautions. Misuse of this equipment may result in personal injury, death, or property damage. 1. You will need this manual for the safety warnings and precautions, operating, inspection, maintenance and cleaning procedures, parts list and assembly diagram. - Page 3 18. KEEP UNIT UPRIGHT when transporting. Do not allow to tilt past 45 degrees. Do not upend or turn upside down. 19. WARNING! Children must be supervised around this machine. Make sure that children know that this coffee dispenser is NOT A TOY. Close door during operation and leave closed at all times when children are present.
-
Page 4: Table Of Contents
Coffee Tap Installation ................5 Regulator Installation ..............6-7 Operation, Maintenance & Storage ..............8 Limited Warranty .................... 11 TECHNICAL INFORMATION Models: SBC570NCF(for nitro-infused cold brew coffee) SBC570CF (for “flat” cold brew coffee) SBC570CMTWIN (for both types) Capacity: 6.0 cubic feet Electrical Input:... -
Page 5: Coffee Dispenser Accessories
COFFEE DISPENSER ACCESSORIES (not included) -
Page 6: Coffee Dispenser Assembly
COFFEE DISPENSER ASSEMBLY Be sure you have a thorough familiarity with the assembly and installation process before turning on your coffee dispenser. Coffee Dispenser Tower NOTE: Once casters are assembled, place your unit in an upright position and allow it to sit for at least 8-10 hours before plugging into an outlet. -
Page 7: N 2 Regulator Installation
REGULATOR INSTALLATION Connect to Proper installation of your nitrogen cylinder regulator and a thorough under- standing of N canisters are essential to the safe use of this product. Regulator Review and follow instructions for handling N cylinders and this section in particular to ensure your safety and the safety of others. - Page 8 Carefully place the keg inside the . Attach the coffee coffee dispenser tube from the tower to the “out” post of the of the Cornelius keg by pushing the ball lock down over the “out” post until it snaps in place. (See figure F.) Figure F Attach the N...
-
Page 9: Operation, Maintenance & Storage
OPERATION, MAINTENANCE & STORAGE USING YOUR COFFEE DISPENSER 1. First be sure that you are connected safely to the proper power supply: a 120V, 60Hz, 16 Amp grounded AC outlet. The cord should be rated for AT LEAST 1875 Watts and a No. 14 AWG minimum size. - Page 10 NOTES...
- Page 11 NOTES...
-
Page 12: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
