WINE KEG DISPENSER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. here (can be found either
on back of unit or on an interior wall):
________________________________
Model SWKD571
Instruction Manual
(Kegs not included)
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
ww.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit SWKD571
Summary of Contents for Summit SWKD571
- Page 1 WINE KEG DISPENSER Model SWKD571 (Kegs not included) Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. here (can be found either 770 Garrison Avenue on back of unit or on an interior wall):...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS IMPORTANT – All persons who will operate this equipment must read and become thoroughly familiar with all operating procedures and safety precautions. Misuse of this equipment may result in personal injury, death, or property damage. 1. You will need this manual for the safety warnings and precautions, operating, inspection, maintenance and cleaning procedures, parts list and assembly diagram. - Page 3 17. KEEP UNIT UPRIGHT when transporting. Do not allow to tilt past 45 degrees. Do not upend or turn upside down. 18. WARNING! Children must be supervised around this machine. Make sure that children know that this appliance is NOT A TOY. Close door during operation and leave it closed at all times when children are present.
-
Page 4: Table Of Contents
Temperature Control / Defrosting ............9 Storing Your Wine Keg Dispenser ............9 Cleaning and Maintenance ..............10 Accessories (Parts List) ................. 11 Limited Warranty .................... 12 TECHNICAL INFORMATION Model: SWKD571 Capacity: 6.0 cubic feet Electrical Input: 115VAC ~ 60Hz Rated Current: 1.9A... -
Page 5: Wine Keg Dispenser Flow And Parts
WINE KEG DISPENSER FLOW AND PARTS Wine Dispenser Tower Wine Keg Dimensions Wine Line 23⅜” High-Pressure Valve Bottle Shut Off Safely 9¼” Double Gauge Regulator Low Pressure Valve Line Tank 1/6 Barrel Wine Keg (Not Included) -
Page 6: Wine Keg Dispenser Assembly
WINE KEG DISPENSER ASSEMBLY Be sure you have a thorough familiarity with the assembly and installation process before turning Wine Dispenser on your wine keg dispenser. Tower NOTE: Once casters are assembled, place your unit in an upright position and allow it to sit for at least 8-10 hours before plugging into an outlet. -
Page 7: Regulator Installation
WINE KEG DISPENSER ASSEMBLY, continued REGULATOR INSTALLATION Connect to Proper installation of your N regulator Cylinder and a thorough understanding of N canisters are essential to the safe use of this product. Review and follow Regulator instructions for handling N cylinders and this section in particular to ensure your safety and the safety of others. -
Page 8: N 2 Regulator & Tap Connection Examples
WINE KEG DISPENSER ASSEMBLY, continued REGULATOR & TAP CONNECTION EXAMPLES PLEASE NOTE: Your N hose comes equipped and assembled with coupling connections for the regulator (green coupler) and the tap connection (silver coupler). The photos below show correct connections. -
Page 9: How To Tap A Wine Keg
HOW TO TAP A WINE KEG INSTALLING KEG TAP ON SINGLE BARREL TYPE KEG This wine dispenser's coupler is compatible only with a single 1/6 barrel keg, although a second untapped keg can be stored behind the tapped keg to keep it cold. Your N canister has a capacity of 2.5 lbs, which will deliver approximately 60 gallons of wine. -
Page 10: Operation, Maintenance & Storage
If there is still a problem with ice, disconnect the unit from power and leave the door open until the ice melts. Wipe up the melt water and be sure the interior is dry, then reconnect power. If the problem of icing persists, notify the SUMMIT’s Customer Service at 800-932-4267 STORING YOUR WINE KEG DISPENSER 1. -
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE To clean the lines and tap, first: 1. TURN OFF THE GAS SUPPLY (N 2. Next, wipe the outside of the machine, clean drip Detach wine line tray and around guardrail. Clean the inside of the cabinet by wiping with a damp cloth. Clean gasket on door to help eliminate trapped, spilled wine which could produce mold and mildew. -
Page 12: Accessories (Parts List)
ACCESSORIES ACCESSORIES ACCESSORIES QUANTITY QUANTITY 1. KEG COUPLER 14. KEG BASE BOARD 2. BACKFLOW STOPPER 15. METAL WASHER 3. RUBBER WASHER 16. KEGORATOR CASTERS BRAKE 4. N RUBBER DIRECTIONAL WASHER 17. KEGORATOR CASTERS 5. WINE TOWER WASHER 18. N TANK STRAP WINE TOWER TAP/WINE HOSE ASSEMBLY 19. -
Page 13: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
