RVS systems RVS-507635 Instruction Manual

Backup camera system with mirrorlink
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
Backup Camera System With Mirrorlink
RVS-507635
Before operating the monitor, please read this manual carefully and keep it for future reference
1
Reverse With Confidence ™

Advertisement

loading
Need help?

Need help?

Do you have a question about the RVS-507635 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RVS systems RVS-507635

Summary of Contents for RVS systems RVS-507635

  • Page 1 Instruction Manual Backup Camera System With Mirrorlink RVS-507635 Before operating the monitor, please read this manual carefully and keep it for future reference Reverse With Confidence ™...

  • Page 2: Table Of Contents

    Troubleshooting......31 Warranty & Disclaimer......32-33 RVS Systems...
  • Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The monitor is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
  • Page 4 Rear View Camera System. If you back up while looking only at the monitor, you may cause RVS Systems...
  • Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
  • Page 6 If you have questions about this product, contact: RVS Systems 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.888.881.2601 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
  • Page 7 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
  • Page 8 7. Do not place cables where they may be pinched or stepped on. 8. Leave at least a 2” space between the monitor and walls, cabinets or other objects to allow adequate air circulation. 9. The monitor is not designed to be waterproof. RVS Systems...

  • Page 9: Precautions

    Operating Precautions 1. The monitor can be powered by a 12/24 volt battery, or the vehicle's electrical system. 2. Make sure all cables are connected properly. Improper cable con- nections may damage the monitor. Remove the power cable connections when not using the device. 3.
  • Page 10 7. Auto Reverse Trigger Wire W/Adjustable Delay (0-10 Sec) 8. USB 2.0 Input 9.System: NTSC/PAL Auto Switch 10.OSD Menu/Remote Control 11. Automatic Shut Off After 15 Minutes Of Inactivity 12. Power Supply: DC12V 13. U-Bracket 14. Removable Sunshade Accessories RVS Systems...
  • Page 11 Monitor 1. Volume Decrease/Setting Quantity Decrease/LEFT 2. Menu 3. Volume Increase/Setting Quantity Increase/RIGHT 4. Power 5. CH 1/UP 6. CH 2/DOWN 7. LINK/Confirm Menu 8. Remote Control Sensor 9. Bracket Knob 10. Reset Button 11. Speaker Remote Reverse With Confidence ™...

  • Page 12: Settings

    Volume: Press “LEFT” or "RIGHT" on the monitor/remote control to enter volume menu and also to adjust volume. Press “MENU” to exit the volume setting. Auto Picture: Select option in the image menu, use “LEFT/RIGHT" to toggle between five options (Standard/Movie/Eco/Personal/Vivid). Press “UP/DOWN” to select next menu option. RVS Systems...
  • Page 13 Brightness: Select option in the image menu, use “LEFT/RIGHT" to ad- just brightness, and press “MENU” to confirm desired choice. Press “UP/ DOWN” to select next menu option. Contrast: Select option in the image menu, use “LEFT/RIGHT" to adjust contrast, and press “MENU” to confirm desired choice. Press “UP/DOWN” to select next menu option.
  • Page 14 RIGHT" to toggle menu timeout length. There are seven options: 10 Sec/20 Sec/30 Sec/40 Sec/50 Sec/60 Sec/close. Press “UP/DOWN” to select next menu option. Menu Transparency: Select option in the settings menu, and use “LEFT/RIGHT" to toggle between four options (Close/Low/ Middle/High). Press “UP/DOWN” to select next menu option. RVS Systems...
  • Page 15 Power On Status: Select option in settings menu, and use "LEFT/ RIGHT" to toggle between three options (Last Memory/Standby/Power On). Press “UP/DOWN” to select next menu option. Blue Screen: Select option in settings menu, and use "LEFT/RIGHT" to turn blue screen on/off when there is no signal. Press “UP/DOWN” to se- lect next menu option.
  • Page 16 4. Supports Tablet PC or notebook with WiDi function. 5. All windows devices can use Screen Share by installing AirParrot soft- ware. 6. Supports online movies, online TV channels, online radio and online webpage browsing. 7. Automatically detects variety of operating systems. RVS Systems...
  • Page 17 Miracast Basic Operating Introduction 1. Airplay Mirroring (for iPhone, iPad, Mac notebook) Find monitor’s hot spot (ex: DONGLE-ACA213068A04) from “Settings’’ of Apple devices and connect. Default password: 12345678 (Tips: the hot spot name has been displayed on the top of the screen and the password is behind the PIN) 1-2.
  • Page 18 Open Apple device control center (Note: At this time, the Apple device is connected with the monitor, without WiFi connection, so it can only mirror local data, or mirror on- line data by using 2G/3G/4G from mobile network) RVS Systems...
  • Page 19 Enter into Airplay interface, choose the device name and then start airply iOS 6: Double-click the HOME key or at the bottom of the main screen, you will see “Airplay”. iOS 7 (or above): From main screen slide screen up, Click “Airplay” and se- lect the monitor's hot spot name.
  • Page 20 WiFi network (include hot spot from mobile device, such as smartphone, tablet PC and PC). For example: Click "QC" and enter password, then click “connect”. Open browser, input website IP: 192.168.49.1 to enter setting interface RVS Systems...
  • Page 21 Click Scan, search the available wireless network Choose the available wireless network, then input the password to connect Tips: IP is shown on the top of main interface. The monitor will be restarted and refresh automatically when connected to the WIFI network. If NO SIGNAL appears on the screen, wait for a few minutes.
  • Page 22 2G/3G/4G network, it could mirror local data and network video, no need any other setup. Note: For different cell phones, the method to open screen mirroring function may vary. Please refer to your cell phone user manual for more detailed infor- mation. RVS Systems...
  • Page 23 2-2. Miracast Mirroring ( for Windows 8.1 tablet ) 2-2-1. Move mouse to the right corner, pop up list, select “Device” Reverse With Confidence ™...
  • Page 24 2-2-2. From device list, select “Project” 2-2-3. The first time to use project function, you need to add a wireless display. 2-2-4. After adding the monitor, the computer will automatically find the monitor hotspot. After this occurs click add. RVS Systems...
  • Page 25 Tip 1: The device DONGLE-ACA213068A04 in this manual is an example device. Different monitors will have different names. Please refer to the displayed name on the top of main interface. Tip 2: When adding a device, “press the button on your DON- GLE-ACA213068A04”...

  • Page 26: Dlna

    Tip: The update may take longer depending on internet connection and WiFi signal. 4-3.The monitor will start OTA upgrade mode automatically after downloading the software. It will restart after upgrading. The latest RVS Systems...
  • Page 27 software version will display on the top right corner of the screen. Reverse With Confidence ™...

  • Page 28: Camera

    18 infra-red illuminators (enables you to see in total darkness) • 1/4 Sharp® color CCD, 250k pixels, 2.1 mm wide lens with 130° angle • Shock resistant with a 20G Vibration and 100G impact rating • Built-in high gain microphone RVS Systems...
  • Page 29 Camera Specifications SENSOR 1/4” SHARP® COLOR CCD PICTURE ELEMENTS 250,000 PIXELS GAMMA CORRECTION R=0.45 TO 1.0 IMAGE SENSOR 600 TV LINES, PAL: 500 (H) X 582 (V) NTSC: 510 (H) X 492 (V) LENS 2.1MM VIEW ANGLE 130° WATERPROOF RATING IP69K SYNC SYSTEM INTERNAL SYNCHRONIZATION...
  • Page 30 Use DLNA pushing function. Some players have a built-in DLNA function, or you can download third party DLNA software in APP STORE. 3. Use screen monitoring with systems lower than Windows 8.1. a. Download and install AirParrot. Website: http://airparrot.com/ RVS Systems...
  • Page 31 Miracast FAQ 1. Video is not smooth a. The quality of video playing depends on many factors, including net- work environment, WiFi signal intensity, and video bit rate. If local vid- eo is not smooth, the video bit rate may be too high. b.
  • Page 32 OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE RVS SYSTEMS, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES.
  • Page 33 INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL RVS SYSTEMS AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN CONTRACT, TORT...
  • Page 34 If you have any questions about this product, contact: RVS SYSTEMS, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 888.881.2601 Better Cameras. Better Service. IT’S OUR GUARANTEE. RVS Systems...
