Page 2: What's In The Box
2. With the OSD function, can make the parking sensors sig- nal and the video camera image superposition, output one standard video signal to DVD or other display 3. Installed on the vehicle license plate frame, not destroy body structure; easy to install RVS SYSTEMS... -
Page 3: Installation Instructions
Installation Instructions 5.3 Cable connection instruction Note: Before installing system let the components of the exhaust system cool down. This will make the installation safer and preclude heat damage to the backup sensor wiring or components. Red to back light +12 Red to back light +12 Black to GND Black to GND... -
Page 4: Display Installation
When connecting the power wires, connect the RED to power and the BLACK to ground. 3. Align the host bracket screw groove and the 4. Plug the anti dismounting cap into the screw plate screw holes, Locking screw. hole. Connect the cable. 5.5 Display Installation Monitor RVS SYSTEMS... - Page 5 Installation Instructions Tools Needed Small flat-tip Screwdriver #2 Phillips Screwdriver Tape Measure Black Electrical Tape Masking Tape Multimeter Pliers Pencil/Marker Testing the system: After installing the system, test the sensors. Warning: Do not stand behind a moving vehicle death or injury could occur. Prior to testing, set the parking brake on, ignition key on (do not start), step foot on brake and shift the vehicle into reverse.
-
Page 6: Specifications
-20°C ~ 85°C -30°C ~ 85°C Store temperature Alarm MODE Awareness Distance Sound Digital Display Safe mode 130-150cm Bi...Bi... 1.3m-1.5m Alarm mode 90-130cm Bi..Bi.. 0.9m-1.3m Alarm mode 60-90cm Bi.Bi. 0.6m-0.9m Dange mode 40-60cm BiBi 0.4m-0.6m 0-40cm Dange mode Biiii 0.0m RVS SYSTEMS... - Page 7 Installation Instructions / Splicing Installing & Splitting Embedded Monitor Installing sun shield: Put shade cover on the display. Installing back cover: Put the monitor with shade cover in the back cover (only for embedded monitor) Splitting back cover: Hold monitor with 2 hands and detach with fingers, as indicated by arrows.
- Page 8 If there is a very small object. The rear 45° oblique to the obstacle If there is a wire fence. If it’s a smooth slope Backing up in heavy rain or snow. If is smooth round object Objects absorbing wave, e.g. Cotton RVS SYSTEMS...
-
Page 9: Troubleshooting
Troubleshooting Troubleshooting No buzzer or display at power up. 1. Is power wire connected to control unit correctly? 2. Verify(+)12V at control unit when vehicle is in reverse. 3. Verify the ground connection. 4. Have you connected to the correct reversing indicator wire? 5. -
Page 10: Warranty
RVS Systems, Inc. system after partial failure or use with improper accessories. - Page 11 Neither shall RVS Systems and/or its affiliates have any responsibility for any decision, action or inaction taken by any person in reliance on RVS Systems systems, or for any delays, in- accuracies and/or errors in connection with our systems functions.
- Page 12 If you have any questions about this product, contact: RVS Systems, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 888.881.2601 BETTER CAMERAS. BETTER SERVICE. IT’S OUR GUARANTEE.
