Page 1: User Manual
ENGLISH USER MANUAL DAB /FM DAB-398SD Multi-Language mini Radio IMPORTANT: Please read the manual carefully before using the product and keep it for future reference. -
Page 2: Table Of Contents
DAB-398SD Key Instruction ....................4 OLED Display .......................... 5 Operation Language Setting ....................6 1. Using for the first time or After Resetting DAB-398SD ..........6 2. Changing Language While Using DAB-398SD .............. 6 Clock Setting ........................... 7 Key Lock ..........................7 DAB-398SD DAB Radio Operation .................. -
Page 3: Unpacking
DAB Stations The earpiece is used as an antenna for receiving DAB signal. Note: *The original earphone is specially made for DAB-398SD. We do not guarantee that other brands of earphones will work well with DAB-398SD. V.20200706A... -
Page 4: Dab-398Sd Key Instruction
DAB-398SD Key Instruction Earpiece Socket Charging socket OLED Display On / Off DAB / FM / Menu /Enter Volume+ Next Key Previous Key Volume - / Lock Switch radio on and switch off. （press one time to switch on, Press &... -
Page 5: Oled Display
OLED Display My Favorite Mode DAB Signal DAB Mode Battery Indication F0 01DBC first favourite DAB Channel DAB Station Name FM Mode FM Signal M7 105.5MHz METRO FINANCE The 8 Stored FM Channel FM Frequency RDS Station Name 07DBC DAB Station name We channel Scrolling Message... -
Page 6: Operation Language Setting
Operation Language Setting 1. Using for the first time or After Resetting DAB-398SD When using DAB-398SD for the first time, the user has to choose and set the operation language. The OLED will display “Select Language” automatically, press DAB/FM to confirm, then press or... -
Page 7: Clock Setting
DAB/FM . After adjusting the hour digits the minute digits will flash, press the or key to adjust the minute digits, confirm by pressing DAB/FM again. Wait for 10sec, DAB-398SD will go back to idle mode (showing clock). This number is flashing “DAB/FM”... -
Page 8: Dab-398Sd Dab Radio Operation
Found 4 DAB Stations Scan DAB Stations When scanning has completed, DAB-398SD radio will play the last available DAB radio station through searching. Press the key to choose the previous station or press the key to choose the next station. The name of the DAB radio station will appear on the OLED screen, (eg: “01DBC) -
Page 9: Play The Favourite Dab Radio Station
There are 10 favorite stations that you can save. In DAB radio mode, press the or key to choose the station that you want to save, press and hold the DAB/FM key for 2 seconds, the words “ Store Mode” will appear on the OLED screen, then press the DAB/FM key once to select the stored position and OLED will show “Store TO FX?”... -
Page 10: Exit The Favourite Mode
4. Exit The Favourite Mode In favourite mode, press and hold the DAB/FM key for 2 seconds, OLED will display “Normal Mode”, press the DAB/FM key once again to confirm exiting Favourite Mode. Press & Press & hold hold F0 01DBC Normal mode 01DBC “DAB/FM”... -
Page 11: Scan Fm Radio Station
“DAB/FM” Press … 01DBC FM loading M0 87.5MHz turn to FM mold In DAB mode Loading FM Stations Play the 1 Stored Channel Press to choose M1 91.4MHz next channel Play the 2 Stored Channel 2. Scan FM Radio Station In FM radio mode, press and hold the ... -
Page 12: Pause Or Play Fm Radio
Reset The DAB Radio Stations When the DAB-398SD radio is switched off, press and hold the DAB/FM key first ,Then press and hold the ON/OFF key at the same time as the DAB/FM key for a few seconds until the OLED shows a series of numbers, it means that all previously saved radio stations have been deleted. -
Page 13: Product Specifications
Product Specifications Multi-Language’s Support (English, German, French, Italian, Norwegian, Danish, Swedish, Spanish) Build-in Polymer-Li rechargeable battery (Charging time: 2 hours) *DAB playing time: 7 hours FM playing time: 7 hours 3.5mm plug in headset socket Frequency range: (Band Ⅲ): 174 ~240 MHz Frequency range: (FM): 87.5~108.0 MHz Memory for saving 60 DAB stations...
