Page 1: User Manual
ENGLISH USER MANUAL DAB+/DAB/FM DAB-398WS Multi-Language mini Radio IMPORTANT: Please read the manual carefully before using the product and keep it for future reference. -
Page 2: Table Of Contents
DAB-398WS Key Instruction ....................... 6 OLED Display ............................7 Operation Language Setting ....................... 9 1. Using for the first time or After Resetting DAB-398WS ..........9 2. Changing Language While Using DAB-398WS ............9 Clock Setting ............................10 Sleep Mode Setting .......................... - Page 3 ....................... 17 3. Manual Tune ........................... 18 4. Pause or Play FM Radio ....................18 Reset The DAB Radio Stations ......................19 Safety Information ..........................19 Product Specifications ......................... 20 WARNING: For safety do not operate DAB-398WS while driving V.20210317A...
-
Page 4: Unpacking
Charge Up Please charge the DAB-398WS for 2 hours before using it for the first time. Please plug the charging cable into the socket of the radio and a 'click' sound will be heard, and the red charge light will be on until the radio is full charged. -
Page 5: Earpiece Usage
The earpiece is used as an antenna, so please plug in the cable before using the device and keep the cable as straight as possible for good reception: DAB Stations The earpiece is used as an antenna for receiving DAB signal. Note: *The original earphone is specially made for DAB-398WS. We do not guarantee that other brands of earphones will work well with DAB-398WS. V.20210317A... -
Page 6: Dab-398Ws Key Instruction
DAB-398WS Key Instruction Earpiece Socket Charging socket OLED Display On / Off Volume+ DAB / FM / Menu /Enter / Font Key Next Key Volume - / Lock Previous Key Switch radio on and switch off. ( press one time to switch on, Press & hold 3sec. to switch off ) ON / OFF: As an enter key. -
Page 7: Oled Display
Fine tune FM frequency Next Key： To select the next station Scan for the available FM radio stations. Choose the next DAB and FM stations. Set the clock. Fine tune FM frequency. Volume + / Font：To increase the volume level To change font size ( press &... - Page 8 The sign of sleep mode FM Mode FM Signal M7 105.5MHz METRO FINANCE The 8 Stored FM Channel FM Frequency RDS Station Name 07DBC DAB Station name We channel Scrolling *Note: Minor interference may occur while OLED is on. OLED will turn off automatically after a short while, resume display by pushing any key. V.20210317A...
-
Page 9: Operation Language Setting
Operation Language Setting 1. Using for the first time or After Resetting DAB-398WS When using DAB-398WS for the first time, the user has to choose and set the operation language. The OLED will display “Select Language” automatically, press to confirm, then press for different languages (English, German, French, Italian, Norwegian, Danish , Swedish and Spanish). -
Page 10: Clock Setting
. After adjusting the hour digits the minute digits will flash, press the key to adjust the minute digits, confirm by pressing again. Wait for 10sec, DAB-398WS will go back to idle mode (showing clock). This number is flashing This number is flashing DAB 14：10... -
Page 11: Sleep Mode Setting
Sleep Mode Setting First press the ON/OFF key to enter idle mode (showing clock), second press and hold the key for 2 seconds, then press to choose “Auto Power Off”, and press to enter the setting, the user can press to choose “On”... -
Page 12: Key Lock
Key Lock To enable key-lock： Lock / unlock: Press and hold the Volume – key for Press & hold Locked press and hold “-”for 2 Any Situation 2 seconds, the word “LOCKED” will “–“ for 2sec seconds show on the OLED screen. Shows it is locked To disable key-lock: Press and hold the Volume –... -
Page 13: Dab-398Ws Dab Radio Operation
Big font is On Big font is Off DAB-398WS DAB Radio Operation 1. Scan the DAB Radio Stations When you switch on the radio for the first time, the OLED screen will display the words “DAB Loading”, it will then Auto scan: automatically scan for local DAB radio stations, then it will show “DAB Scanning…”... -
Page 14: Save Your Favourite List Of The Dab Radio Stations
DAB Situation Enter menu mode Enter rescan mode When scanning has completed, DAB-398WS radio will play the last available DAB radio station through searching. Press the key to choose the previous station or press the key to choose the next station. The name of the DAB radio station will appear on the OLED screen, (eg: 01DBC) 2. -
Page 15: Play The Favourite Dab Radio Station
3. Play The Favourite DAB Radio Station: To select favourite mode, press and hold the key during DAB radio mode for 2 seconds to enter the menu option, then press the to enter the “Favourite mode”, press once again to confirm the favourite mode, press the key to choose the favorite station. -
Page 16: Pause Or Play The Dab Radio
5. Pause or Play the DAB Radio In DAB radio mode, press the ON/OFF key to pause the radio. The clock will then appear on the OLED screen (The clock will be adjusted by the DAB radio station automatically). To resume play on the radio, press the ON/OFF key again. Show Time Press one time to pause or... -
Page 17: Fm Radio Operation
FM Radio Operation 1. Listen To FM Radio In DAB mode, press the key once to change to FM mode. The OLED will show “FM Loading…” then the FM radio frequency will appear on the OLED screen. For example: M0 88.0MHz. Press to play the previous channel and press for the next channel. -
Page 18: Manual Tune
3. Manual Tune In FM radio mode, press and hold the key for 2 seconds until the “Manual Tune” icon is shown on the OLED screen, press key to enter ,the word “TUNE" will be shown on the first line, press the keys to adjust the radio frequency, to finish manual tuning, just wait for 10 seconds and confirm. -
Page 19: Reset The Dab Radio Stations
Reset The DAB Radio Stations When the DAB-398WS radio is switched off, press and hold the key first ,Then press and hold the ON/OFF key at the same time as the key for a few seconds until the OLED shows a series of numbers, it means that all previously saved radio stations have been deleted. When you switch on the radio again, it will automatically re-scan the new radio stations available. -
Page 20: Product Specifications
Product Specifications Multi-Language’s Support (English, German, French, Italian, Norwegian, Danish, Swedish, Spanish) Build-in Polymer-Li rechargeable battery (Charging time: 2 hours) *DAB playing time: 7 hours FM playing time: 7 hours 3.5mm plug in headset socket Frequency range: (Band Ⅲ): 174 ~240 MHz Frequency range: (FM): 87.5~108.0 MHz Memory for saving 60 DAB stations...
